- Page 1 ET137006M0002/00 INSTRUCTION MANUAL JIG BASE ...
- Page 2 Safety precaution are classified into five categories Death or serious injury may result from misusing the product without following the instructions. Minor injury, as well as damage to the product may result from misusing the product without following the instructions. Bad influence on test result may result from misusing the product without following the instructions.
- Page 3 - CONTENTS - 1. OVERVIEW 1.1COMPONENTS ···································································· 1-1 1.2 INSTALLATION ·································································· 1-2 4. MAINTENANCE ········································································ 4-1...
- Page 4 1.OVERVIEW Jig Base use when endurance test in environment chamber with DR11MR (driving unit) and the clamshell type testing jig. 1.1 STRUCTURE and COMPONENTS ２ １ ３ MANUFACTURE № NAME TYPE Qty. NOTE (MATERIAL) Jig Base ET137006A0002 YUASA SYSTEM Coupling (Disk type)
- Page 5 1.2 INSTALLATION [ Tool:13 mm / 19 mm Spanner, 5 mm Allen wrench] 1 ） Put the jig base into chamber. Chamber which installation Side Position Adjustment Bolt Tighten the nut Rotate to adjust after adjustment. the adjustment bolts. (Height and Side)
- Page 6 2 ） Adjust the jig base position using by the height adjustment bolt and side position adjustment bolt to the state shown in the figure dimension. Must adjust the jig base height at first, next adjust the side position. (Using each adjustment bolts) Refer dimension from access hole for chamber for the Jig base position.
- Page 7 5 ） Locate the testing jig position to the state shown in the under figure dimension. Tighten fixing bolt for testing jig after setting the jig. Confirm to be coaxial the axis for testing jig and access hole for chamber. Fixing bolt tightening torque ：...
- Page 8 6 ） Joint the driving unit and testing jig after attach coupling to the driving unit. Should prepare the table separately to put the driving unit. Tightening torque ： 12 N ･ m (using 5 mm Allen wrench) * Do not over tighten the hexagonal bolt to break. Confirm the coupling to slide smoothly on joint shaft and shaft for the driving unit before tightening a bolt in coupling.
- Page 9 【MEMO】...
- Page 10 4 Maintenance This Jig is maintenance-free. Change to the new one if some components will go bad or break because of using condition or requirement. If change to the new one if some components will break because of using condition or aging, please contact the sales agent.
- Page 11 【MEMO】 ...
