MAXUS MIFA
MPV,5 Doors
2022-
395V
Li-ion Battery
Airbag
High
strength
zone
Fuse box
disabling
high voltage
system
LSK-MIFA-EV-E001
9.
VIP type seat
of 2nd row
Stored
gas inflator
Zone
requiring
special
attention
High
voltage
component
ID No.
4.
Other type seats
of 2nd row
Seat belt
pretensioner
Battery
low voltage
Version No.
01
SRS control
unit
High
voltage
battery
pack
Version date
06/2022
Gas strut/
Preloaded
spring
High voltage
power cable/
component
Page
1 of 4
Advertisement
Summary of Contents for Maxus MIFA 9 2022
- Page 1 MAXUS MIFA MPV,5 Doors 2022- VIP type seat Other type seats of 2nd row of 2nd row 395V Li-ion Battery Gas strut/ Stored Seat belt SRS control Airbag Preloaded gas inflator pretensioner unit spring Zone High High High voltage requiring...
- Page 2 1. Identification / recognition 2. Immobilisation / stabilisation / lifting A - Immobilisation / stabilisation B - Lifting PUSH 1x PUSH 1x Secure the vehicle using P gear and parking brake Just press the button once, P gear and parking brake work at the same time. Suitable lifting points High-voltage battery Click the “power off”...
- Page 3 3 . Disable direct hazards / safety regulations Disconnect from the charging station (emergency release) 1. Remove the left side panel. 2. Locate the loop of the emergency release . 3. Pull the loop PUSH 1x PUSH 1x Pull the loop Pull the loop Access to 12V Battery PULL 2x...
- Page 4 6. In case of fire If it is difficult to apply copious amounts of water to the high USE LARGE AMOUNT OF WATER voltage battery, it is recommended to allow the high voltage battery to burn itself out. BATTERY RE-IGNITION! 7.
