"Global Pool Products is committed to engineering and manufacturing world class products in the pool industry"

TSUNAMI ASSEMBLY & INSTALLATION

GUIDE

www.global-poolproducts.com

Global Pool Products

1330 Pigeon Rd

Bad Axe, MI 48413

Information contained in this document is proprietary and confidential to

P: 989-269-5900 - TF: 866-712-0606

Global Pool Products and not to be reproduced without

Fax: 989-269-5902

written consent from Global Pool Products.

www.global-poolproducts.com

Page | 1

Table of Contents

Need help?

Do you have a question about the TSUNAMI and is the answer not in the manual?

Questions and answers

Summary of Contents for Global TSUNAMI

Page 1 “Global Pool Products is committed to engineering and manufacturing world class products in the pool industry” TSUNAMI ASSEMBLY & INSTALLATION GUIDE www.global-poolproducts.com Global Pool Products 1330 Pigeon Rd Bad Axe, MI 48413 Information contained in this document is proprietary and confidential to...
Page 2: Table Of Contents
“Global Pool Products is committed to engineering and manufacturing world class products in the pool industry” TSUNAMI SLIDE TABLE OF CONTENTS Introduction PAGE 3 Tsunami Post Installation Instructions PAGE 4 Maintenance Instructions PAGE 4 Tsunami Slide Placement/Stub Up PAGE 5...
Page 3: Introduction
Examine all parts thoroughly prior to installation to avoid anything that may have been damaged in transit. A damaged part should not be used in the installation of this slide. Contact Global Pool Products if any parts arrived damaged. Proper assembly and installation of the Tsunami Slide is imperative. Not following the directions provided will void Global Pool Products Warranty and may affect the safety of the slide rider.
Page 4: Tsunami Post Installation Instructions
“Global Pool Products is committed to engineering and manufacturing world class products in the pool industry” POST INSTALLATION CHECKLIST FOR TSUNAMI SLIDE Installer to review with slide owner upon completion of slide installation. Examine: The flume for any apparent cracks or gashes.
Page 5: Tsunami Slide Placement/Stub Up
“Global Pool Products is committed to engineering and manufacturing world class products in the pool industry” Tsunami Slide Placement/Stub-up Location Global Pool Products 1330 Pigeon Rd Bad Axe, MI 48413 Information contained in this document is proprietary and confidential to...
Page 6: Tsunami Specification Sheets
This slide is intended for use on in-ground residential swimming pools ONLY. Our multi point anchoring system allows the Tsunami to accommodate most geographical regions. The slide is rated for a maximum of 275 lb. (124 kg) for its riders.
Page 7 “Global Pool Products is committed to engineering and manufacturing world class products in the pool industry” Tsunami Slide Specifications Global Pool Products 1330 Pigeon Rd Bad Axe, MI 48413 Information contained in this document is proprietary and confidential to P: 989-269-5900 - TF: 866-712-0606...
Page 8 “Global Pool Products is committed to engineering and manufacturing world class products in the pool industry” Tsunami Slide Specifications Global Pool Products 1330 Pigeon Rd Bad Axe, MI 48413 Information contained in this document is proprietary and confidential to P: 989-269-5900 - TF: 866-712-0606...
Page 9 “Global Pool Products is committed to engineering and manufacturing world class products in the pool industry” TSUNAMI ASSEMBLY INSTRUCTIONS Tools Needed: 10. 5/8” Deep Well Socket 1. 3/16” Allen Wrench PTFE (Teflon) Tape 11. 9/16” Deep Well Socket 2. 7/32” Allen Wrench PTFE (Teflon) Glue 3.
Page 10 “Global Pool Products is committed to engineering and manufacturing world class products in the pool industry” Prior to the Start of Assembly: o Utilize the cardboard that the slide shipped in as a barrier between your slide components and the surface that the slide is being assembled on to prevent any scuffs and scratches.
Page 11: Tsunami Assembly
“Global Pool Products is committed to engineering and manufacturing world class products in the pool industry” Tsunami Assembly Instructions STEP 1 Attaching the base to the lower flume a. Use bag one from the hardware kit to attach the lower flume to the base b.
Page 12 “Global Pool Products is committed to engineering and manufacturing world class products in the pool industry” STEP 2 Installing the foam gasket and butyl on the lower flume a. Install the shorter 34” foam-rubber gasket from the seal kit tube on the lower flume, start at the top and install it following the curve of the flume, cut off any excess and discard it b.
Page 13 “Global Pool Products is committed to engineering and manufacturing world class products in the pool industry” STEP 3 Attaching the upper flume to the lower flume a. Use two people to lift the upper flume and place it onto the lower flume, they lock into place with the grooved design b.
Page 14 “Global Pool Products is committed to engineering and manufacturing world class products in the pool industry” STEP 4 Attaching the plumbing a. Use the PVC fitting in bag four from the hardware kit to hookup the plumbing in the upper ladder b.
Page 15 “Global Pool Products is committed to engineering and manufacturing world class products in the pool industry” STEP 5 Attaching the upper ladder to the lower ladder a. Stand the lower ladder upright, place the upper ladder on top and guide the remaining flex hose into the lower ladder b.
Page 16 “Global Pool Products is committed to engineering and manufacturing world class products in the pool industry” STEP 5.5 Installing the dual seal on the upper ladder a. Measure the center of the ladder, use the two through bolt holes as measuring points, mark center with a sharpie b.
Page 17 “Global Pool Products is committed to engineering and manufacturing world class products in the pool industry” STEP 6 Attaching the ladder to the flume assemblies a. From bag six in the hardware kit, use two 3” studs and install them into the upper flume, tighten them using a 3/16”...
Page 18 “Global Pool Products is committed to engineering and manufacturing world class products in the pool industry” STEP 7 Installing the inner connections between the ladder and the flume a. From bag seven in the hardware kit, use two 3/4” hex bolts, each with one flat washer, insert them into the two lower connection points inside the ladder b.
Page 19 “Global Pool Products is committed to engineering and manufacturing world class products in the pool industry” STEP 8 Installing the access cover plate a. From bag eight in the hardware kit, use six Phillips head screws to secure the access panel on the upper ladder b.
Page 20: On Deck Mounting & Plumbing Instructions
“Global Pool Products is committed to engineering and manufacturing world class products in the pool industry” Optional Lighting Preparation Install 1” conduit next to the water stub-up before concrete is poured. Run the conduit outside of the concrete pool deck to either the pool equipment or junction box.
Page 21 “Global Pool Products is committed to engineering and manufacturing world class products in the pool industry” 1. Place the assembled slide on the pool deck relative to the pool wall with the ladder side over the stub up location. 2. Check to ensure the exit of the flume clears all coping edges. The slide may be angled to your preference as long as the guidelines provided in Global Pool Product’s Placement Instructions are...
Page 22 “Global Pool Products is committed to engineering and manufacturing world class products in the pool industry” 9. Drive all anchors through the slide anchoring holes. 10. Expand anchors by tightening the nuts three to five turns. When the anchor is set, remove the nut and install a lock washer, then retighten the nut to specified torque.
Page 23 “Global Pool Products is committed to engineering and manufacturing world class products in the pool industry” Pool Slide Installation – Paver Pool Deck Tools Required ½” Concrete Drill Bit ¾” Socket or Wrench Chalk Line Hammer Hammer Drill Hardware Rip Tide, Tidal Wave, Tsunami (10) –...
Page 24: Exploded View Reference Materials
“Global Pool Products is committed to engineering and manufacturing world class products in the pool industry” Global Pool Products 1330 Pigeon Rd Bad Axe, MI 48413 Information contained in this document is proprietary and confidential to P: 989-269-5900 - TF: 866-712-0606...
Page 25 “Global Pool Products is committed to engineering and manufacturing world class products in the pool industry” Global Pool Products 1330 Pigeon Rd Bad Axe, MI 48413 Information contained in this document is proprietary and confidential to P: 989-269-5900 - TF: 866-712-0606...
Page 26 “Global Pool Products is committed to engineering and manufacturing world class products in the pool industry” Global Pool Products 1330 Pigeon Rd Bad Axe, MI 48413 Information contained in this document is proprietary and confidential to P: 989-269-5900 - TF: 866-712-0606...
Page 27 “Global Pool Products is committed to engineering and manufacturing world class products in the pool industry” * Hardware attaches through access plate on back side of ladder section *GPP-B375x75HHCS 3/8” x ¾” Hex Bolt QTY. 4 *GPPBW375 WASHER QTY. 4...
