Summary of Contents for AeroTow T3
- Page 1 AeroTow User manual Are you ready to go? 989-777-0910 AmigoAeroTow.com...
- Page 2 Power, on / charger off. Lighting switch. Hydraulic lift remote. Tires Max tow capacity T3 Weight 18” x 8” x 8.5” 20,000 lbs on level Unit weight is 500 lbs ground Labeling Always follow all warnings and labeling on the T3.
- Page 3 Precautions As the operator, you are fully responsible for the safe operation of the tug and any damage done to the aircraft or hangar due to operation errors. Familiarize yourself with the throttle and speed response of the tug before attaching your aircraft. The tug does not stop immediately, this is intentional to protect your aircraft from damage.
- Page 4 Unscrew the nut and remove bolt (B). Insert the handle into the handle connector on the T3 frame (C). Secure the handle to the T3 using the nut and bolt (B). Connect the hydraulic control cable (D) to (E). Connect the battery cable (F) to (G).
- Page 5 Handle controls A. T3 power on / off B. Toggles light on / off C. Fuse knob D. Hydraulic lift up / down E. Press in for forward / reverse...
- Page 6 Connecting your aircraft To connect the tug to the aircraft, move the tug close to the front wheel. Use the lower lift button on the handle controls to drop the hydraulic lift. Using the winch controller, run the winch line out, so there is enough slack to attach the wheel strap around the nose gear.
- Page 7 Moving your aircraft Check the surrounding area, and remove any obstacles or obstructions before moving your aircraft, remove chocks. Make sure the wheel strap is tightened around the nose gear. Return to the handle of the tug. Turn power on and move your aircraft using the reverse / forward switch located on the front of the handle control box.
- Page 8 AeroTow by Amigo Mobility 6693 Dixie Hwy, Bridgeport, MI 48722 989-777-0910 AmigoAeroTow.com...
