HSP GmbH Zum Handwerkerhof 2 90530 Wendelstein Tel. 09129 / 2852-0 Fax: 09129 / 2852-11 Web: www.hsshsp.de EMAIL: HSP@hsshsp.de NTG-3000 Transducer Operating Instructions Document Version 2.11 Software Version 3.8 NTG-3000 Operating Instructions Version 2.11 Page 1 of 18...
Page 2
HSP GmbH Zum Handwerkerhof 2 90530 Wendelstein Tel. 09129 / 2852-0 Fax: 09129 / 2852-11 Web: www.hsshsp.de EMAIL: HSP@hsshsp.de Versions / Revisions: Document Creation Author Description version date 2012-07-25 P. Compensis First official version 2012-09-17 P. Compensis Description for software version 3.2 2012-10-16 P.
Ethernet/PROFIBUS. This document describes installation, connection and startup of the transducer. 2 Scope of application of this document These Operating Instructions only apply to transducer NTG-3000. Software Version >=3.8 Hardware Rev. 5.1 3 Transport and storage 3.1 Storage temperature...
Page 5
HSP GmbH Zum Handwerkerhof 2 90530 Wendelstein Tel. 09129 / 2852-0 Fax: 09129 / 2852-11 Web: www.hsshsp.de EMAIL: HSP@hsshsp.de 5.1 Installation The following steps must be performed for installing the device: 1. Hook on 2. Swivel and click in place 5.2 Removal...
HSP GmbH Zum Handwerkerhof 2 90530 Wendelstein Tel. 09129 / 2852-0 Fax: 09129 / 2852-11 Web: www.hsshsp.de EMAIL: HSP@hsshsp.de 6 Connection A protective conductor (PE) and the voltage supply must always be connected (terminal X100). All other connections are optional for the purposes of operation.
HSP GmbH Zum Handwerkerhof 2 90530 Wendelstein Tel. 09129 / 2852-0 Fax: 09129 / 2852-11 Web: www.hsshsp.de EMAIL: HSP@hsshsp.de 7 Description of design of connections 7.1 Connection of protective conductor (PE) Before the device is placed in operation, a connection must be established between protective conductor terminal X100/3 and the PE potential of the place of installation.
HSP GmbH Zum Handwerkerhof 2 90530 Wendelstein Tel. 09129 / 2852-0 Fax: 09129 / 2852-11 Web: www.hsshsp.de EMAIL: HSP@hsshsp.de 8 Configuration The transducer must be configured for the connected signals (terminal strips X500 to X503 and X600 to X602) before it is placed in operation for the first time. The 16-position rotary switch labeled “CONFIGURATION”...
HSP GmbH Zum Handwerkerhof 2 90530 Wendelstein Tel. 09129 / 2852-0 Fax: 09129 / 2852-11 Web: www.hsshsp.de EMAIL: HSP@hsshsp.de 9 LEDs Description Color POWER Lit when operating voltage is present Green STATUS To indicate operation and errors (see 15.1) Green ERROR To indicate error conditions (see 15.1)
HSP GmbH Zum Handwerkerhof 2 90530 Wendelstein Tel. 09129 / 2852-0 Fax: 09129 / 2852-11 Web: www.hsshsp.de EMAIL: HSP@hsshsp.de 11 Measured value acquisition 11.1 Filtering of the analog inputs (U1–3 and I1–3) The analog inputs (U1–3 and I1–3) are filtered by default. This filtering can be disabled via the option byte (see NTG 3000 - Data protocol).
Page 11
HSP GmbH Zum Handwerkerhof 2 90530 Wendelstein Tel. 09129 / 2852-0 Fax: 09129 / 2852-11 Web: www.hsshsp.de EMAIL: HSP@hsshsp.de 11.2 Scan Rate of the analog inputs The measured values are read at different rates in the different modes: Scan Rate Mode 1 100 µs...
HSP GmbH Zum Handwerkerhof 2 90530 Wendelstein Tel. 09129 / 2852-0 Fax: 09129 / 2852-11 Web: www.hsshsp.de EMAIL: HSP@hsshsp.de 12 Filter For the filtered compensated frequency (f ) and the filtered effective power (P comp filtered filtered there are three filters of second order integrated.
Page 13
HSP GmbH Zum Handwerkerhof 2 90530 Wendelstein Tel. 09129 / 2852-0 Fax: 09129 / 2852-11 Web: www.hsshsp.de EMAIL: HSP@hsshsp.de 12.3 Filter parameters of the first and second filter level The parameters of the first and second filter level must be parameterized over Profibus (see section “Settings via PROFIBUS”...
Web: www.hsshsp.de EMAIL: HSP@hsshsp.de 13 Algorithms The NTG-3000 is equipped with various algorithms to catch errors and to detect and to display them. 13.1 Simple Phase Failure Detection At each system cycle the simple phase failure detection examines, whether the sum of the phase voltage is within a threshold around zero.
HSP GmbH Zum Handwerkerhof 2 90530 Wendelstein Tel. 09129 / 2852-0 Fax: 09129 / 2852-11 Web: www.hsshsp.de EMAIL: HSP@hsshsp.de 13.3 Rate-of-Change-Limiter The Rate-of-Change-Filter prevents, that the calculated compensated frequency (f comp gefiltert makes a step in case of a phase failure. This cannot physically occur due to the inertia of the generator.
Page 16
HSP GmbH Zum Handwerkerhof 2 90530 Wendelstein Tel. 09129 / 2852-0 Fax: 09129 / 2852-11 Web: www.hsshsp.de EMAIL: HSP@hsshsp.de 15.1 Status and error LEDs STATUS LED ERROR LED (green) (red) Normal operation 1 Hz System startup (for approx. 2 seconds) or during...
Page 17
HSP GmbH Zum Handwerkerhof 2 90530 Wendelstein Tel. 09129 / 2852-0 Fax: 09129 / 2852-11 Web: www.hsshsp.de EMAIL: HSP@hsshsp.de Error description: No data are being received from the transducer via Ethernet. Action: Check the IP address of the receiver (see Section 13) and the Ethernet cable connection (see Section 7.4).
HSP GmbH Zum Handwerkerhof 2 90530 Wendelstein Tel. 09129 / 2852-0 Fax: 09129 / 2852-11 Web: www.hsshsp.de EMAIL: HSP@hsshsp.de 16 Overview about changes 16.1 Version 3.7 to Version 3.8 Error correction in the advanced phase of failure detection. ...
