- Page 1 C SERIES VIDEO PROCESSOR USER MANUAL Copyright © 2022 Starview International Private Limited. All rights reserved. Singapore Headquarters: 60 Kaki Bukit Place, #05-19 Eunos Techpark, Singapore 415979 Website: www.starviewint.com | Email: sales@starviewint.com | Tell: +65 31575338...
-
Page 2: Table Of Contents
6.5.8 Other Settings ..............................58 6.5.9 Help.................................59 6.5.10 About Us ...............................60 Website: www.starviewint.com | Email: sales@starviewint.com | Tell: +65 31575338 Copyright © 2022 Starview International Private Limited. All rights reserved. Singapore Headquarters: 60 Kaki Bukit Place, #05-19 Eunos Techpark, Singapore 415979... -
Page 3: Device Connections
1. DEVICE CONECTIONS 1.1 Input Cards The C series supports a variety of input sources. Connect the input sources to the matched input card connectors. DVI, HDMI, SDI, CVBS, VGA or DP input sources Connect the input sources to the matched input card connectors using corresponding cables or converter cables. -
Page 4: Power Supply
Connect the power connector on the rear panel to the electrical outlet using the supplied power cord. 1.4 Control Card You can control the C series devices on a control PC through either of the following two methods. Method I: Direct control for single-user control Connect the device Ethernet port to the control PC. -
Page 5: Preview Card
DEVICE CONECTIONS 1.5 Preview Card The C series allows you to monitor the inputs and outputs on a PC or monitor. Figure 1-4 Preview card connection Via Ethernet port: Connect one of the Ethernet ports on the preview card and the Ethernet port of the control card to the same switch for the input source and screen monitoring on the Web page. -
Page 6: Device Login
You have obtained the login user name and password. The default user name and password are "admin". Notes When an C series device is connected directly to a control PC, the device and control PC must be on the same network segment and their IP addresses cannot conflict. For example, if the device IP address is 192.168.0.10, the IP address of the control PC must be 192.168.0.X and X cannot be... - Page 7 DEVICE LOGIN When an C series device is connected to a control PC using a router or switch, you must set to automatically get the IP address, and select Obtain an IP address automatically for the network settings on the control PC.
-
Page 8: Screen Configuration
H_16xRJ45+2xfiber sending card or H_20xRJ45 sending card. Website: www.starviewint.com | Email: sales@starviewint.com | Tell: +65 31575338 Copyright © 2022 Starview International Private Limited. All rights reserved. Singapore Headquarters: 60 Kaki Bukit Place, #05-19 Eunos Techpark, Singapore 415979... - Page 9 Step 3 Select a communication port and click Next . Website: www.starviewint.com | Email: sales@starviewint.com | Tell: +65 31575338 Copyright © 2022 Starview International Private Limited. All rights reserved. Singapore Headquarters: 60 Kaki Bukit Place, #05-19 Eunos Techpark, Singapore 415979...
- Page 10 For configuration for irregular screens, please refer to the Starview Software User Manual. For configuration for common and irregular screens, you can also use Starview Software from Starview. For detailed information, please refer to the Starview Software User Manual.
-
Page 11: Basic Operations
: Bring the selected layer to the front, and the layer image will be displayed completely. Website: www.starviewint.com | Email: sales@starviewint.com | Tell: +65 31575338 Copyright © 2022 Starview International Private Limited. All rights reserved. Singapore Headquarters: 60 Kaki Bukit Place, #05-19 Eunos Techpark, Singapore 415979... - Page 12 Live (default): The layer editing process is displayed on the screen in real time. Figure 4-3 Live more Website: www.starviewint.com | Email: sales@starviewint.com | Tell: +65 31575338 Copyright © 2022 Starview International Private Limited. All rights reserved. Singapore Headquarters: 60 Kaki Bukit Place, #05-19 Eunos Techpark, Singapore 415979...
-
Page 13: Adding Bkg
Step 1 On the Programming page, click BKG below the screen list area to expand the BKG settings pane. Website: www.starviewint.com | Email: sales@starviewint.com | Tell: +65 31575338 Copyright © 2022 Starview International Private Limited. All rights reserved. Singapore Headquarters: 60 Kaki Bukit Place, #05-19 Eunos Techpark, Singapore 415979... -
Page 14: Adding Osd
Click another image in the BKG list to replace the current BKG. 4.3 Adding OSD The C series supports both OSD text and OSD image settings. OSD text supports scrolling. On the Programming page, click OSD below the screen list area to expand the OSD settings pane. - Page 15 Click the up or down arrow button next to the text box. Enter an opacity value in the text box. Website: www.starviewint.com | Email: sales@starviewint.com | Tell: +65 31575338 Copyright © 2022 Starview International Private Limited. All rights reserved. Singapore Headquarters: 60 Kaki Bukit Place, #05-19 Eunos Techpark, Singapore 415979...
- Page 16 On the Web page, you can click and drag the OSD to quickly adjust its position. Website: www.starviewint.com | Email: sales@starviewint.com | Tell: +65 31575338 Copyright © 2022 Starview International Private Limited. All rights reserved. Singapore Headquarters: 60 Kaki Bukit Place, #05-19 Eunos Techpark, Singapore 415979...
-
Page 17: Setting Presets
Step 2 Click Preset on the left to expand the preset list. Figure 4-11 Loading presets Website: www.starviewint.com | Email: sales@starviewint.com | Tell: +65 31575338 Copyright © 2022 Starview International Private Limited. All rights reserved. Singapore Headquarters: 60 Kaki Bukit Place, #05-19 Eunos Techpark, Singapore 415979... -
Page 18: Setting Preset Playbacks
Step 1 On the Programming page, click Preset Playback on the left to enter the playback settings page. Figure 4-13 Adding preset playbacks - 1 Website: www.starviewint.com | Email: sales@starviewint.com | Tell: +65 31575338 Copyright © 2022 Starview International Private Limited. All rights reserved. Singapore Headquarters: 60 Kaki Bukit Place, #05-19 Eunos Techpark, Singapore 415979... - Page 19 The screen is locked during the playback. Website: www.starviewint.com | Email: sales@starviewint.com | Tell: +65 31575338 Copyright © 2022 Starview International Private Limited. All rights reserved. Singapore Headquarters: 60 Kaki Bukit Place, #05-19 Eunos Techpark, Singapore 415979...
-
Page 20: Grouping Input Sources
Step 2 Click Group to pop up the grouping window. Website: www.starviewint.com | Email: sales@starviewint.com | Tell: +65 31575338 Copyright © 2022 Starview International Private Limited. All rights reserved. Singapore Headquarters: 60 Kaki Bukit Place, #05-19 Eunos Techpark, Singapore 415979... -
Page 21: Cropping Input Sources
Step 6 Click OK to complete the grouping. 4.7 Cropping Input Sources The C series supports the input source cropping function. The cropped input source can be used as a new input source. Step 1 On the Programming page, click Input Signal on the left to view the input source list. The green connectors are accessed with signal sources. - Page 22 Figure 4-20 Cropped input source Website: www.starviewint.com | Email: sales@starviewint.com | Tell: +65 31575338 Copyright © 2022 Starview International Private Limited. All rights reserved. Singapore Headquarters: 60 Kaki Bukit Place, #05-19 Eunos Techpark, Singapore 415979...
-
Page 23: Setting 3D Effect
BASIC OPERATIONS 4.8 Setting 3D Effect The C series can work with the EMT200 3D emitter from NovaStar and 3D glasses to provide you with 3D visual experience. You can set the 3D parameters in NovaLCT or on the Web. - Page 24 Step 5 Check the box next to 3D to turn on the 3D function. Website: www.starviewint.com | Email: sales@starviewint.com | Tell: +65 31575338 Copyright © 2022 Starview International Private Limited. All rights reserved. Singapore Headquarters: 60 Kaki Bukit Place, #05-19 Eunos Techpark, Singapore 415979...
-
Page 25: Setting Channel Logos
Step 1 Select an input source and “…” appears next to the input source name. Website: www.starviewint.com | Email: sales@starviewint.com | Tell: +65 31575338 Copyright © 2022 Starview International Private Limited. All rights reserved. Singapore Headquarters: 60 Kaki Bukit Place, #05-19 Eunos Techpark, Singapore 415979... - Page 26 Step 3 Select Set Logo to pop up the channel logo settings window. Figure 4-26 Setting logo Step 4 Enable the logo function. The C series supports text or image channel logos. Text logo Enter the logo text in the Content text box.
-
Page 27: Setting Input And Output Edid
EDID settings adopt this method. The parameters for advanced EDID settings are shown as follows. Website: www.starviewint.com | Email: sales@starviewint.com | Tell: +65 31575338 Copyright © 2022 Starview International Private Limited. All rights reserved. Singapore Headquarters: 60 Kaki Bukit Place, #05-19 Eunos Techpark, Singapore 415979... -
Page 28: Managing Users
Step 2 Click Add to pop up the new user adding window. Website: www.starviewint.com | Email: sales@starviewint.com | Tell: +65 31575338 Copyright © 2022 Starview International Private Limited. All rights reserved. Singapore Headquarters: 60 Kaki Bukit Place, #05-19 Eunos Techpark, Singapore 415979... - Page 29 Step 2 Click Change Password in the column of Management to change the user password. Figure 4-31 Changing password Website: www.starviewint.com | Email: sales@starviewint.com | Tell: +65 31575338 Copyright © 2022 Starview International Private Limited. All rights reserved. Singapore Headquarters: 60 Kaki Bukit Place, #05-19 Eunos Techpark, Singapore 415979...
- Page 30 Step 4 Grant permissions to the user. Step 5 Click OK to update the user information. Website: www.starviewint.com | Email: sales@starviewint.com | Tell: +65 31575338 Copyright © 2022 Starview International Private Limited. All rights reserved. Singapore Headquarters: 60 Kaki Bukit Place, #05-19 Eunos Techpark, Singapore 415979...
-
Page 31: Lcd Menu Introduction
Below the connector area, the device temperature, fan and power statuses are displayed. 5.2 Multiviewer View the input and screen monitoring information. Website: www.starviewint.com | Email: sales@starviewint.com | Tell: +65 31575338 Copyright © 2022 Starview International Private Limited. All rights reserved. Singapore Headquarters: 60 Kaki Bukit Place, #05-19 Eunos Techpark, Singapore 415979... -
Page 32: Settings
IP address, subnet mask and gateway. Website: www.starviewint.com | Email: sales@starviewint.com | Tell: +65 31575338 Copyright © 2022 Starview International Private Limited. All rights reserved. Singapore Headquarters: 60 Kaki Bukit Place, #05-19 Eunos Techpark, Singapore 415979... -
Page 33: Firmware Version
Figure 5-6 Serial port settings 5.3.2 Firmware Version View the versions of all cards. Website: www.starviewint.com | Email: sales@starviewint.com | Tell: +65 31575338 Copyright © 2022 Starview International Private Limited. All rights reserved. Singapore Headquarters: 60 Kaki Bukit Place, #05-19 Eunos Techpark, Singapore 415979... -
Page 34: Advanced Settings
Clear the data stored in the device, and reset the device settings to factory defaults. Website: www.starviewint.com | Email: sales@starviewint.com | Tell: +65 31575338 Copyright © 2022 Starview International Private Limited. All rights reserved. Singapore Headquarters: 60 Kaki Bukit Place, #05-19 Eunos Techpark, Singapore 415979... - Page 35 Web page after the device is restarted. Select the desired language and click OK to complete the language settings. Figure 5-10 LCD screen Figure 5-11 Web page Website: www.starviewint.com | Email: sales@starviewint.com | Tell: +65 31575338 Copyright © 2022 Starview International Private Limited. All rights reserved. Singapore Headquarters: 60 Kaki Bukit Place, #05-19 Eunos Techpark, Singapore 415979...
- Page 36 Step 3 When the message “Updated successfully” appears, click Close to restart the system. USB Import and Export The C series supports importing and exporting the device data using a USB drive, which will greatly facilitate the new device configuration in the future.
-
Page 37: Language
Load from USB: Import the data from a USB drive. Backup to USB: Export the device data to a USB drive for backup. 5.4 Language Change the UI language. The C series currently supports English and Simplified Chinese. Figure 5-15 Changing language Notes: Switching the device front panel UI language will simultaneously switch the Web page UI language. - Page 38 LCD MENU INTRODUCTION Figure 5-16 About us Website: www.starviewint.com | Email: sales@starviewint.com | Tell: +65 31575338 Copyright © 2022 Starview International Private Limited. All rights reserved. Singapore Headquarters: 60 Kaki Bukit Place, #05-19 Eunos Techpark, Singapore 415979...
-
Page 39: Web Introduction
When the LED 4K sending card is used, to use the output locating function, you must enable the mapping function in Starview Software and use the receiving cards that support the mapping function. Website: www.starviewint.com | Email: sales@starviewint.com | Tell: +65 31575338 Copyright ©... - Page 40 WEB INTRODUCTION Note: For related receiving card information, please visit Starview official website or contact our technical support staff. Screen Configuration Parameters On the screen configuration page, click at the right edge to expand the screen parameter settings pane. Figure 6-3 Screen configuration parameters...
- Page 41 (redder) the image is. The higher the temperature, the colder (bluer) the image is. Website: www.starviewint.com | Email: sales@starviewint.com | Tell: +65 31575338 Copyright © 2022 Starview International Private Limited. All rights reserved. Singapore Headquarters: 60 Kaki Bukit Place, #05-19 Eunos Techpark, Singapore 415979...
- Page 42 Device page. Rate Website: www.starviewint.com | Email: sales@starviewint.com | Tell: +65 31575338 Copyright © 2022 Starview International Private Limited. All rights reserved. Singapore Headquarters: 60 Kaki Bukit Place, #05-19 Eunos Techpark, Singapore 415979...
-
Page 43: Programming
BKG, cropping the input source, setting the preset and preset playback. Website: www.starviewint.com | Email: sales@starviewint.com | Tell: +65 31575338 Copyright © 2022 Starview International Private Limited. All rights reserved. Singapore Headquarters: 60 Kaki Bukit Place, #05-19 Eunos Techpark, Singapore 415979... -
Page 44: Multiviewer
Multiviewer on the LCD screen on the device front panel to view the monitoring information. Website: www.starviewint.com | Email: sales@starviewint.com | Tell: +65 31575338 Copyright © 2022 Starview International Private Limited. All rights reserved. Singapore Headquarters: 60 Kaki Bukit Place, #05-19 Eunos Techpark, Singapore 415979... - Page 45 MVR property settings pane. Figure 6-7 MVR property settings Website: www.starviewint.com | Email: sales@starviewint.com | Tell: +65 31575338 Copyright © 2022 Starview International Private Limited. All rights reserved. Singapore Headquarters: 60 Kaki Bukit Place, #05-19 Eunos Techpark, Singapore 415979...
-
Page 46: Device
Website: www.starviewint.com | Email: sales@starviewint.com | Tell: +65 31575338 Copyright © 2022 Starview International Private Limited. All rights reserved. Singapore Headquarters: 60 Kaki Bukit Place, #05-19 Eunos Techpark, Singapore 415979... - Page 47 IP address, subnet mask and other information for each Ethernet port independently. Website: www.starviewint.com | Email: sales@starviewint.com | Tell: +65 31575338 Copyright © 2022 Starview International Private Limited. All rights reserved. Singapore Headquarters: 60 Kaki Bukit Place, #05-19 Eunos Techpark, Singapore 415979...
-
Page 48: Settings
Under custom mode, you can select Advanced to enable the advanced EDID settings function. The parameters for advanced settings are shown as follows. Website: www.starviewint.com | Email: sales@starviewint.com | Tell: +65 31575338 Copyright © 2022 Starview International Private Limited. All rights reserved. Singapore Headquarters: 60 Kaki Bukit Place, #05-19 Eunos Techpark, Singapore 415979... -
Page 49: Ipc Management
On the Settings page, click IPC Management on the left to enter the IPC management page. Figure 6-12 IPC management Website: www.starviewint.com | Email: sales@starviewint.com | Tell: +65 31575338 Copyright © 2022 Starview International Private Limited. All rights reserved. Singapore Headquarters: 60 Kaki Bukit Place, #05-19 Eunos Techpark, Singapore 415979... - Page 50 IP settings of the device in advance, and then fill the related parameters accordingly on the Web page. Website: www.starviewint.com | Email: sales@starviewint.com | Tell: +65 31575338 Copyright © 2022 Starview International Private Limited. All rights reserved. Singapore Headquarters: 60 Kaki Bukit Place, #05-19 Eunos Techpark, Singapore 415979...
- Page 51 When you select Add Multiple, the ports of IP addresses must be the same. Website: www.starviewint.com | Email: sales@starviewint.com | Tell: +65 31575338 Copyright © 2022 Starview International Private Limited. All rights reserved. Singapore Headquarters: 60 Kaki Bukit Place, #05-19 Eunos Techpark, Singapore 415979...
- Page 52 After the video sources are added successfully, the cameras and their IP address will be listed on the left. Website: www.starviewint.com | Email: sales@starviewint.com | Tell: +65 31575338 Copyright © 2022 Starview International Private Limited. All rights reserved. Singapore Headquarters: 60 Kaki Bukit Place, #05-19 Eunos Techpark, Singapore 415979...
- Page 53 Click and drag a source on the left to the input source template. Website: www.starviewint.com | Email: sales@starviewint.com | Tell: +65 31575338 Copyright © 2022 Starview International Private Limited. All rights reserved. Singapore Headquarters: 60 Kaki Bukit Place, #05-19 Eunos Techpark, Singapore 415979...
- Page 54 Select the desired signal sources by checking the boxes in front of them. Website: www.starviewint.com | Email: sales@starviewint.com | Tell: +65 31575338 Copyright © 2022 Starview International Private Limited. All rights reserved. Singapore Headquarters: 60 Kaki Bukit Place, #05-19 Eunos Techpark, Singapore 415979...
-
Page 55: User Management
Website: www.starviewint.com | Email: sales@starviewint.com | Tell: +65 31575338 Copyright © 2022 Starview International Private Limited. All rights reserved. Singapore Headquarters: 60 Kaki Bukit Place, #05-19 Eunos Techpark, Singapore 415979... -
Page 56: Communication Settings
Set the serial port related parameters for a better connection with the central control device and device control through the central control device. Website: www.starviewint.com | Email: sales@starviewint.com | Tell: +65 31575338 Copyright © 2022 Starview International Private Limited. All rights reserved. Singapore Headquarters: 60 Kaki Bukit Place, #05-19 Eunos Techpark, Singapore 415979... -
Page 57: Firmware Update
WEB INTRODUCTION 6.5.6 Firmware Update The C series supports firmware update through the Web page. Make sure you have downloaded the update package from Starview official website before the update. The system supports the update for the control card, AUX and MVR cards, input cards and output cards. You can select to update a single component or the whole unit. -
Page 58: Other Settings
On this page, you can set the performance, Genlock and preset transition. Website: www.starviewint.com | Email: sales@starviewint.com | Tell: +65 31575338 Copyright © 2022 Starview International Private Limited. All rights reserved. Singapore Headquarters: 60 Kaki Bukit Place, #05-19 Eunos Techpark, Singapore 415979... -
Page 59: Help
When Fade is selected, the transition duration can be set. Device Backup The C series devices support both the backup between the devices of the same model and the backup between two LED 4K sending cards on the same device. You must set the backup in Starview Software by referring Starview Software User Manual. -
Page 60: About Us
Tel: +420 602 66 75 66 For the most current specification information, please visit http://www.starviewint.com Copyright 2022 STARVIEW INTERNATIONAL PTE LTD. All rights reserved. All brand names and product names are trademarks, registered trademarks or tradenames of their respective holders. STARVIEW INTERNATIONAL PTE LTD management system is registered to ISO 9001 and ISO 45001.
