MV3-IM and MV3-TS Series USER Guide

Software MV3-IM and MV3 Series Multizone Controllers

Written by : K. PERRIN

Date : 08/04/19

Change history

SISE_M_REGUL_Serie M_MV3-IM_MV3-TS_V7.3_20200108_B_En

Hot runner temperature control

Date

08/04/19

08/01/20

Approved by : NCN

Date : 08/01/20

Change description

Merge MV3-IM and MV3-TS, 6.0 Version

Version 7.3

Translated from the original manual

www.sise-plastics.com

Table of Contents

Need help?

Do you have a question about the MV3-IM Series and is the answer not in the manual?

Questions and answers

Summary of Contents for S.I.S.E. MV3-IM Series

Page 1 MV3-IM and MV3-TS Series USER Guide Hot runner temperature control Software MV3-IM and MV3 Series Multizone Controllers Written by : K. PERRIN Approved by : NCN Date : 08/04/19 Date : 08/01/20 Change history Date Change description 08/04/19 Merge MV3-IM and MV3-TS, 6.0 Version 08/01/20 Version 7.3 Translated from the original manual...
Page 2: Table Of Contents
CONTENTS FIRST START-UP ........................5 GENERAL PRESENTATION OF THE INTERFACE ............5 2.1) C ......................5 2.1.1) Contextual help ....................... 6 ocking/Unlocking the user interface 2.1.2) L ................ 6 creen shots 2.1.3) S ......................... 7 2.1.4) Navigation and screens ....................7 2.2) S ......................
Page 3 3.2.3.3) Alarm Parameters .................... 40 3.2.4) Electrical analysis of the mold..................41 3.2.4.1) Mold veriﬁ cation (MoldScan) ................ 41 3.2.4.2) Readings ......................42 3.2.4.3) Mold monitoring....................42 3.2.4.4) Consumption ....................46 3.3) A ......................46 3.3.1) Remote log-in........................ 46 3.3.2) Communication ......................47 3.3.3) System information .......................
Page 4: First Start-Up
1) FIRST START-UP Connect the power cord to the appropriate power supply (see nameplate and operating instructions). Check all incoming and outgoing connections. Turn on the system using the interruptor located on the front. After a few seconds, the display screen lights up. System type/ Serial number/ Software version...
Page 5: 1) Contextual Help
The status bar provides general information on the system status such as date and time, current conﬁ guration ﬁ le, current screen name (as well as other information relevant to the screen such as the number of zones displayed out of the total number of zones, the number of zones selected and the number of zones in alarm), current operating mode (Stop/Gradual stop/Standby/Production - see §3.2.1).
Page 6: 3) Screen Shots
Functions available for the diﬀ erent privilege levels are listed below: Privilege level Accessible functions The interface is "read-only", no changes can be made to the system. Possible modiﬁ cations are: • Change a setpoint • Turn zones On/Oﬀ • Auto/Manual mode •...
Page 7 Press the tab to return to this display Select the appropriate thumbnail to access the screen Press the «Zone conﬁ guration table» thumbnail to go to that screen. You can now check the status of the control zones by clicking on the "Control view" tab and by selecting the "Control"...
Page 8 2.2) S The screens are assigned to the diﬀ erent views according to their function: • The SYSTEM view pertains to the whole system (i. e. mold ﬁ les). • The CONTROL view pertains to the temperature control. • The ALARM view pertains to alarm management. •...
Page 9: 1) Information On Heating Zones
2.3) G The "Control" and "Table of active alarms" screens both contain information on the heating zones. On each of these screens the zones are represented in a grid: zoom in or out to re-size this grid. "Control" screen "Table of active alarms" screen 2.3.1) Information on heating zones The information displayed for each zone also depends on the selected zoom level and on the screen size.
Page 10: 2) Alarm Screen
Min. information displayed Zone without alarm Zone with low temperature alarm Zone name + Group identiﬁ cation icon Temperature Status The meaning of the various status icons is described below: Icon Description Temperature of the zone is below setpoint: Low temperature alarm. Temperature of the zone is above setpoint: High temperature alarm.
Page 11 Min. information displayed Zone with high temperature alarm or other alarms Zone with low temperature alarm Zone name + Group identiﬁ cation icon Temperature alarm Power alarm The meaning of the various temperature alarm icons is described below: Icon Fault Temperature of the zone is below setpoint: Low temperature alarm.
Page 12: 2) Changing The Number Of Zones Displayed
2.3.2) Changing the number of zones displayed It is possible to zoom in or out so as to display more or fewer zones. This allows an overall view of the system showing fewer details for each zone, or alternatively to view more information of a smaller number of zones.
Page 13: 2) Zoom In Or Out Using The Navigation Icon
2.3.2.2) Zoom in or out using the navigation icon Pressing the navigation icon in the Action bar brings up a double icon bar with the following actions: Icon Action Scroll up, equivalent to moving towards the ﬁ rst zone. Scroll down, equivalent to moving towards the last zone. Zoom in, display fewer zones but with more detail.
Page 14: Using The System
3) USING THE SYSTEM In order to use the system correctly, it is necessary to conﬁ gure it properly before you use it for the ﬁ rst time. This greatly facilitates daily use. The software also has advanced features including remote operation and customizable company information.
Page 15: 2) Regional Parameters
Heating neutralization input action This option is used to select the action of the HEATING NEUTRALIZATION input (see §6.4 of the Operating instructions). This input makes the system switch to the ‘Stop’ or ‘Gradual stop’ states. To restart heating, changing the input is necessary, but not enough. The Operating mode selector of the screen must be used (except for the last option: see the list of options below).
Page 16: 3) Changing The Interface Lock Passwords
Choose language Set date and time Time zone To change the date, press one of the ﬁ elds (day, month, year), then use the up and down arrows to increase/decrease the value in this ﬁ eld. To change the language of the interface, click on the corresponding ﬂ ag. The time zone parameter must be speciﬁ...
Page 17: 4) Network Settings
3.1.1.4) Network settings Choose to assign an IP address automatically or manually, and conﬁ gure network settings such as a Network mask or Gateway. Connect an ethernet cable between the unit and a PC or Injection Molding Machine to modify the network parameters. icon indicates that the system is connected and the network is working.
Page 18: 2) Ramp Softstart Settings
Minimum automatic mode setpoint and maximum automatic mode setpoint Maximum and minimum setpoints can be speciﬁ ed for the automatic mode. Abnormally high temperature threshold This value determines the temperature above which an Abnormally high temperature alarm is triggered, even if the zone involved is stopped. Changeover to manual mode if a thermocouple is cut If a thermocouple is cut, the zone concerned switches to manual mode, with the last power percentage applied.
Page 19 Start-up ramps: On start-up, the zones in automatic mode are heated gradually until they reach their operating setpoint. There are four possible types of start-up ramps: Duration ramp Gradient ramp The system heats at the maximum gradient of A, The system heats at the maximum gradient of A. then maintains the temperature at B for a period During cooling, gradient E will be applied of C minutes.
Page 20: 3) Heating Zone Confi Guration
and E ramp gradients: A and E ramp gradients determine the heating / cooling gradient and thus the instantaneous power consumption. Settings will therefore be done according to criteria of technical necessity and the need to limit the peak current during heating. Optimized power consumption AND non-optimized heating time.
Page 21 The values which appear on the screen are those common to the selected zones. For values which are not identical for all the selected zones, the following symbol will appear: ---. Only changes in these values will be applied to the selected zones upon validation. Modiﬁ ed values appear in red.
Page 22 On/Oﬀ The selected zones can be turned on or oﬀ by pressing the "ON" and "OFF" icons. Operating mode and setpoints Heating zones can be controlled automatically or manually In automatic mode a setpoint is speciﬁ ed in °C or in °F and the control system automatically selects the power to be applied to the zone in order to bring that zone up to the selected temperature and keep it there.
Page 23 Note: Boost duration, as well as the Duration without alarm after boosting, are the same for all heating zones and can be conﬁ gured in the «Temperature control settings» screen (§3.1.2.1). value For a positive boost value For a negative boost value Zone slaving Conﬁ...
Page 24 Temperature alarm trigger thresholds Zone temperature is monitored in automatic mode. If this temperature rises above or falls below the setpoint, a High or Low Temperature Alarm is triggered. Alarm trigger thresholds can be conﬁ gured in this screen. If these trigger thresholds are set at ± 5°C and the setpoint of the zone is 150°C, a Low Temperature alarm is triggered if the measured temperature of the zone falls below 145°C, and a High Temperature alarm if the temperature rises above 155°C.
Page 25: 4) Zone Groups
3.1.2.4) Zone Groups Zone groups have two functions: • Make it easier to conﬁ gure the system by selecting the group of zones to modify • Specify which zones are nozzles and which are manifold, necessary when using a staggered ramp.
Page 26 The group is created when the icon is pressed in the Action bar. Pressing the icon on the Action bar will cancel its creation. Upon creating a group, the group zone display and assignment screen is displayed automatically. Group zone display and assignment : You can view or modify the contents of a group by selecting it in the list of groups and pressing the button or by double-clicking on it in the list of groups.
Page 27: 5) Zone Confi Guration Table
Deleting a zone group: Delete a zone group by selecting it in the list of groups and pressing You will be asked to conﬁ rm the deletion. The group will be deleted if the icon is pressed in the Action bar. Pressing the icon on the Action bar will cancel the deletion of the group.
Page 28: 3) Confi Guration Fi Les
3 categories of settings can be displayed from this screen: Screen Settings Conﬁ guration settings (On/Oﬀ , Auto/Manual, Setpoint, Current Temperature, Applied Power Setpoint Parameters (On/Oﬀ , Auto prod setpoint, Auto standby setpoint, Manual prod setpoint, Manual standby setpoint) Tolerance Parameters (Manual prod setpoint, Manual standby setpoint) These settings are accessible from the 'Quick change' action bar of the conﬁ...
Page 29: 1) Creating A Confi Guration Fi Le
Conﬁ gure the temperature control: §3.1.2.3 – §3.1.2.5. § Switch zone heating on: in the "System" view , "Operating mode selector" screen switch to "Production" state Wait until all zones are in the column, then wait 5 minutes. Apply reference values: "Control" view , "Mold monitoring"...
Page 30: 2) Displaying A Confi Guration Fi Le
The ﬁ elds below can be edited by clicking on each line: • File name (mandatory): the name of the ﬁ le as it will appear in the list of ﬁ les • Created by (optional): the name of the person who created the ﬁ le •...
Page 31: 3) Loading A Confi Guration Fi Le
3.1.3.3) Loading a conﬁ guration ﬁ le Load conﬁ guration ﬁ les using the "Conﬁ guration ﬁ les" screen ("System" view ): select a ﬁ le in the left-hand list (the ﬁ le name is highlighted and its details appear in the ﬁ elds on the right of the list), then press the Load icon Loading a ﬁ...
Page 32: 7) Exporting And Importing Confi Guration Fi Les Using A Usb Fl Ash Drive
3.1.3.7) Exporting and importing conﬁ guration ﬁ les using a USB ﬂ ash drive A conﬁ guration ﬁ le can only be exported to or imported from a USB ﬂ ash drive once the USB ﬂ ash drive (or a USB hard disk) has been connected to the USB port on the front of the system. Once the USB key has been connected, the icon will appear in the Action bar of the "Conﬁ...
Page 33 Navigate the ﬁ le list to choose the ﬁ le to be imported Press The imported ﬁ le is then present in the list of ﬁ les. Export a conﬁ guration ﬁ le to a USB ﬂ ash drive in PDF format: To export a conﬁ...
Page 34: 1) Selecting The Operating Mode
3.2) N 3.2.1) Selecting the operating mode 3.2.1.1) Description of operating modes The status bar contains an indicator showing which operating mode the system is in: This indicator is also an icon that opens a menu to change the mode. It is displayed on all screens: Stable states: The appliance in stable operation is in one of the 4 following modes:...
Page 35: 2) Setting The Operating Mode
MoldScan state: This special test state is initiated only from its dedicated page and is displayed with the following icon: • MoldScan: The system is testing the previously selected zones one by one. 3.2.1.2) Setting the operating mode By default, on power-up, the system is in the "Stop" state. However, it can be set diﬀ...
Page 36: 2) Heating Zone Management
3.2.2) Heating zone management 3.2.2.1) "Quick change" action bar Various frequent actions can be carried out directly from the "Control" screen as well as in the zone conﬁ guration screen. To do this, select one or more zones (§2.3.3). (§ additional buttons are displayed in the Action bar.
Page 37: 2) Automatic And Manual Setpoint
3.2.2.2) Automatic and manual setpoint For each zone, the control system accepts 2 setpoints for the Standby state and 2 setpoints for the Production state (§3.2.1), a temperature setpoint for automatic operation and a power setpoint for manual operation. Each zone can be operated either manually or automatically If the zone is conﬁ...
Page 38: 2) Alarm Log
3.2.3.2) Alarm log The log of alarms generated within the system can be viewed in the "Alarm log" view, "Alarms" screen. In the example shown they are sorted by date The list can contain up to 1000 alarms. Press the bar at the top of the list to view the alarms sorted by zone number, name, date or alarm type, in increasing or decreasing order.
Page 39: 3) Alarm Parameters
When a USB ﬂ ash drive is plugged in, it is possible to export the alarm log for evaluation from a PC using the action icon and then . If a ﬁ lter is in use, you will have the choice to export the ﬁ...
Page 40: 4) Electrical Analysis Of The Mold
3.2.4) Electrical analysis of the mold Two types of mold analysis are available: • MoldScan: one-time analysis when a mold is ﬁ rst installed or after mold maintenance, to check the integrity of the mold and its connections. • Continuous mold analysis, based on measurements made during operation From the continuous mold analysis, zone power consumption is calculated according to the power applied.
Page 41: 2) Readings
The screen for setting / conﬁ rming the test parameters is displayed: 3 parameters must be set: • Test duration: the value is given in s/kW. For example, for zones of 250W and 1.2kW, with a value of 300s/kW, at a maximum the test will take, respectively, 75s (0.250x300=75s) and 6 minutes (1.2x300=360s=6min°.
Page 42 Through the mold monitoring screen the user can quickly assess the operation and consumption of the control system. For monitoring to be eﬀ ective, the calculated values must be taken as reference values. The mold monitoring screen is accessible in the "Control" view Temperature monitoring Power monitoring Heating element monitoring...
Page 43 "Power monitoring" table Power monitoring tolerances can be set/activated/deactivated in this table. Power monitoring limits in relation to the reference power, as well as the current power are displayed. The latter is colored red when outside its tolerance. From this page you access the sub-menu for applying reference values. The basic idea is to monitor the power applied to the load in order to detect if any of various parameters drifts from its proper value (for example: excessive power consumption, etc.).
Page 44 From this page you access the sub-menu for applying reference values. Using the button, you can also change the display system of quantities: ohms, watts, amperes. Applying reference values: To have valid reference values, the values must be saved in the "Save measurements" sub-menu. Actions that can be performed from the sub-menu are as follows: Icon...
Page 45: 4) Consumption
3.2.4.4) Consumption This screen displays consumption in real time for each zone. The value is expressed in Watts Amperes 3.3) A 3.3.1) Remote log-in Users can log in to the interface via Ethernet using a VNC client (example on PC, available at: «http://www.realvnc.com/download/viewer/»...
Page 46: 2) Communication
3.3.2) Communication The system can be connected to an injection molding machine or another external machine. Communication can be set in the "Conﬁ guration" view , "External parameters" screen Up to 3 simultaneous communication channels can be conﬁ gured. 3.3.3) System information System information gives details of the company and of the system’s conﬁ...
Page 47: 1) Restoring Factory Settings
By pressing "More...", you can view detailed system information: This information (serial number, embedded software version, etc.) can be requested in case of a call to our after-sales service. 3.3.3.1) Restoring factory settings action icon will restore the system to its original factory settings. All control settings will be reset.
Page 48: 4) Data Acquisition
3.3.4) Data acquisition Beginning at start-up, the, setpoint, applied power and temperature data are stored using the last two hours of operation. They can be exported and even viewed in the "Control" view , "Data acquisition" page Depending on the orientation of the screen, the layout of this page will be diﬀ erent: landscape screen portrait screen You can toggle between displays by...
Page 49 Customizable recording : starts recording. To start recording, a USB ﬂ ash drive must be detected by the system. A location and ﬁ lename must be selected by clicking on the "File selection" input ﬁ eld and completing it. If necessary, time between two samples must be changed by clicking on the 'Time between two samples' input ﬁ...
Page 50: 2) Curves
3.3.4.2) Curves This page allows you to view the data as curves. By default, no curve is shown. To select the curves to be displayed, click on the ‘Select curves’ button. A filter setting screen is then opened, where zones to be displayed (max. 2) and types of data to be displayed (Temperature - Setpoint - Power) can be selected.
Page 51: 5) Documentation Fi Les
3.3.5) Documentation ﬁ les The "Documentation ﬁ les" screen , "System" view , allows you to display various factory-installed documents like: • Operating instructions. • Connection diagrams. Double-click on the name of the document you wish to view to open the reading screen: Use the buttons of the action bar to navigate.
Page 52: 6) Programmable Clock
3.3.6) Programmable Clock The "Programmable Clock" screen , "System" view, allows you to program the system so that it behaves in a speciﬁ c way: • Weekly planning. * Planning state changes during the week. • Duration programming. * Programming a maximum production duration. •...
Page 53: 2) Duration Programming
To change an element of the action (for ex. the time), click on the time box of the line to be modiﬁ ed. Once the actions have been set, you must conﬁ rm them by clicking on in order to save the modiﬁ...
Page 54: Maintenance Instructions
4) MAINTENANCE INSTRUCTIONS For further information on the system please see the Operating Instructions. 4.1) T Eﬀ ects on Indicators, display Defect Protections Solutions tooling Decrease in Thermocouple Low temperature - Remedy the cut by testing the applied power cut. alarm activated.
Page 55 Eﬀ ects on Indicators, display Defect Protections Solutions tooling Real Real temperature display is Temperature High and low - Material problem. temperature is unstable, oscillations. temperature alarms - Mold problem. unstable activated. - Check zone crossing with the Moldscan function §3.2.4.1 symbols may appear on the screen and the status bar...
Page 56 Eﬀ ects on Indicators, display Defect Protections Solutions tooling Defective load "Load fault" alarm - Check connections. temperature activated. - Change the heater. does not symbol increase appears and the status bar blinks red. Abnormal Material "Power monitoring" - Check the mold applied power inﬁ...
