Inter-Tech C-3 Saphir Manual page 3

Thank you for buying a case from Inter-Tech. You got a high-quality case with a lot of individual controllable light effects and plenty space for
large graphics adapter and hard disks.
This case is made only for computer assembling and indoor use.
We recommend to read this manual carefully and to connect fans and controller as per description.
We assume no liability for damages caused by nonobservance of this manual. Keep this manual for later use.
Make sure that the case is isolated from electric grid when working on it.
Because LED work with less voltage the current is higher to get the same wattage. Therefore the fire hazard increases in case of improper
installation or use. Ensure that all cables are correct and strong connected before starting the computer.
In case of strange noise, smell or smoke, cut the connection to the electric grid immediately.
We recommend to separate the computer from the electric grid in case of longer non-use.
If you want to dispose your computer, don´t dispose it with normal waste. Please bring it to the special collection points for electric waste.
Please ask you municipality for that. Cardboard and plastics from packaging can be disposed in the appropriate waste container of household
garbage.
We grant the implied warranty for this product. In case of warranty claim, please contact your dealer. The complete warranty terms are shown
on our website www.inter-tech.de.
Pos. Description
Distance holder
A
B Screws
C Screws
D Screws
Screws
E
F Screws
G Cable ties
Fan mounting at back side
Fan mounting on top
Manual C-3 Saphir
Quantity Use
For Mainboard mounting
5
For mounting of Mainboards
18
2,5" HDD
For Power Supply
4
4 For 3,5" HDD
For 3,5" HDD
4
8 For fans on power supply tunnel
4 For cable mounting
- You can mount one 120mm fan.
- Remove left side panel.
- Place the fan from ahead into position and fix it
with screws from behind(these screws are part
of the fan).
Fan mounting in front
and
Fan mounting on the power supply tunnel
- You can mount one 120mm fan.
- Remove left side panel.
- Remove dust filter from top (it´s fixed by
magnets).
- Place the fan from below into position and fix it
with screws F from above(these screws are
part of the fan).
- Put the dust filter back on his place
- You can mount up to three 120mm fans.
- Remove left side panel.
- Take off front panel by pulling the lower end of
the front panel.
- Take care not to tear off the cables.
- Place the fan from behind into position and fix it
with screws from ahead (these screws are part
of the fan).
- Re-mount the front panel by pushing it onto the
case, beginning at the top.
- Avoid to clamp cables.
- You can mount up to two 120mm fans.
- Remove left side panel.
- Place the fan from above into position and fix it
with screws F from above (these screws are
part of the delivery).
