Plum MacBAT 5 User Manual
  1. Manuals
  2. Brands
  3. Plum Manuals
  4. Media Converter
  5. MacBAT 5
  6. User manual

Plum MacBAT 5 User Manual

Electronic volume converter
Hide thumbs

Advertisement

Quick Links

Download this manual
MacBAT 5
Electronic Volume Converter
USER GUIDE
DOCUMENT REVISION: 1.0
VALID FOR FIRMWARE:
VERSION: V061615
SERIES: S007.12
HARDWARE: H1.3.0.
This User Guide document is only an annex to the main document
"MacBAT 5 User manual".
Implicitly read the user manual, where all necessary information, also
information regarding safety, are included. User Guide is only a
supporting document, includes only selected information, useful
during device installation, configuration and maintenance.
