Summary of Contents for IKONIX 40417
- Page 1 40417 INSTRUCTION SHEET Signal Tower Light 24V Installation V 1.00 | 7.2021 | p/n 40421...
- Page 2 40417 Instruction Sheet Introduction This instruction sheet covers the installation of the Signal Tower Light 24V. The light is compatible with the following Ikonix instrument models: IKONIX BRAND MODEL OMNIA® II Series HypotULTRA® Series Hypot® Series Associated Research HYAMP® Series HypotMAX®...
- Page 3 40417 Instruction Sheet Note: Inspect the part for any damage. If the part shows signs of damage, please contact our +1-800-858-8378 info@ikonixusa.com. Customer Care Group at or email at Installation SOLDER Solder the signal tower wires to the rear of the 9 Pin connector as illustrated in Figure 1.
- Page 4 40417 Instruction Sheet POWER CONNECTION Using a small screwdriver connect the two Brown cables to the 24 V supply connector’s Positive “+” and Negative “-“ ports. Note: Unused wires (White, Blue, and Yellow) should be properly cut and trimmed back. These wires are not required for operation in two light mode.
- Page 5 40417 Instruction Sheet VERIFY Connected the 9 Pin DSUB assembly to the Signal Output port of the test instrument. Run a test to verify the test is in process, the PROCESSING bit will be active, and the red signal light will illuminate and flash. This indicates that the testing station is not safe to approach.
