Summary of Contents for Sauer Danfoss DP200 Series
- Page 1 PLUS+1 GUIDE DP200 Series Graphical Terminals Technical Information...
-
Page 2: Table Of Contents
DP210 Series USB mini-B connector pin out information ..........8 Order Variants DP200 Series Available Models ....................9 DP210 Series Available Models ....................9 DP200 Series Related Products Part Numbers ..............10 Accessories ..............................10 Operating Considerations .........................11 © 2007 Sauer-Danfoss. All rights reserved. Printed in Europe.•... -
Page 3: Introduction
PLUS+1 GUIDE DP200 Graphical Terminals Introduction DP00 Features The DP200 series of PLUS+1 graphical terminals provides a cost effective, high quality solutions to fit the needs of today’s mobile machines. Features (Model Dependent): • High resolution grayscale LCD display •... -
Page 4: Dp200 Series Dimensions
PLUS+1 GUIDE DP200 Graphical Terminal DP200 Series Dimensions DP00 Model Features The DP200 Series of graphical terminals are available in two general variants, the DP200 series and the DP210 series DP00 Dimensions 41.5 mm [1.63 in] 32.5 mm [1.27 in] 115.9 mm [4.56 in]... -
Page 5: Installation Drawing
PLUS+1 GUIDE DP200 Graphical Terminals Installation Drawing Installation Tolerances 106.2 mm (+/- 0.3) [4.18 in (+/- 0.01)] 115.9 mm ( 0.3) [4.56 in (+/- 0.01)] Panel gasket seal 106.2 mm [4.18 in] (±0.3 mm[0.01 in]) • Gasket seal area crosshatched •... -
Page 6: Installation Procedures
Panel Gasket Bracket 10105917 Panel Bracket 10105915 M3x10 Screw (x4) Fastening Installation Mounting screw placement DP200 Series Electrical Connection Kit 101009 12-pin Deutsch connection Kit Contents: 10100738 DTM06-12SA 12-pin Deutsch connector 10100743 Deutsch terminal 10100741 WM 12S locking plug Mounting and fastening Installation •... -
Page 7: Pin Functions
PLUS+1 GUIDE DP200 Graphical Terminals Pin Functions DP200 Series Product Parameters DP200 Series Processor ARM 7 core, 32 bit/ 60 MHz 64KB on-chip, 512MB on board FRAM 16 KB Power Supply 9–63 Vdc/6.5 Watts Connector Deutsch DTM-12 Type LCD with 32 grayscale levels... -
Page 8: Pinout Functions
PLUS+1 GUIDE DP200 Graphical Terminal Pinout Functions Deutsch DTM-1 Pinout Function DP200 Series pin assignments Code B 00 Code B 01 Code B 04 Power ground- Power supply+ CAN 0+ CAN 0– AIN/ CAN Shield See Code B option DIN/AIN... -
Page 9: Order Variants
RTC and LTF D Flash Memory/Application Key 2MB without Application Key 2MB with Application Key Application Log None 4 MB USB Port Type None USB Device DP200 Series Available Models DP200-00-00-01-00-00 10107021 10107380 DP200-00-01-03-00-00 DP200-01-01-02-00-00 10106883 10107381 DP200-01-01-03-00-00 DP200-04-01-02-00-00 10107022... -
Page 10: Dp200 Series Related Products Part Numbers
PLUS+1 GUIDE DP200 Graphical Terminal Accessories DP200 Series Related Products Part Numbers Accessories 10106893 J1939 CAN Engine Monitor Software 10100944 Deutsch Mating Connector Bag Assembly 10107264 DP2XX Mounting Hardware Kit 10101000 PLUS+1 GUIDE Single User License Electrical Connection Kits 10100944... -
Page 11: Operating Considerations
PLUS+1 GUIDE DP200 Graphical Terminals Operating Considerations APPLICATION • Disconnect your machine’s battery power before connecting power and signal AND OPERATING cables to the DP200. CONSIDERATIONS • Before doing any electrical welding on your machine, disconnect all power and signal cable cables connected to the DP200 •... - Page 12 OUR PRODUCTS Sauer-Danfoss Mobile Power and Control Systems – Market Leaders Worldwide Hydrostatic transmissions Sauer-Danfoss is a comprehensive supplier providing complete Hydraulic power steering systems to the global mobile market. Electric power steering Sauer-Danfoss serves markets such as agriculture, construction, Electrohydraulic power steering road building, material handling, municipal, forestry, turf care, and Closed and open circuit axial piston...
