Foundations Child Craft GUARD RAIL 9524 Assembly Directions And Parts List

• 5216 Portside Dr., Medina, OH 44256 USA • PH: 1 330.722.5033 • FAX: 1 330.722.5037
ASSEMBLY DIRECTIONS AND PARTS LIST
BEFORE STARTING THE ASSEMBLY PROCEDURE, READ ALL DIRECTIONS WITH CARE.
This model contains both metric and imperial hardware.
The enclosed hardware contains (2) types of Allen Head Bolts (B) and Joint Connector Nut (C). The
crib models listed below will use the imperial thread (1/4-20) type. All other models will use a metric
date of manufacturer before proceeding to establish which hardware type is designed for your crib.
This information will be printed on a label attached to your crib. Once the model number and date of
manufacturer is established, refer to the following list. If your model number is listed below, or if your
crib was manufactured before January 1, 2012, use the hardware contained in the bag which has the
printed warning on that bag. All other models will use the second metric type. Also use the enclosed
Allen Wrenches (A) with either version. Discard the second set of (B) and (C) which is not used.
Core Crib Model Number
F10031.XX
Cribs designed for this guard rail manufactured before 01-01-2012
PARTS ENCLOSED IN METRIC HARDWARE BAG
A
(2) Allen Wrench
PARTS ENCLOSED IN IMPERIAL THREAD HARDWARE BAG
B
(4) Allenhead Bolts
IMPERIAL THREAD (1/4-20)
YY
Allenhead Bolts
NOTE: These bolts came with your crib. Refer to crib assembly instruction manual under section
the attached instructions and diagrams while assembling the guard rail.
Division of Foundations
www.childcraftbaby.com
WARNING
Read carefully before proceeding.
B
(4) Allenhead Bolts
METRIC (6 mm)
ITEMS THAT CAME WITH YOUR CRIB
Worldwide, Inc.
®
Finish Color Code
XX will be any number from 00 to 99
C
C
(4) Joint Connector Nut
IMPERIAL THREAD (1/4-20)
1
GUARD RAIL
9524
(4) Joint Connector Nut
METRIC (6 mm)
SI642H
