Instruction manual
SWIRL-2 propeller range
Aérodrome de Villefranche Tarare (LFHV)
289 Avenue Odette & Edouard DURAND
69620 FRONTENAS - FRANCE
Phone : + 33 (0)4 74 72 12 69 - Fax : +33 (0)4 74 72 10 01
ISO 9001:2008 Certified Company
E-mail : contact@duc-helices.com - www.duc-helices.com
for its Quality System Management
DH_SW2_BE_02_D
Made in France
22/03/2017
Advertisement
Table of Contents
Related Manuals for DUC Hélices SWIRL-2
Summary of Contents for DUC Hélices SWIRL-2
- Page 1 Instruction manual SWIRL-2 propeller range Aérodrome de Villefranche Tarare (LFHV) 289 Avenue Odette & Edouard DURAND 69620 FRONTENAS - FRANCE Phone : + 33 (0)4 74 72 12 69 - Fax : +33 (0)4 74 72 10 01 ISO 9001:2008 Certified Company E-mail : contact@duc-helices.com - www.duc-helices.com...
- Page 2 Revision update Date Index Object of modification 23/12/2014 Creation in English 20/01/2015 Minor correction 02/04/2015 Update of the hub 01/06/2015 Update 22/03/2017 New address This instruction manual is to be maintained throughout the life of the propeller. He may have to evolve. The owner must check with the DUC Hélices company the latest version being valid applicable to the propeller.
- Page 3 Identification Date Delivery note n° Engine/Gearbox Owner ratio recommended Aircraft pitch blade angle Notes: ........................................................................................................................................................................................Performances PITCH (°) at FULL TAKE-OFF SLOW VARIOUS FAST CLIMB RATE 25cm from the THROTTLE DISTANCE CRUISE CRUISE CRUISE tip of the VARIO 0 (ft/min or m/s) (km/h &...
-
Page 4: Table Of Contents
11.1. Dimension of the engine propeller-shaft ......................21 11.2. Airfoil ................................22 11.3. Moment of inertia of the SWIRL-2 propeller ....................22 11.4. Operating limitation of the SWIRL-2 propeller ....................22 11.5. Identification marking of the propeller ......................22 11.6. -
Page 5: Presentation Of The Swirl-2 Propeller
2-blade hub available in Compact version for Ø210mm spinner (Ø4”) Direct assembly on the propeller-shaft Ø101.6mm Excellence version “SWIRL-2-R” for direct drive engine from 100hp to 140hp: Longitudinal reinforced carbon structure Higher bending strength Titanium color finishing Advanced controls... -
Page 6: Shielding Leading Edge In Inconel
Preview Designation Reference Part number Ø101.6mm (4") Compact hub – Fixing with 6 screws CHC M8 with Ø13 or 14mm drive lug Two-blade Inconel SWIRL-2 propeller, Right (Compact hub) 01-28-001 H-SW2_2-D-I_MFU Two-blade Inconel SWIRL-2-R propeller, Right (Compact hub) 01-37-001 H-SW2_2-D-R_I_MFU Ø101.6mm (4") hub –... -
Page 7: Applications
(hour) (inch) (°) range(°) 3 AXIS – TRACTOR 15° → 23° JABIRU 2200 4 strokes Two-blade Inconel SWIRL-2, right Ø1620 18° 16° → 24° JABIRU 3300 4 strokes Two-blade Inconel SWIRL-2-R, right Ø1660 19° 15° → 23° UL Power 260i/iS... -
Page 8: Components Of The Swirl-2 Propellers
4. Components of the SWIRL-2 propellers The SWIRL-2 propellers are available in several versions and can be mounted on different model of engine. 4.1. Mounting configuration of the SWIRL-2 propellers Here is a configuration table of the SWIRL-2 propeller mounting according the propeller-shaft of the engine. -
Page 9: Exploded View For Propeller
(x6) Remark This exploded view shows the principle of the SWIRL-2 propeller assembly. The size of all of these components changes depending on the configuration of the propeller (diameter hole of the metallic inserts of the half-hub, length of the screws…). -
Page 10: Assembly Instruction Of The Propeller
5. Assembly instruction of the propeller The assembly of the SWIRL-2 propellers is shown below. It is recommended to assemble the propeller on a worktable before installing it on the plane. The procedure is the same for two-blade and three-blade SWIRL-2 propellers. -
Page 11: Installation On The Aircraft
If needed, see in annex 11.1. Dimension of the engine propeller-shaft. Remark: All engines having a propeller-shaft with a P.C.D. Ø101.6mm/Ø4" can install the SWIRL-2 propeller directly. The holes of the metal inserts of the rear half-hub must be adapted to suit with the indexing paws of the propeller-shaft. - Page 12 A spacer is necessary in the following case: Engine propeller-shaft type Jabiru (6 indexing paws Ø14mm on P.C.D. Ø101.6mm/Ø4") Engine propeller-shaft placed inside the engine hood or not place at more than 14mm Determination of the spacer length: Measure the distance X between the propeller-shaft and the engine hood limit, then add 14mm.
- Page 13 45 N.m information. Remark: It is imperative to use a spinner when using propeller SWIRL-2. The mounting plate of the spinner can be placed before or after the spacer adaptation. It is necessary to adapt the mounting in function of its position.
-
Page 14: Setting Of The Propeller & Finalization Of The Installation
5.3. Setting of the propeller & Finalization of the installation At this point, the propeller is installed on your aircraft with the spinner mounting plate. If the propeller is already assembled and the blades angle set, pass directly Otherwise, follow all the steps below to adjust the pitch angle before the final tightening of the screw. - Page 15 SWIRL-2 Slightly untighten the propeller fixing screws and the hub assembly screw. Note : M6 screw presence in the case of the Compact Hub version. Adjustment roller of the leading edge 25 cm Reading blade angle Intrados of the blade with the...
- Page 16 After a final verification (position and orientation of parts, tightening...), mount the spinner on the mounting plate by tightening the spinner screws to a torque of 4Nm (0.4kg/m) with the appropriate tools. In the presence of a marking, please respect the indexing of the spinner from its plate. SWIRL-2 At this point, the propeller is ready for first tests.
-
Page 17: Precautions
SWIRL-2 6. Precautions PRECAUTIONS If you notice any abnormal installation or operation, do not undertake the flight and immediately contact the DUC Hélices company. Being aware of potential risks during assembly and initial testing of the propeller. Stay focused, attentive and vigilant to your environment. Recheck several times points to be observed. -
Page 18: Installation Without Spinner Or With Spinner Other Than Duc
8. Installation without spinner or with spinner other than DUC In the case of installation of the propeller without spinner mounting plate or other spinner mounting plate, be careful to check the following points: Length of the fixing screws of the propeller: Must be adapted according the thickness of the spinner mounting plate. -
Page 19: Regular Maintenance (By The User)
SWIRL-2 9.1. Regular maintenance (by the user) For a safety use of the SWIRL-2 propellers, it is necessary that the user performs regular maintenance to detect any abnormalities. This maintenance is usually just a simple check. Frequency of checking: Each pre-flight Control methods: Visual inspection &... -
Page 20: Complete Maintenance (By Duc Hélices)
9.3. Complete maintenance (by DUC Hélices) Upon reaching the TBO (potential flight time between overhaul) defined by DUC Hélices, the propeller must be returned to the corporation for a full inspection of all components of the propeller. See section 2. Applications for the potential value of an hour's flight engine. The possible degradation of the propeller components may vary depending on the location of use. -
Page 21: Annexes
SWIRL-2 11. Annexes 11.1. Dimension of the engine propeller-shaft ROTAX 912S engine propeller-shaft JABIRU 2200 engine propeller-shaft Tightening torque 6 central screw = 4,0 Kg/m ; 40 N.m Note: Drilling holes for optional pin UL Power engine propeller-shaft Lycoming O-235-H2C engine prop-shaft, type SAE 1... -
Page 22: Airfoil
Leading edge Intrados Extrados Axis of propeller carrier plate completely vertical Trailing edge Advancement of the aircraft 11.3. Moment of inertia of the SWIRL-2 propeller Coming soon. 11.4. Operating limitation of the SWIRL-2 propeller Maximum Maximum Designation Reference engine power... -
Page 23: Declaration Of Conformance Of The Swirl-2 Propellers
11.6.3. Design Control The SWIRL-2 propeller was design on CAD software. All the CAD files and 2D drawings are stored in the Design Office of DUC Hélices Company, as the definition of the SWIRL-2 configurations. All the technical data (dimensions, materials and processes) are saved in manufacturing procedure. - Page 24 Aérodrome de Villefranche-Tarare (LFHV) 289 Avenue Odette & Edouard DURAND 69620 FRONTENAS - FRANCE ISO 9001:2008 Phone: + 33 (0)4 74 72 12 69 - Fax: +33 (0)4 74 72 10 01 certified company E-mail: contact@duc-helices.com - www.duc-helices.com After sales service: service.technique@duc-helices.com Neoprene cover –...
