Comco Ikarus C42 B Pilot Operating Handbook

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
PILOT OPERATING HANDBOOK
for the aircrafts IKARUS C42 B according to
building standard LTF-UL-2019 from 15 January 2019
Modell No.
German Ident-No.
Type
Aircraft Serial-No.
This handbook is to be kept in the aircraft at all times.
The described options are certified for Germany and have been tested in
Germany.
Please note:
Different regulations apply in different countries for the use of the C42 series
as a tow plane for gliders, for banner towing or to drop skydivers. Please check
with the authorities responsible for your country.
C42 B
66141.1 (Issue 1)
IKARUS C42B with
reference to the TB-42-024-2020
________-________
Issue: 1
Date of issue: 25.06.2021
