- Page 1 HORIZONTAL DIAPER CHANGING STATION ALP411-E USER GUIDE...
- Page 2 THANK YOU FOR YOUR PURCHASE. Known in the industry for excellent products, Alpine Industries is a manufacturer of innovative, solution-based products for the commercial and institutional markets worldwide. Combining commitment to the customer, design innovation and skilled, dedicated workforces, they have produced a range of products that are an essential part of every commercial facility.
-
Page 3: Table Of Contents
Table of Contents Parts Included Hardware Bag Installation Instructions Operation Instructions 10 Maintenance and Cleaning Limited Warranty 12 Disclaimer... -
Page 4: Parts Included
Parts Included CHANGING STATION DOOR/WALL PLATE Tools Required (Not Included) Adult Installation Required • Level • Measuring Tape • Power Drill with 7/32”, 1/8” and ½” masonry bits. • Power screwdriver with bull nose Philips bit. CAUTION: • Read all instructions before assembly of Diaper Changing Station. •... - Page 5 Hardware 3” WOOD SCREWS (4) 3/4” FLAT WASHERS (4) 3/4” FINISHING WASHERS (4) TOGGLE ANCHORS (2) 3” MACHINE SCREWS (2) 1 ¼” CAPS (4)
-
Page 6: Installation Instructions
Installation Instructions WARNING: • One wall stud MUST be located and USED for at least one side of the diaper changing station. • The diaper changing station CANNOT be heavier than the anchors or walls they are attached to. • It MUST be firmly secured to support the additional weight of a child. •... - Page 7 Installation Instructions FIGURE A WOODEN WALL WALL STUD...
- Page 8 Installation Instructions NOTE 2: FOR USE WITH TOGGLE ANCHORS (E): • If the finished wall surface has wood studs that are not 16” on center, has metal studs, or has an underlying surface of concrete block, use ½” bit. • Use Machine Screws (C) and Flat Washers (D) (See Figure B on page 6). •...
- Page 9 Installation Instructions FIGURE B WALL WOODEN WALL STUD...
- Page 10 Installation Instructions USING TOGGLE ANCHORS: 1. Insert the metal end of the Toggle Anchor (E) into the 1/2’’ hole. 2. Slide zip strip down snugly against the wall. 3. Snap off break-away pieces of Toggle Anchor (E) (See Figure C below). 4.
- Page 11 Installation Instructions RECOMMENDED BLOCKING 1. If the walls do not have studs on center, additional blocking is necessary (See Figure D below). 2. Contact an architect or building contractor to make sure the blocking is adequate and complies with building codes. FIGURE D 7.2 in.
-
Page 12: Operation Instructions
Operation Instructions 1. Rotate base downward and place the infant on top of the changing surface. 2. Use restraint system as described below. After the child has been changed, remove the restraint system, and rotate the base back up against the wall. USING THE RESTRAINT SYSTEM: 1. -
Page 13: Maintenance And Cleaning
Maintenance and Cleaning 1. Clean by using a damp cloth with mild soap or mild multi-purpose cleaner. 2. Do not use any strong chemical cleaners or cleaning agents that may be hazardous to children. 3. Check all hardware and components monthly or as required to ensure the hardware is tight and there are no missing or damaged pieces. -
Page 14: Limited Warranty
Limited Warranty 1. Alpine Industries (the company) warrants to the purchaser that the product will be free from de- fects in workmanship and materials for a period of one (1) year from the date of purchase. 2. These warranties are not assignable or transferable to any other person. -
Page 15: Disclaimer
ANY REMEDY FAILS ITS ESSENTIAL PURPOSE. If any provision of this Agreement is declared invalid or unenforceable, the remaining provisions of this Agreement will remain in effect. Alpine Industries has the right to modify these terms and conditions at any time. - Page 16 ALP411-E 27 Selvage Street • Irvington, NJ • 07111 • © 2021 Alpine Industries. alpineindustries.com...
