Lambrecht sun[e] 00.16130.501030 Manual

Next level digital secondary standard pyranometer
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Manual
sun[e]
00.16130.501030
Next level digital secondary standard pyranometer
compliant with IEC
61724-1:2017 Class A

Advertisement

Table of Contents
loading

Related Manuals for Lambrecht sun[e] 00.16130.501030

Summary of Contents for Lambrecht sun[e] 00.16130.501030

  • Page 1 Manual sun[e] 00.16130.501030 Next level digital secondary standard pyranometer compliant with IEC 61724-1:2017 Class A...

  • Page 2: Safety Instructions And Warranty

    Please note the loss that unauthorised manipulation of the system shall result in the loss of warranty and non-liability. Changes to system components require express written permission from LAMBRECHT meteo GmbH. These activities must be performed by a qualified technician. The warranty does not cover: 1.

  • Page 3: Table Of Contents

    Measured value and parameter register Sensor parameters / configuration-parameters Network communication: getting started Adapting the Modbus address and communication settings Maintenance and trouble shooting Recommended maintenance and quality assurance Trouble shooting Appendices LAMBRECHT meteo – Auto-configuration EU declaration of conformity...

  • Page 4: Introduction

    Introduction Welcome to the next level in solar radiation monitoring! The all-digital sun[e] pyranometer offers the highest accuracy and highest data availability: using new Recirculating Ventilation and Heating (RVH ) technology, sun[e] outperforms all pyranometers equipped with traditional ventilation systems. sun[e] is the ideal instrument for use in PV system performance monitoring and meteorological networks.
  • Page 5 • supported by an efficient calibration and maintenance organisation. LAMBRECHT meteo and Hukseflux offers local support in the main global economies: USA, EU, China, India, Japan and Brazil. Recalibration is recommended every 2 years, which is good practice in the industry.

  • Page 6: Ordering And Checking At Delivery

    1 Ordering and checking at delivery 1.1 Ordering sun[e] Id-No. for standard configurations sun[e]: Version 00.16130.501030: digital ISO 9060 secondary standard pyranometer sensor with Modbus over RS-485 Common options / accessories are: • cable 5m, M12 plug connector Id-No. 32.14567.060030 •...

  • Page 7: Instrument Schematic

    2 Instrument schematic sun[e]’s scientific name is pyranometer. A pyranometer measures the solar radiation received by a plane surface from a 180 ° field of view angle. This quantity, expressed in W/m , is called “hemispherical” solar radiation. The solar radiation spectrum extends roughly from 285 to 3000 x 10 m.

  • Page 8: Specifications Of Sun[E]

    3 Specifications of sun[e] 3.1 Specifications of sun[e] sun[e] measures the solar radiation received by a plane surface from a 180 field of view angle. This quantity, expressed in W/m , is called “hemispherical” solar radiation. sun[e] offers irradiance in W/m as a digital output.
  • Page 9 sun[e] ADDITIONAL SPECIFICATIONS Measurand hemispherical solar radiation Measurand in SI radiometry units irradiance in W/m Optional measurand sunshine duration Field of view angle 180 ° Technology employed Recirculating Ventilation and Heating (RVH Heating included Ventilation included Output definition running average over 4 measurements, refreshed every 0.1 s Recommended data request interval 1 s, storing 60 s averages IEC 61724-1:2017 COMPLIANCE...
  • Page 10 LOW POWER OPERATING MODE Operating condition heater [OFF] and ventilator [OFF] Zero offset a 5 W/m Supply voltage range 5 to 30 VDC Power consumption < 0.1 W CALIBRATION Calibration traceability to WRR Calibration hierarchy from WRR through ISO 9846 and ISO 9847, applying a correction to reference conditions Calibration method indoor calibration according to ISO 9847, Type IIc...

  • Page 11: Dimensions Of Sun[E]

    3.2 Dimensions of sun[e] M5 (2x) Ø 68 Figure 3.2.1 Dimensions of sun[e] in x 10...

  • Page 12: Installation Of Sun[E]

    4 Installation of sun[e] 4.1 Site selection and installation Table 4.1.1 Recommendations for installation of pyranometers Location The horizon should be as free from obstacles as possible. Ideally, there should be no objects between the course of the sun and the instrument. Mechanical mounting / thermal insulation Use connection by bolts to the bottom plate of the instrument.

  • Page 13: Installation Of The Sun Screen

    4.2 Installation of the sun screen The quick release system of sun[e]’s sun screen allows for easy and secure mounting of the sun screen on the sensor. Installation and removal of the connector can be done after removal of the sun screen.

  • Page 14: Installation Of Pyranometer

    4.3 Installation of pyranometer LAMBRECHT meteo provides several mounting set for the sun[e] pyranometer. Id-No. 32.14627.003010 Set for inclined mounting on traverse system 14627 Id-No. 32.14627.003000 Set for horizontal mounting on traverse system 14627 Id-No. 33.14627.012000 Set for wall mounting The picture below shows the installation of the sun[e] on the “Set for inclined mounting”...

  • Page 15: Electrical Connection Of Sun[E]: Wiring Diagram

    4.4 Electrical connection of sun[e]: wiring diagram The instrument must be powered by an external power supply, providing an operating voltage in the range from 8 to 30 VDC. This is the main power supply for the sensor, using the brown and white wires.
  • Page 16 cable. To minimise noise on the network when no transmission is occurring, a pull up and pull down resistor are required. Typical values for both resistors are in the range from 650 to 850 Ω. shield shield not connected grey [+] 8 to 30 VDC brown [ - ] 8 to 30 VDC...

  • Page 17: Communication With Sun[E]

    "most significant byte" is sent first. For values that go beyond one register (e.g. 32 bit) this is not clearly specified for the Modbus. In these cases (32 bit or 64 bit) the LAMBRECHT Modbus sensors follow the big-endian number format. Example Big-Endian: Register size value 16 - Bits 0x1234 is transmitted in the order: 0x12 0x34.

  • Page 18: Modbus Command Set

    Write Multiple Register" command: 0x10 (Write sensor data) 5.6 Measured value and parameter register The Lambrecht meteo Modbus provide in the register range 30001 to the measured values. The registers Addresses 30001 to 35000 apply to all Lambrecht meteo Modbus sensors, but are only available or valid if the respective sensor supports the corresponding values (e.g.

  • Page 19: Sensor Parameters / Configuration-Parameters

    5.7 Sensor parameters / configuration-parameters Table 5.7.1 Configuration registers Register Parameter name Unit Divisor Description address 40001 Modbus device address The addresses 1...247 are allowed. 40200 Baud rate 0,01 96=9600 192=19200 384=38400 46000 Number of mapping-registers* Contains the number of occupied mapping registers for the auto- configuration sun[e] = 8...

  • Page 20: Network Communication: Getting Started

    Network communication: getting started Once it has the correct Modbus address and communication settings, sun[e] can be connected directly to an RS-485 network and a power supply. Installing a sun[e] in the network also requires configuring the communication for this new Modbus device.

  • Page 21: Maintenance And Trouble Shooting

    6 Maintenance and trouble shooting 6.1 Recommended maintenance and quality assurance sun[e] can measure reliably at a low level of maintenance in most locations. Usually unreliable measurements will be detected as unreasonably large or small measured values. As a general rule this means that regular visual inspection combined with a critical review of the measured data, preferably checking against other measurements, is the preferred way to obtain a reliable measurement.

  • Page 22: Trouble Shooting

    6.2 Trouble shooting Table 6.2.1 Trouble shooting for sun[e] General Inspect the instrument for any damage. Inspect if the connector is properly attached. Check the condition of the connectors (on chassis as well as the cable). Inspect if the sensor receives DC voltage power in the range of 8 to 30 VDC. Inspect the connection of the shield (typically not connected at the network side).

  • Page 23: Appendices

    = 8 Since the addresses from the range 30001 to 35000 apply to all Lambrecht sensors, an address from this range is also representative of a measured value type. For example, register 30401 always contains the current value of the air temperature. If this register address is not included in the list in register range 46001 to 49000, the connected Modbus sensor does not supply an air temperature.
  • Page 24 Table 7.1.2 Standard registers for auto-configuration Register Parameter name Unit Factor Description Data Func- Storage-type address type tion- >16 bit code 30001 Wind speed instantaneous 10 1 decimal place 0x04 Big-Endian value WORD 30201 Wind direction ° 10 1 decimal place 0x04 Big-Endian instantaneous value...
  • Page 25 For example, in the sun[e], registers 46001 to 46008 contain valid addresses. The holding register 46000 contains the number of registers “8”, all 8 registers must be read out in the block with the function code 0x04. Too many registers or too few lead to an error message. Table 7.1.3 Mapping-Register for auto-configuration Register Register...

  • Page 26: Eu Declaration Of Conformity

    7.2 EU declaration of conformity LAMBRECHT meteo GmbH. Friedlaender Weg 65-67 37085 Goettingen Germany in accordance with the requirements of the following directive: 2014/30/EU The Electromagnetic Compatibility Directive hereby declare under our sole responsibility that: Product model: sun[e] Product type:...
