Summary of Contents for Verint Nextiva S2800e V-UPM-1
- Page 1 Nextiva S2800e V-UPM-1 Outdoor Parapet Mount Installation & Operation Manual...
- Page 2 Verint Systems Inc. does not warrant, guarantee or make any representation regarding the use or the results of the use of the information, links, tools, and materials in terms of the accuracy, reliability, quality, validity, stability, completeness, currentness, or otherwise of its content or products.
- Page 3 Introduction ® The information in this manual covers the installation, operation, and maintenance of the Nextiva S2800e V-UPM-1 Parapet Mount. This unit should only be installed by a qualified technician using approved materials and wiring practices in accordance with the National Electrical Code ANSI/NFPA 70, state, and local codes.
- Page 4 TABLE 1 MOUNTING KIT COMPONENTS Item No. Component Quantity Function Wall bracket Secures parapet mount to mounting surface Wall bracket cover Secures parapet mount in wall bracket Support bracket Secures bottom wall bracket Closes off bottom of mount but allows cabling to be routed 5/16-18x1 in.
- Page 5 Before beginning installation of the parapet mount, run all necessary cabling to the location selected for the installation. Cables are routed up through the mount to the dome system. 1. Attach one wall bracket and the support bracket to the parapet surface using appropriate hardware for the material of the parapet.
- Page 6 Nextiva S2800e Figure 1 V-UPM-1 Installation...
- Page 7 Figure 2 Mounting Plate Dimensions Operation To swivel the mount in from the parapet for access to the dome system, loosen the bolts enough to allow movement. Swing the unit in from the parapet. Tighten the bolts. After servicing or adjustment is complete, loosen the bolts, position the mount, and tighten bolts.
