AI Buddy
​
DISCLAIMER:​
T his guide is for reference only and does not constitute any form of commitment from the
provider. Products, specifications, and functionality presented in this document (including but not limited to
color, size, screen display, and so forth) may differ from the actual product.
Getting Started Guide

Version 2.2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AI Buddy Plai WiFi and is the answer not in the manual?

Questions and answers

Summary of Contents for Gyrfalcon Technology AI Buddy Plai WiFi

  • Page 1 AI Buddy    Getting Started Guide  Version 2.2 ​ DISCLAIMER:​ T his guide is for reference only and does not constitute any form of commitment from the provider. Products, specifications, and functionality presented in this document (including but not limited to color, size, screen display, and so forth) may differ from the actual product.

  • Page 2: Table Of Contents

      Contents  AI Buddy Basic Settings AI Buddy Buttons and LED Indicators Specifications Charging and Safety Precautions Application User Guide First Steps Connecting to the AI Buddy Mode A: Direct Connect Mode Mode B: Trunk Connection Mode Mode C: Mobile Hotspot Connection Mode Wireless USB Flash Drive AI Sample Applications About the Application Menu Bar...

  • Page 3: Ai Buddy Basic Settings

    AI Buddy Basic Settings AI Buddy Buttons and LED Indicators Reserved Button Memory Card Indicator Reset Button AI Indicator Power Button WiFi Indicator Power Indicator Charging Port ● Power Indicator: Blinks when charging and working. ● Power 100%~76%: Blinks quickly 4 times. ●...

  • Page 4: Specifications

    Specifications Network Transmission rate: 150Mbps Network standards IEEE802.11b，IEEE 802.11g，IEEE 802.11n Wireless Security WPA-PSK/WPA2-PSK Working frequency band / frequency 2.4GHz Working mode Routing mode, Wireless relay Gateway IP address 10.10.10.254 Username: ​ a dmin ​ | Password: ​ a dmin Login Climate Working temperature 0℃...

  • Page 5: Charging And Safety Precautions

    Charging and Safety Precautions To keep the AI Buddy from shutting down due to insufficient power, monitor the power indicator and charge the device before use. Safety Precautions ● Using an unlicensed or incompatible battery may cause fire, explosion or other hazards. ●...

  • Page 6: Connecting To The Ai Buddy

    Step 2.​ After download finishes, open the application on your device. Step 3.​ Ensure that the AI Buddy device is fully charged, then turn it on. Step 4.​ Use Mode A to connect the application to the AI Buddy device as described in the following section.

  • Page 7: Mode B: Trunk Connection Mode

    3. Choose the AI Buddy WiFi access point and enter the password (default 12345678 ​ ) . The SSID and password are on the back of the AI Buddy and on the package. Or you may manually select to connect to the AI Buddy WiFi access point directly from your phone Settings.
  • Page 8 Note:​ Trunk mode works only on 2.4GHz networks. How to Use 1. Connect to AI Buddy via Mode A first then return to Connect to AI Buddy. 2. Select Trunk Connection Mode. 3. Click Next. 4. Select an alternate WiFi access point and enter the WiFi access password. 5.

  • Page 9: Mode C: Mobile Hotspot Connection Mode

    ​ Mode C:​ M obile Hotspot Connection Mode Note​ : If there is no available WiFi, you can use this method to have Internet access using your mobile device as a hotspot while using AI Buddy. How to Use 1. Connect to AI Buddy via Mode A first, then choose Mobile Hotspot Connection Mode. 2.

  • Page 10: Wireless Usb Flash Drive

    Step 1 Step 2 Note:​ ​ I f connected through HOTSPOT mode, you will see the green chain and “Internet Explorer” icon. Wireless USB Flash Drive The wireless USB flash drive is a mobile hard drive that connects to your mobile device wirelessly and can be used to store files.

  • Page 11: Ai Sample Applications

    3. Long press “File List” to download the selected file. It will be stored at the “AI Buddy” subdirectory of the phone memory by default. C urrently, only some common format files can be directly opened. Other file Note:​ ​ formats may need to be downloaded to the phone memory before they can be opened.
  • Page 12 Select from Album Select a picture: Select a picture from the album and get the image recognized. Capture Real-time Video Capture real-time video and get images identified. The more angles you can capture in the video, the better the accuracy for object identification. For example, “Dog Breed Recognition”...

  • Page 13: About The Application Menu Bar

    About the Application Menu Bar Connect to AI Buddy Connect to AI Buddy box using different modes TTS Setting Turn on/off text-to-speech reading mode. Lock AI Buddy Lock AI Buddy box to your account to enable file privacy and prohibit others from using all other AI Buddy app features.

  • Page 14: Work Exception Handling

    Note: ​ O nce your account is locked, you must sign in to the authorized account to access all the AI Buddy functions. Work Exception Handling Tip:​ If you encounter a long response time while using the AI Buddy mobile app, or if the communication connection or the AI Indicator is not functioning properly, in most cases these issues can be resolved by restarting the app or restarting the AI Buddy device.
