WASHING MACHINE
SERVICE MANUAL
CAUTION
Before servicing the washer, Read the safety precautions in the manual.
MODEL
:WF-HXB110FS /01

Advertisement

Table of Contents
loading

Related Manuals for LG WF-HXB110FS/01

Summary of Contents for LG WF-HXB110FS/01

  • Page 1 WASHING MACHINE SERVICE MANUAL CAUTION Before servicing the washer, Read the safety precautions in the manual. MODEL :WF-HXB110FS /01...

  • Page 2: Table Of Contents

    SAFETY PRECAUTION! ■ DISASSEMBLE POWER CORD BEFORE SERVING ■ RECONNECT ALL GROUNDING DEVICES IMPORTANT SAFETY NOTICE! This service information is intended for individuals possessing adequate backgrounds of electrical, electronic and mechanical experience. Any attempt to repair this appliance may result in personal injury or property damage.

  • Page 3: Specifications

    1. SPECIFICATIONS POWER SOURSE Refer to rating label on the back of Washer INPUT Refer to rating label on the back of Washer CAPACITY Refer to rating label on the back of Washer INNER TUB Stainless INLET WATER 0.3kgf/cm ~ 8.0kgf/cm PRESSURE SPIN SPEED 950 rpm...

  • Page 4: Installation Instructions

    2. INSTALLATION INSTRUCTIONS 2-1. HOW TO ADJUST LEVEL Installation area • Install the washer on flat and firm surface. Checking level • Open the lid, and check if the washer is correctly leveled by looking down from the top. Adjustable leg Turn the adjustable legs to set the washer horizontal (2 EA).
  • Page 5 Checking slope Confirming level • • Place the washer to original position If installation surface is tilted, the washer will be shaken. and confirm the level. Horizontal setting Distance between drain hose and the wall • • Lift up the front of the washer and Distance between drain hose and the wall should adjust level by turning the be more than 10 cm, and the distance between the...
  • Page 6 2-2. CONNECTING WATER SUPPLY HOSE Before connecting Water Supply Hose to water tap, check your hose type and choose correct instruction. Water Supply Hose may vary according to the country. Make sure connect blue inlet hose to COLD water tab, and orange inlet hose to HOT water tab. Connecting Water Supply Hose to water tap Normal Type (Normal tab without thread &...
  • Page 7 (NORMAL TAB WITHOUY THREAD & ONE TOUCH TYPE INLET HOSE.) One Touch Type Separate Middle connector from Water Supply Hose Separate Middle connector from the Water Conector Middle connector Etiqueta Fixed Stiicker Fija Supply Hose by pulling the Pressing Rod and Medio Manija de Presión Pressing Handle...
  • Page 8 Screw Type Attach the water supply hose to the tap. Push the water supply hose up so that the rubber packing within the hose can adhere completely Water to the tap. Water Supply Hose Rubber Packing Connect the water supply hose to the tap. Connect the water supply hose to the tap and then tighten it by screwing it to the right.
  • Page 9 2-3. CONNECT THE DRAIN HOSE ▒ For pump model • Check that the drain hose is • • Connect the drain hose to Attach the clip to the drain hung up over the edge of the the outlet of the drain pump hose.

  • Page 10: Operating Instructions

    3. OPERATING INSTRUCTION 3-1. IDENTIFICATION OF PARTS * WATER POWDER DETERGENT BOX SUPPLY HOSE FOR DELAYED WASHING / Make sure the SOFTENER BOX water does not leak. * POWER PLUG If the supply cord is damaged, it must be BLEACH replaced by the DISPENSER( manufacturer or its...

  • Page 11: Before Starting To Wash

    Use nylon nets for long, DELICATE items. For laundry with long strings or long length , a net will prevent tangling during washing. Fasten zippers, hook, and strings to make sure that these items don't snag on other clothes. ※ Nylon net is not supplied by LG.
  • Page 12 Using Water Amount of WATER LEVEL This machine detects the quantity of laundry automatically, then sets the WATER LEVEL and displays the amount of detergent to be used. When you select a wash program, the WATER LEVEL and amount of Detergent (to be used) will be shown on the control panel.
  • Page 13 Using Detergent Detergent Follow the Detergent package directions. Using too little Detergent is a common cause of laundry problems as is if too much detergent is used. Only more Detergent if you have hard water, large loads, greasy or oily soils or lower Water Temperature. Choosing the right Detergent We recommend the use of drum type, low sudsing high efficiency Detergent(powder,liquid or concentrated).
  • Page 14 Using Liquid Bleach • Check clothing care label for special instructions and separate the laundry to be bleached • Dilute liquid chlorine bleach. • Measure the recommended amount of liquid bleach carefully following instructions on the bottle. • Before starting the washer, pour measured amount of bleach directly into bleach dispenser.
  • Page 15 ☞ SPECIAL GUIDE FOR STAIN REMOVAL WARNING ■ Do not use or mix liquid chlorine bleach with other household chemicals such as toilet cleaners, rust removers, acid or products containing ammonia. These mixtures can produce dangerous fumes which can cause serious injury or death. ■...

  • Page 18: Washing Programs

    3-4. WASHING PROGRAMS...

  • Page 22: Other Functions

    3-5. Other Functions...
  • Page 26 * Air Dry...
  • Page 29 for 3 seconds to select Child Lock. * Child Lock for 3 seconds...
  • Page 30 3-6. CLEANING AND MAINTENANCE When there is a possibility of freezing ambient temperatures. • Close the water taps and remove the Water Supply Hose. • Remove the water which remains in the water supply. • Lower the drain hose and drain the water in the bowl and the drain hose by spinning. If frozen •...

  • Page 31: Wiring Diagram

    BASE/LINE WIRING DIAGRAM MAIN CONTROLLER CN10 4 2 3 1 1 4 5 3 6 2 1 2 3 1 2 3 4 5 6 7 1 2 3 4 5 6 7 8 9 10 BN YL BK GY PL OR BL RD BL RD OR YL GN BL WH GY...

  • Page 32: Disassembly Instruction

    4-2. DISASSEMBLY INSTRUCTION ▶ Be sure to unplug the power to repair and replace electric parts. CAUTION FOR ELECTROSTATICS Be sure to make earth connection for trouble diagnosis and parts replacement. If impossible, touch earth wire on the body to remove electric deviation between the body and product before work.
  • Page 33 2) Disassembly of Back Panel, Power Cord, Inlet Valve & BP Sensor ① Remove two back panel fixing screws in the back side. ② Disassemble the back panel. ③ Disconnect two connectors and disassemble the power cord. ④ Remove a valve fixing screw & disconnect the leads form the inlet valve.
  • Page 34 3) Disassembly of Back cover, Drain Pump. ① Remove back cover fixing screws then disassemble the back cover. ② Disconnect the leads and the drain hose-p from the drain pump. ③ Remove the pump fixing screws and the connector hose disassemble the drain pump. 4) Replacement of Damper asm ①...
  • Page 35 6) Replacement of Rotor & Stator ① Disassemble rotor nut with boxer(M18) or spaner. (※ In assembled, the force is over than 200kgf. ② Disassemble rotor, pull out the rotor as shown Fixing Bolt ③ water guide. Water Guide ④ Before disassemble stator,disconnect the Stator Housing stator housing.
  • Page 36 ⑤ SNAP RING. (Lower upper position screws) ⑥ Check the direction of SNAP RING. (The handle of snap ring is toward to rotor and stator.) ⑦ Preventing fallen the stator, tighten with one hand and then loosen the last screw. ⑧...
  • Page 37 4-3. How to use Test Mode 1. Cautions during the service ■ Both AC220V and DC power are embedded in the controller assembly output connector, so be careful of the electric shock during the disorder diagnosis.(Wear cotton gloves during the work.) ■...
  • Page 38 4-4. TROUBLESHOOTING BY COMMON WASHING PROBLEMS Many washing problems involve poor soil and stain removal, residues of lint and scum, and fabric damage. For satisfactory washing results, follow these instructions. Use ONLY powdered or liquid HE (High Effificiency) detergents. Do NOT use flakes scraped from a soap cake or bar, flakes, soap ribbons (available in some markets,) detergent tablets, plastic pouches, magic laundry balls, or anything other than powdered or liquid HE detergent products.

  • Page 39: Troubleshooting With Error Code

    4-5. TROUBLESHOOTING WITH ERROR CODE Problem Diagnosis Estimated Cause of Display Action Standard Abnormal Condition • When it did not reach the • Open the faucet for water Water supply problem 1. When the faucet is locked or RESET level frequency frozen supply •...
  • Page 40 Problem Diagnosis Estimated Cause of Display Action Standard Abnormal Condition • When the door cannot be • Remove the foreign object Lid open 1. When there is a foreign object locked in the lid lock hole in the lid lock hole •...
  • Page 41 Problem Diagnosis Estimated Cause of Display Action Standard Abnormal Condition Coin stuck Occurs when motor is 1. When foreign object such as Remove the coin or foreign locked coin, pin, or clip entered the object stuck between the washing plate washer vane with pliers, etc.

  • Page 42: How To Diagnose And Repair By Symptom

    4-6. HOW TO DIAGNOSE AND REPAIR BY SYMPTOM 1) Washer is not energized. How to repair & settle Where, what & how to check? Possible Cause Result of Check Household Power supply Poor Defect of the electrical Change the electrical. 1.
  • Page 43 2) Defects on displaying funcion How to repair & settle Where, what & how to check? Possible Cause Result of Check Main voltage Less than 85% of the Low voltage To explain that it is 1. Measure mains voltage at the wall outlet rating caused by low voltage in electric supply and...
  • Page 44 4) Water doesn’t come into the wash tub. How to repair & settle Where, what & how to check? Possible Cause Result of Check Inlet Valve 1. If water doesnʼt come though the inlet valve works(electric sound occurs) 1) Check whether water mains is cut. Water mains cut.
  • Page 45 5) Water fills continuously of intermittently How to repair & settle Where, what & how to check? Result of Check Possible Cause Wrong Installation/Leakage 1. Check whether the drain hose is laying Drain hose laying Wrong installation. The drain hose should be down on the floor.
  • Page 46 6) Display "LE" message and doesn't work How to repair & s ett le Where, what & how to check? Poss ible Cause Re sult of Check 1. In initial state display “ LE ” mess age. Motor coil is open. Change the motor 1) Check resistance of the motor.
  • Page 47 7) Water does not drain. How to repair & settle Where, what & how to check? Possible Cause Result of Check Drain Pump/Drain Valve 1. Check whether there is drain pump/ There is pump/valve Drain pump/drain valve Disassemble the drain pump/ is blocked by drain valve cap and remove drain valve working sound.
  • Page 48 8) Water drains thought it is not the time of drain. How to repair & settle Where, what & how to check? Possible Cause Result of Check Drain Hose 1. Check whether the drain hose is The discharge height Wrong installation of the Put the outlet of drain hose installed properly so that the discharge is lower than...
  • Page 49 11) Vibration, Noise or Unbalance Error happens during spin. How to repair & settle Where, what & how to check? Possible Cause Result of Check Using conditions such as installation etc. 1. Check whether the washer is leveled. Not leveled. Defect of installation Level the washer.
  • Page 50 12) Power is automatically turned off during operation or immediately turning on the power button. How to repair & settle Where, what & how to check? Possible Cause Result of Check Auto Power Relay or Controller 1. Check whether power is automatically Automatically tumed Mechanical defect of the Change the switch.

  • Page 51: Exploded View

    5. EXPLODED VIEW TOP COVER ASSEMBLY TUB ASSEMBLY CABINET ASSEMBLY...
  • Page 52 5-1. THE EXPLODED VIEW OF TOP COVER ASSEMB A020 A030 A040 A010 A052 A065 A240 A200 A062 A061 A190 A060 A163 A165 A152 A150 A101 A230 A163 A100 A101 A171 A170 A180 A270 A140...
  • Page 53 5-2. THE EXPLODED VIEW OF OUT CASE ASSEMBLY F004 F005 F002 F070 F001 F003 F000 F040 F020 F023 F024 F090 F023 For Non-Pump...
  • Page 54 K005 K004 K000 K012 K021 K020 K040 K050 K061 K060 K110 NATURAL K100 K250 K064 K140 K345 K340 K270 K240 - For Non pump type K200 K290 K210 K201 K305 K300 K430...
  • Page 55 Mar. 2014 PRINTED IN CHINA P/No.:MFL40322192...
