- Page 1 USER MANUAL 3PHASE HYBRID INVERTER 10-200KW Sate Copyright, copying and plagiarism without any authorization is prohibited The company is committed to the continuous improvement of the inverter. This information is subject to change without notice. please refer to the actual product.
-
Page 2: Table Of Contents
Contents I.Brief Introduction..............................3 A. General Instructions............................3 B. Cautions................................3 II.Installation and Wiring of the Inverter.......................3 A.Environment for Installation..........................3 B.Inspection before Installation...........................4 C.Installation Position............................4 D.Wiring..................................4 1.Output System for 10-200KW inverter 3 phases type..................4 2.Wiring Inspection..............................5 III.Operation of the Inverter -1..........................5 A.Procedures of Switching on Single Machine....................5 B.Procedures of Regular Switching Off ......................6 IV.Operation of the Inverter -2..........................6... - Page 3 D.Alarm4:Battery Discharging...........................12 E.Alarm5:Over-loaded............................13 F.Alarm6:Temporary Bypass..........................13 G.Alarm7:Turn to Bypass due to Over-loaded....................13 H.Alarm8:Order to Bypass ..........................13 I.Alarm9:Over-heat or Fault of Cooling Fans.....................13 VIII.Display Function............................13 A. General Introduction............................13 1.Instruction on LCD Indicators..........................13 2.Instruction on Main Screen..........................14 3.Introduction on Display Content........................15-17 IX.Connection with Computer..........................18...
-
Page 4: I.brief Introduction
I.INTRODUCTION A. General Instructions for inverter The product is the DC power (battery, storage battery) into alternating current (380V, 50Hz sine wave).It consists of an inverter bridge, control logic, and filter circuit.Widely used in air conditioners, home theater, electric grinders, power tools, sewing machines, computers, televisions, washing machines, range hoods, refrigerators, VCRs, massage, fans, lighting, etc.By connecting the cable to the battery, the appliances connected to the output of the machine will be able to use a variety of electrical appliances. -
Page 5: B.inspection Before Installation
conditioner is needed. The closer are these two temperatures, the larger capacity of the ventilation system would be, based on the following equation: Q(m³/h)=3. 1+Pdiss(kcal)/(ta-te)(c) kcal is the unit of Pdiss , adjust Pdiss 10% for allowing the loss of energy. B.Inspection before Installation After putting out the Inverter from the packing box, please check : whether there's any damage on it;... -
Page 6: Wiring Inspection
(4) Cable size for Input / Output , shown as the below table: (mm²) Input (including Bypass) Output Battery Model Positive Negative 10KW 15KW 20KW 30KW 40KW 50KW 60KW 80KW 100KW 120KW 140KW 160KW 200KW 100 100 2.Wiring Inspection After finishing wiring all of the input/output cables, the following should be inspected: (1) whether the order of the phases is correct;... -
Page 7: B.procedures Of Regular Switching Off
B.Procedures of Regular Switching Off 1. Disconnect the output switch; 2. Disconnect the Bypass Switch; 3. Disconnect the Battery Switch; 4. Disconnect the Rectifier Input Switch; 5. Disconnect the main power switch. Warning: 1. Please strictly follow the above procedures to turn off the inverter; 2. -
Page 8: C.static Bypass Mode
Step 3: After the battery is fully charged (e.g. by solar or wind charge controller), it will then automatically transfer to battery supplying power to the loads. See Workflow as below: Note: Battery supporting time would be affected by the power consumption of the loads and temperature. -
Page 9: D.reparing Mode
D.Reparing Mode Used when the inverter needs repairing without cutting the power for the loads. When Repair Switch is closed, the control panel stops displaying, and eletricity goes from bypass route to the load and the load will be affected by any interference on the power grid. Batteries cannot supply the power for loads;... -
Page 10: B.battery Maintenance
<5% Distortion Soft Start 0~100% 5 seconds Time Table 1 2.Output Rectifier shown as Table 2 Model 10KW 15KW 20KW 30KW 40KW 50KW 60KW 80KW 100KW 120KW 140KW 160KW 200KW Max. Output 216VDC 408VDC 432VDC Voltage Charging 5A ~30A (adjustable) -
Page 11: B.battery
B.Battery Shown as Table 3 Model 10KW 15KW 20KW 30KW 40KW 50KW 60KW 80KW 100KW 120KW 140KW 160KW 200KW Max. Discharge 104A 156A 125A 156A 187A 249A 311A 373A 435A 497A 559A Current Battery 192 VDC 360VDC 384VDC Voltage Float... -
Page 12: D.bypass
Inverter Efficiency on 100% load Table 4 D.Bypass Shown as Table 5 Model 10KW 15KW 20KW 30KW 40KW 50KW 60KW 80KW 100KW 120KW 140KW 160KW 200KW Input 105A 125A 150A 199A 240A 300A 340A 388A 480A Current Phase 3 phases, R S T +N+G Nominal 380vac ±15% (Stable Load) -
Page 13: Vii.alarms
Efficiency >85% (100% load) Communication RS232 Port Operating 0~40℃; Temperature Operating Relative 5%~95% Humidity Operating ＞1000M（1% Power dcreased in every 100M increased. Maximum 4000M） Altitude Cooling Method Force Ventilation Color Black Input Cable From Bottom and Back Maintenance Front / Top/ Flank side Side Input Setup Terminal Board... - Page 14 D.Alarm4:Battery Discharging It alarms once the batteries start to discharge. In about 2 minutes, the alarm stops. It alarms when the batteries capacity is close to exhausted voltage. (The above happens without "Mute" being pressed) E.Alarm5:Over-loaded It alarms when load power exceeds 100% of the output power of the inverter; Loads need to be reduced, otherwise the inverter will turn to bypass automatically.
- Page 15 INVERTER Inverter LED OUTPUT Load LED ALARM ALARM LED 1.2 LED STATUS MEANS Green normally on AC input works properly Green flashing Ac input anomaly Ac Input LED does not light There is no AC input Green normally on Battery discharge inverter Green flashing Battery low pressure alarm Battery LED...
- Page 16 2. LCD display graphics instructions Power input parameters Entry operation Battery voltage Battery capacity % value AC charging current Current running mode Output voltage parameter Output load parameters Mute and cancel the mute button Current time date Inverter on or off Solar Voltage Solar Current 15th...
- Page 17 3. Operation Mode Setting： 3C.1 modification parameters: Enter the password to modify and set parameters. The factory password is: 123456 16th...
- Page 18 3C.2 modify battery parameters: Click directly in the blank of the battery and input the voltage value the user wants 17th...
- Page 19 3. RS 422/RS 232 transferable port 4. Signal board for dry contact alarm 5. 12-pulse rectifying 6. All kinds of non-regular machine PSC Solar UK Physical Office/Warehouse: 41B, Olutoye Cres/Adeniyi Jones, Ikeja, Lagos State,Nigeria Phone No.: +2348120855444, +2348123655444 Website: www.pscsolaruk.com Email Address: info@pscsolaruk.com...
