LG 55LK535C Service Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
LED LCD TV
SERVICE MANUAL
CHASSIS : LC0AD
MODEL: 55LK535C
CAUTION
BEFORE SERVICING THE CHASSIS,
READ THE SAFETY PRECAUTIONS IN THIS MANUAL.
P/NO : MFL67180810 (1206-REV00)
Internal Use Only
http://biz.lgservice.com

Advertisement

loading

Related Manuals for LG 55LK535C

Summary of Contents for LG 55LK535C

  • Page 1 Internal Use Only http://biz.lgservice.com LED LCD TV SERVICE MANUAL CHASSIS : LC0AD MODEL: 55LK535C CAUTION BEFORE SERVICING THE CHASSIS, READ THE SAFETY PRECAUTIONS IN THIS MANUAL. P/NO : MFL67180810 (1206-REV00)

  • Page 2: Table Of Contents

    CONTENTS ....................2 PRODUCT SAFETY ................. 3 SPECIFICATION..................6 ADJUSTMENT INSTRUCTION..............9 BLOCK DIAGRAM..................13 EXPLODED VIEW ..................15 SCHEMATIC CIRCUIT DIAGRAM .............. - 2 - Copyright ©2011 LG Electronics. Inc. All rights reserved. LGE Internal Use Only Only for training and service purposes...

  • Page 3: Product Safety

    An other abnormality exists that must be corrected before the receiver is returned to the customer. Copyright ©2011 LG Electronics. Inc. All rights reserved. - 3 - LGE Internal Use Only Only for training and service purposes...
  • Page 4 Copyright ©2011 LG Electronics. Inc. All rights reserved. - 4 - LGE Internal Use Only Only for training and service purposes...
  • Page 5 CAUTION: Maintain original spacing between the replaced component and adjacent components and the circuit board to prevent excessive component temperatures. Copyright ©2011 LG Electronics. Inc. All rights reserved. - 5 - LGE Internal Use Only Only for training and service purposes...

  • Page 6: Specification

    0.630 mm x 0.630 mm 55”LGD(FHD,100Hz) EEFL Back Light 55”LGD(FHD) Edge 3D EEFL 1.06 Billion, 16.7 Milion Display Colors 3H, AG Coating - 6 - Copyright ©2011 LG Electronics. Inc. All rights reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 7 1200*1024 63.595 60.02 108.875 SXGA FHD model 1280*720 74.25 720p DTV Standard 1920*1080 66.587 59.93 138.5 WUXGA FHD model - 7 - Copyright ©2011 LG Electronics. Inc. All rights reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 8 59.87 79.5 WXGA HDCP 1360*768 47.72 59.8 84.75 WXGA HDCP 1280*720 74.25 HDCP HDCP/FHD model 148.5 WUXGA 1920*1080 67.5 Copyright ©2011 LG Electronics. Inc. All rights reserved. - 8 - LGE Internal Use Only Only for training and service purposes...

  • Page 9: Adjustment Instruction

    3) Click “Read” tab, and then load download file(XXXX.bin) by clicking “Read” 4) Click “Connect” tab. If “Can’t” is displayed, check connection between computer, jig, and set. - 9 - Copyright ©2011 LG Electronics. Inc. All rights reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 10 Module Tool option1 Tool option2 Tool option3 Tool option4 Tool option5 55LK535C 46784 19478 24864 49161 14616 4) Completed selecting Tool option. - 10 - Copyright ©2011 LG Electronics. Inc. All rights reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 11 • Check whether written EDID data is correct or not. * For Service main Assembly, EDID have to be downloaded to Insert Process in advance. - 11 - Copyright ©2011 LG Electronics. Inc. All rights reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 12 • Enter “START” by pushing “OK” key. For Analog EDID For HDMI EDID D-sub to D-sub DVI-D to HDMI or HDMI to HDMI - 12 - Copyright ©2011 LG Electronics. Inc. All rights reserved. LGE Internal Use Only Only for training and service purposes...

  • Page 13: Block Diagram

    BLOCK DIAGRAM - 13 - Copyright ©2011 LG Electronics. Inc. All rights reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 14 - 14 - Copyright ©2011 LG Electronics. Inc. All rights reserved. LGE Internal Use Only Only for training and service purposes...

  • Page 15: Exploded View

    X-RADIATION, Shock, Fire, or other Hazards. Do not modify the original design without permission of manufacturer. Copyright LG Electronics. Inc. All rights reserved. - 15 - LGE Internal Use Only Only for training and service purposes...
  • Page 16 RSDS Power OPT +3.3V_Normal +1.26V_VDDC +1.26V_VDDC VDDC 1.26V MODEL OPTION VDD_RSDS:88mA VDDC : 2026mA MODEL OPTION VDD_RSDS PIN NAME PIN NO. HIGH OPT_0 OPT_4 L213 +2.5V_Normal BLM18PG121SN1D NO_FRC : LOW MODEL_OPT_0 FRC_HW_OPT NO FRC U3_INTERNAL : HIGH LOW U5_EXTERNALBOOT :HIGH HIGH L214 MODEL_OPT_4 50/60Hz LVDS...
  • Page 17 EAN61829001 EAN61857101 EAN61857201 IC301-*3 IC301-*2 K4B1G1646G-BCH9 IC301-*4 H5TQ1G63DFR-PBC NT5CB64M16DP-CF FRC_DDR_1600_HYNIX FRC_DDR_1333_SS_NEW FRC_DDR_1333_NANYA_NEW VREFCA VREFCA VREFCA VREFDQ VREFDQ VREFDQ VCC1.5V_U3_DDR DDR3 1.5V By CAP - Place these Caps near Memory VCC1.5V_U3_DDR VDD_1 VDD_1 +1.5V_FRC_DDR A10/AP VDD_2 VDD_1 A10/AP VDD_2 VDD_3 A10/AP VDD_2 VDD_3 A12/BC...
  • Page 18 ST_3.5V--> 3.375V --> 3.46V +12V/+15V 20V-->3.51V --> 3.76V (3.59V) +3.5V_ST -> 3.375V +12V/+15V +3.5V_ST FROM LIPS & POWER B/D PANEL_POWER 24V-->3.78V --> 3.92V (3.79V) +3.5V_ST 12V -->3.58V --> 3.82V (3.68V) R488 18.5V-->3.5V --> 3.75V (3.59V) 100K IC408 R405-*1 R407-*1 NCP803SN293 0.01uF C442 C409...
  • Page 19 CRYSTAL_KDS X1002-*1 32.768KHz +3.5V_ST NEW_SUB R4034 4.7K X1002 32.768KHz NEW_SUB R4035 4.7K CRYSTAL_EPSON R1034 4.7M CRYSTAL_KDS +3.5V_ST R1091 10K for Debugger MICOM_DEBUG_WAFER TP1601 P1001 +3.5V_ST 12505WS-12A00 C1010 0.1uF TOP SIDE for reset. TP1602 MICOM_RESET MICOM_DEBUG +3.5V_ST NEC_ISP_Tx MICOM_DEBUG NEC_ISP_Rx R1047 MICOM_DEBUG C1003 1/16W...
  • Page 20 CONTROL IR & LED +3.5V_ST EYEQ/TOUCH_KEY R2405 R2411 R2404 EYEQ/TOUCH_KEY OLD_SUB NEW_SUB NEC_EEPROM_SCL P2401 P2402 12507WR-12L 12507WR-15L 5.6V C2408 18pF D2403 L2401 R2401 BLM18PG121SN1D KEY1 EYEQ/TOUCH_KEY EYEQ/TOUCH_KEY R2402 L2402 D2402 NEC_EEPROM_SDA BLM18PG121SN1D 5.6V R2412 5.6V KEY2 C2409 D2404 AMOTECH 18pF C2401 C2402 0.1uF...
  • Page 21 USB_DIODES EAN61849601 IC1450 L1451-*1 AP2191DSG CIS21J121 +5V_USB L1451 MLB-201209-0120P-N2 $0.077 OUT_2 IN_1 120-ohm C1452 OUT_1 IN_2 C1453 R1458 R1459 10uF C1451 0.1uF 1/8W 1/8W 22uF +3.3V_Normal R1455 4.7K USB_JACK USB1_CTL R1454 USB_JACK_LV3400 R1451 47 USB1_OCD JK1450-*1 JK1450 SIDE_USB_DM SIDE_USB_DP D1451 RCLAMP0502BA SYMBOL MARK OF THIS SCHEMETIC DIAGRAM INCORPORATES SPECIAL FEATURES IMPORTANT FOR PROTECTION FROM X-RADIATION.
  • Page 22 HDMI EEPROM 5V_HDMI_1 +5V_Normal ENKMC2838-T112 D821 HDMI_1_RENESAS HDMI_1_ATMEL 5V_HDMI_1 5V_DET_HDMI_1 HDMI_1 IC801-*1 IC801 EDID_WP R1EX24002ASAS0A AT24C02BN-SH-T SHIELD Q802 R830 R896 HPD1 $0.055 2SC3052 C806 R884 R888 C802 0.1uF 2.7K 2.7K R804 0.1uF 1.8K DDC_SCL_1 R876 DDC_SDA_1 DDC_SDA_1 R875 DDC_SCL_1 5V_HDMI_2 +5V_Normal R824 HDMI_CEC...
  • Page 23 RGB/SPDIF/PC/HP New Item Development EARPHONE BLOCK HP_LOUT C1118 002:V7 10uF HEAD_PHONE C1115 1000pF R1125 JK3301 Q1101 +3.3V_Normal MMBT3904-(F) KJA-PH-0-0177 MMBT3904-(F) Q1104 +3.5V_ST R1155 DETECT HP_ROUT HP_DET C1119 10uF 002:V7 C1116 1000pF Q1102 R1128 MMBT3904-(F) MMBT3904-(F) Q1103 R1129 3.3K SIDE_HP_MUTE Q1106 2SC3052 RGB PC +5V_Normal...
  • Page 24 RS232C R1123 JP1121 R1124 +3.5V_ST JP1122 D1107 D1108 CDS3C30GTH CDS3C30GTH C1101 0.33uF SPG09-DB-009 IC1101 JK1101 C1106 MAX3232CDR 0.1uF C1102 0.1uF C1103 0.1uF DOUT1 RIN1 C1104 0.1uF ROUT1 S7_NEC_RXD DIN1 C1105 0.1uF DOUT2 DIN2 S7_NEC_TXD RIN2 ROUT2 EAN41348201 SYMBOL MARK OF THIS SCHEMETIC DIAGRAM INCORPORATES SPECIAL FEATURES IMPORTANT FOR PROTECTION FROM X-RADIATION.
  • Page 25 [51Pin LVDS Connector] (For FHD 60/120Hz) PANEL_VCC [30Pin LVDS Connector] [41Pin LVDS Connector] (For HD 60Hz_Normal) L702 (For FHD 120Hz) 120-ohm WAFER_FHD P705 P703 P704 FF10001-30 FI-RE51S-HF-J-R1500 FI-RE41S-HF-J-R1500 WAFER_FHD WAFER_FHD_120HZ C700 C709 C710 10uF 1000pF 0.1uF WAFER_FHD R713 PWM_DIM TP721 RXD4- TP722 OPC_OUT...
  • Page 26 VCC_1.5V_DDR VCC_1.5V_DDR VCC_1.5V_DDR VCC_1.5V_DDR VCC_1.5V_DDR DDR3 1.5V By CAP - Place these Caps near Memory VCC_1.5V_DDR DDR3 1.5V By CAP - Place these Caps near Memory A-MVREFDQ A-MVREFCA B-MVREFDQ B-MVREFCA Close to DDR Power Pin Close to DDR Power Pin CLose to Saturn7M IC CLose to DDR3 CLose to Saturn7M IC...
  • Page 27 +3.3V_Normal +3.3V_Normal S_FLASH_MAIN_MACRONIX IC1401 MX25L8006EM2I-12G +3.3V_Normal C1401 /SPI_CS 0.1uF SO/SIO1 HOLD# SPI_SDO SCLK /FLASH_WP SPI_SCK R1405 SI/SIO0 SPI_SDI R1401 Q1401 KRC103S S_FLASH_MAIN_WINBOND IC1401-*1 W25Q80BVSSIG DO[IO1] HOLD[IO3] %WP[IO2] DI[IO0] SYMBOL MARK OF THIS SCHEMETIC DIAGRAM INCORPORATES SPECIAL FEATURES IMPORTANT FOR PROTECTION FROM X-RADIATION. FILRE AND ELECTRICAL SHOCK HAZARDS, WHEN SERVICING IF IS GP2R 20101023...
  • Page 28 GP2R_LARGE_TUNER +5V_TU BOOSTER : CHINA OPT RF_SWITCH_CTL Pull-up can’t be applied L3701 BOOSTER_OPT because of MODEL_OPT_2 BLM18PG121SN1D BOOSTER_OPT BOOSTER_OPT R3734 R3743 close to TUNER Q3701 BOOSTER_OPT ISA1530AC1 R3737 R3762 2.2K CONTROL_ATTEN BOOSTER_OPT CN_2INPUT_H_LG3911 R3745 BOOSTER_OPT Q3702 FE_BOOSTER_CTL TU3701 2SC3052 LNA2_CTL TU3702 The pull-up/down of LNA2_CTL C3709...
  • Page 29 +1.8V_AMP +3.3V_Normal IC404 AP1117E18G-13 ADJ/GND Vd=1.4V 120 mA C434 C421 C446 0.1uF 0.1uF 10uF +24V SPK_L+ D501 1N4148W R519 R526 100V L506 R527 C536 R535 10.0uH 0.1uF 4.7K C529 390pF NRS6045T100MMGK SPEAKER_L C534 0.47uF 10.0uH C547 C521 C515 C519 0.01uF 10uF 0.1uF 0.1uF...
  • Page 30 Rear AV AV_CVBS_IN COMPONENT2 +3.3V_Normal REAR_AV C1643 C1648 D1619 47pF 220pF R1654 R1612 R1615 +3.3V_Normal REAR_AV REAR_AV COMP2_DET ETHERNET FOR DVB_T2 D1613 R1660 5.6V JK1604 REAR_AV PPJ233-01 AV_CVBS_DET [RD]E-LUG R1666 REAR_AV D1624 C1646 5.6V [GN]E-LUG [RD]O-SPRING 0.1uF R1619 REAR_AV [GN]O-SPRING [RD]CONTACT L-MONO COMP2_Y+...
  • Page 31 SIDE CVBS PHONE JACK (New Item Development) SIDE_CVBS L9903 BLM18PG121SN1D JK9901 KJA-PH-1-0177 SIDEAV_CVBS_IN SIDE_CVBS M5_GND +3.3V_Normal SIDE_CVBS C9907 R9907 [YL]E-LUG D9901 100pF SIDE_CVBS ADUC30S03010L_AMODIODE SIDE_CVBS [YL]O-SPRING R9915 R9911 M3_DETECT SIDEAV_DET [YL]CONTACT C9901 100pF D9902 SIDE_CVBS [WH]O-SPRING 5.6V ADMC5M03200L_AMODIODE [RD]CONTACT SIDE_CVBS SIDE_CVBS L9902 SIDE_AV_GENDER...
  • Page 32 * Option name of this page : CI_SLOT (because of Hong Kong) CI Region CI SLOT +5V_CI_ON CI TS INPUT CI_DATA[0-7] AR1905 FE_TS_DATA[7] +5V_Normal CI_MDI[7] FE_TS_DATA[6] C1906 CI_MDI[6] FE_TS_DATA[5] 10uF CI_MDI[5] FE_TS_DATA[4] CI_MDI[4] EAG41860102 CI_SLOT_JACK_LV3400 AR1906 P1901 FE_TS_DATA[3] P1902 CI_MDI[3] /CI_CD1 FE_TS_DATA[2] 10067972-000LF...
  • Page 33 6.5T_GAS 12.5T_GAS 9.5T_GAS 7.5T_GAS 8.5T_GAS 5.5T_GAS MDS62110206 MDS62110205 MDS62110209 MDS61887708 MDS61887710 MDS62110204 GAS1 GAS1-*2 GAS1-*5 GAS1-*4 GAS1-*3 GAS1-*1 7.5T_GAS 9.5T_GAS 5.5T_GAS 6.5T_GAS 12.5T_GAS 8.5T_GAS MDS62110205 MDS62110204 MDS61887710 MDS62110209 MDS61887708 MDS62110206 GAS2-*2 GAS2-*1 GAS2-*3 GAS2-*5 GAS2-*4 GAS2 9.5T_GAS 7.5T_GAS 8.5T_GAS 12.5T_GAS 5.5T_GAS MDS62110209 MDS61887710...
  • Page 34 +3.3V_Normal L/DIM_LED/DRIVER +3.3V_Normal P2100 12507WR-08L R2102 R2103 FRC_L/DIM_REVERSE_SEL L/DIM_SCLK LED_DRIVER_D/L L/DIM_MOSI R4029 LED_DRIVER_D/L_SCL R4028 LED_DRIVER_D/L_SDA LED_DRIVER_D/L V_SYNC C2100 C2101 C2102 C2103 C2104 18pF 18pF 18pF 18pF 18pF SYMBOL MARK OF THIS SCHEMETIC DIAGRAM INCORPORATES SPECIAL FEATURES IMPORTANT FOR PROTECTION FROM X-RADIATION. GP2R 20101023 FILRE AND ELECTRICAL SHOCK HAZARDS, WHEN SERVICING IF IS...
  • Page 35 TI solution RF-3D OPTION +3.3V_Normal +3.3V_Normal P3401 12507WR-12L L3401 3D_SG 120-ohm 3D_SG 3.3V R3410 R3411 R3412 3D_SG R3402 2.7K 2.7K 2.7K M_REMOTE_RX 3D_SG 3D_SG 3D_SG 3D_SG R3408 M_REMOTE_TX 3D_SG R3409 RESET M_RFModule_RESET 3D_SG FREQ. GPOIO_0 GPOIO_1 GPOIO_2 R3407 DC_MREMOTE 3D_SG 3D Off R3401 DD_MREMOTE...
