OWNERS
MANUAL
Model No.
45-03252
CAUTION:
Read Rules for
Safe Operation
and Instructions
Carefully
PRINTED IN USA
™
45 GALLON ATV SPRAYER
IMPORTANT!
The wheel bearings are not prelubricated.
The wheel hubs must be fi lled with grease after the wheels
are assembled to the axle.
• Assembly
• Operation
• Maintenance
• Repair Parts
the fastest way to purchase parts www.speedepart.com
FORM NO. 40216 (2/06)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 45-0325 and is the answer not in the manual?

Questions and answers

Related Manuals for Agri-Fab 45-0325

Summary of Contents for Agri-Fab 45-0325

  • Page 1 ™ OWNERS MANUAL Model No. 45-03252 CAUTION: Read Rules for Safe Operation and Instructions Carefully PRINTED IN USA 45 GALLON ATV SPRAYER IMPORTANT! The wheel bearings are not prelubricated. The wheel hubs must be fi lled with grease after the wheels are assembled to the axle.

  • Page 2: Rules For Safe Operation

    Any power equipment can cause injury if operated improperly or if the user does not understand how to operate the equipment. Exercise caution at all times when operating equipment. 1. Read this owners manual carefully before attempting to assemble or operate this sprayer. 2.

  • Page 3: Full Size Hardware Chart

    FULL SIZE HARDWARE CHART KEY QTY. DESCRIPTION KEY QTY. DESCRIPTION KEY QTY. DESCRIPTION KEY QTY. DESCRIPTION Hex Bolt, 3/8" x 4-1/4" Hex Bolt, 3/8" x 4-1/4" Hex Bolt, 3/8" x 4-1/4" Hex Bolt, 3/8" x 2-1/2" Hex Bolt, 3/8" x 2-1/2" Hex Bolt, 3/8"...

  • Page 4: Tools Required For Assembly

    ASSEMBLY INSTRUCTIONS TOOLS REQUIRED FOR ASSEMBLY (2) 7/16" Wrenches (2) 1/2" Wrenches (2) 9/16" Wrenches (1) Adjustable Wrench (1) Screwdriver (1) Pliers (1) Grease Gun 1. Remove all items from the carton and lay them out as shown on pages 2 and 3. 2.
  • Page 5 5. Assemble the axle through the side angles and the tongue. Fasten the axle to the side angles using two 1/4" x 2" hex bolts and two 1/4" nylock nuts. Do not tighten yet. See fi gure 4. 1/4" x 2" HEX BOLT AXLE 1/4"...
  • Page 6 IMPORTANT: Do not overtighten bolts fastening to tank. Tighten until lock washers are snug and fl attened. 11. Attach the tank to the frame using six 1/2" spacers with six 3/8" x 1-1/4" hex bolts, 3/8" lock washers and 3/8" fl...
  • Page 7 19. Attach the (RH) boom arm assembly to the (RH) boom mount assembly as shown in fi gure 11, using a 3/8" x 4-1/4" hex bolt, three 3/8" fl at washers, and one 3/8" nylock nut. Do not overtighten. 20. Place a 3/8" x 2-1/2" hex bolt through the loose end of the spring and then assemble a 3/8"...
  • Page 8 29. Connect the boom connecting hose and the return (bypass) hose to the "Y" valve fi tting, placing a hose gasket in the swivel nut on each hose. Insert the return hose into the top of tank. See fi gure 15. BOOM HOSE GASKET CONNECTING...

  • Page 9: Operation

    OPERATION BEFORE STARTING It is important to test the boom and spray gun with plain water fi rst to check the sprayer for leaks and to set the spray pattern and nozzle pressure. If a leak should occur, thread tape may be used to better seal the fi tting. PUMP PRESSURE SWITCH The pump is equipped with a pressure switch.

  • Page 10: Maintenance

    4. Set the desired boom pressure, spraying with plain water while making pressure adjustments. For best results stay in the 20 to 30 PSI range. (At 10 PSI the spray pattern begins to break up, and at 40 PSI some drift develops.) Refer to the tip chart on page 11.
  • Page 11 Spray Spray Spray Spray Spray Spray Spray Pressure Pressure Pressure Pressure Pressure Pressure Pressure Tip Capacity Tip Capacity Tip Capacity Tip Capacity Tip Capacity Tip Capacity Tip Capacity Width Width Width Width Width Width Width US Gallons US Gallons US Gallons US Gallons US Gallons US Gallons...
  • Page 12 REPAIR PARTS FOR 45 GALLON SPRAYER MODEL 45-03252...
  • Page 13 REPAIR PARTS FOR 45 GALLON SPRAYER MODEL 45-03252 REF. REF. REF. REF. REF. REF. PART PART PART PART PART PART QTY. QTY. QTY. QTY. QTY. QTY. DESCRIPTION DESCRIPTION DESCRIPTION DESCRIPTION DESCRIPTION DESCRIPTION 47419 47419 47419 47419 47419 47419 Tank (45 Gallon) Tank (45 Gallon) Tank (45 Gallon) Tank (45 Gallon)
  • Page 14 NOTES...
  • Page 15 NOTES...

  • Page 16: Repair Parts

    REPAIR PARTS Agri-Fab, Inc. 303 West Raymond Sullivan, IL. 61951 217-728-8388 © 2004 Agri-Fab, Inc. www.agri-fab.com...
