  • Page 1 GPI-8941 Series User Guide...
  • Page 2 Ross has become well known for the Ross Video Code of Ethics. It guides our interactions and empowers our employees. I hope you enjoy reading it below. If anything at all with your Ross experience does not live up to your expectations be sure to reach out to us at solutions@rossvideo.com.
  • Page 3 Ross Video. While every precaution has been taken in the preparation of this document, Ross Video assumes no responsibility for errors or omissions. Neither is any liability assumed for damages resulting from the use of the information contained herein.
  • Page 4 Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense. Notice — Changes or modifications to this equipment not expressly approved by Ross Video Ltd. could void the user’s authority to operate this equipment. Canada This Class “A”...
  • Page 5 To avoid the potential release of those substances into the environment and to diminish the need for the extraction of natural resources, Ross Video encourages you to use the appropriate take-back systems. These systems will reuse or recycle most of the materials from your end-of-life equipment in an environmentally friendly and health conscious manner.

  • Page 7: Table Of Contents

    Contents Introduction Related Publications ............................... 11 Documentation Conventions ..........................11 Interface Elements ............................... 11 User Entered Text ............................... 12 Referenced Guides .............................. 12 Menu Sequences ..............................12 Important Instructions ............................12 Contacting Technical Support ..........................12 Before You Begin Features .................................. 13 Workflow Diagram ..............................
  • Page 8 DashBoard Interfaces Overview ..........................36 Basic Configuration Before You Begin ..............................37 Assigning an IP Address to the Card ........................37 Setting up the Reference ............................38 Selecting a Reference Source ..........................38 Setting up the Vertical Reference Timing Window ....................39 Setting up Remote Control Specifying the Protocol for an Output ........................41 Enabling the GPI-8941 for the GPI485 Serial Protocol ..................42 Specifying a Group Number ..........................43...
  • Page 9 RossTalk Protocol Before You Begin ..............................73 Examples ................................73 Sessions .................................. 74 Sample Session 1 ..............................74 Sample Session 2 ..............................76 Module ID and Capabilities ........................... 77 Session Control ..............................78 Message Auto-Response Control ........................78 Verbose Message Control ........................... 79 GPI Index Base Control ............................
  • Page 10 iv • Contents GPI-8941 Series User Guide (v9.0)

  • Page 11: Introduction

    • “Glossary”provides a list of terms used throughout this guide. Related Publications It is recommended to consult the following Ross documentation before installing and configuring your GPI-8941: • DashBoard User Guide, Ross Part Number: 8351DR-004 • OGX-FR Series Quick Start Guide, Ross Part Number: 8322DR-202 •...

  • Page 12: User Entered Text

    IP Address, Subnet Mask, and Gateway for your device. Contacting Technical Support At Ross Video, we take pride in the quality of our products, but if problems occur, help is as close as the nearest telephone.

  • Page 13: Before You Begin • 13

    Before You Begin The GPI-8941 cards provide an interface between openGear agents, such as DashBoard, and hardware devices that communication via the General Purpose Interface (GPI). Some devices produce outputs (GPI outputs) that are intended to either control other devices or signal their own status. When these signals are connected to inputs (GPI inputs) on the rear module, the card communicates the state of the GPIs via the openGear protocol (OGP) to DashBoard.

  • Page 14: Input Circuit Diagrams

    Serial Port RossTalk Protocol GPI485 via TCP/IP Protocol DashBoard Control Daughter Card 2 Daughter Card 1 16 Channels Input 16 Channels Input 16 Channels Output 16 Channels Output GPI-8941 Rear Module Figure 2.1 Simplified Workflow Diagram Input Circuit Diagrams This section provides simplified input circuit diagrams for the GPI-8941. Figure 2.2 provides a simplified circuit diagram for isolated inputs.

  • Page 15: Output Circuit Diagrams

    Output Circuit Diagrams This section provides simplified output circuit diagrams for the GPI-8941. Figure 2.4 provides a simplified circuit diagram for contact closure outputs. 0.5A FROM OUTPUT REAR MODULE CARD CIRCUIT Figure 2.4 Simplified Circuit Diagram — Contact Closure Outputs Figure 2.5 provides a simplified circuit diagram for voltage source outputs.
  • Page 16 16 • Before You Begin GPI-8941 Series User Guide (v9.0)

  • Page 17: Hardware Overview

    Bootload Button This button for factory service in the unlikely event of a complete card failure. Do not press this button unless instructed to do so by Ross Technical Support personnel. Control and Monitoring Features This section provides information on the card-edge LEDs for the card. Refer to Figure 3.2 for the location of the LEDs and controls.

  • Page 18: Status And Selection Leds

    Depending on the card model, the pins may be allocated for GPI inputs, GPI outputs, or a combination.  Ensure to use only the supplied back-shells (Ross part number 30-01038) with a back-shell maximum thickness of 0.645" (16.4mm). 18 • Hardware Overview...
  • Page 19 For More Information on... • the number of GPI inputs and outputs for your card, refer to Table 2.1. • cabling the GPI inputs and outputs, refer to the chapter “GPIO Cabling” on page 23. • reference cabling, refer to the chapter “Reference Cabling” on page 31. •...
  • Page 20 20 • Hardware Overview GPI-8941 Series User Guide (v9.0)

  • Page 21: Physical Installation

    Physical Installation If you have questions pertaining to the installation of GPI-8941, please contact us at the numbers listed in the section “Contacting Technical Support”. Our technical staff is always available for consultation, training, or service. Caution — The DFR-8310 series, the DFR-8320 series, and the DFR-8321 series frames do not support the GPI-8941 cards.

  • Page 22: Installing The Gpi-8941 Card Into A Frame

    Installing the GPI-8941 Card into a Frame The slot the GPI-8941 installs into depends on the slot combination you installed the rear module in. This allows adequate spacing to avoid damaging the card, the cards installed in the neighboring slots, or both. Refer to Table 4.1 for valid slot combinations when using the 8323AR-325 rear module.

  • Page 23: Gpio Cabling

    GPIO Cabling This chapter outlines the GPI input and output cabling designations for the GPI-8941. Overview The general purpose interface (GPI) connectors are male 37-pin DC sub-miniature connectors with 4-40 jack-screws for mating connector locking. Inputs There are two types of GPI inputs: isolated (dry) and pull-to-ground (wet). •...
  • Page 24 Figure 5.1 illustrates the left DC-37 connector on the rear module. This connector is always GPI 1-16 and is labeled as Expansion 1 (input or output) in the DashBoard > Product tab. Figure 5.1 Left Connector Figure 5.2 illustrates the pinouts for the right DC-37 connector on the rear module. This connector is always GPI 17-32 and is labeled as Expansion 2 (none, input, or output) in the DashBoard >...

  • Page 25: Gpi-8941-I16 Pinouts

    GPI-8941-I16 Pinouts Left Connector Input Function Right Connector Input Function - Not Connect GPI 1-16 Expansion 1 GPI 17-32 Expansion 2 - No Connect Pull-to-Ground Isolated Isolated Pull-to-Ground Pull-to-Ground Isolated Isolated Pull-to-Ground Chassis GND Chassis GND Chassis GND Chassis GND Circuit GND Circuit GND Circuit GND...

  • Page 26: Gpi-8941-I32 Pinouts

    GPI-8941-I32 Pinouts Left Connector Input Function Right Connector Input Function GPI 1-16 Expansion 1 GPI 17-32 Expansion 2 Pull-to-Ground Isolated Isolated Pull-to-Ground Pull-to-Ground Isolated Isolated Pull-to-Ground Chassis GND Chassis GND Chassis GND Chassis GND Circuit GND Circuit GND Circuit GND Circuit GND Input 1A Input 1+...

  • Page 27: Gpi-8941-O16 Pinouts

    GPI-8941-O16 Pinouts Left Connector Output Function Right Connector Output Function - No Connect GPI 1-16 Expansion 1 GPI 17-32 Expansion 2 - No Connect Contact Contact Contact Contact Voltage Source Voltage Source Voltage Source Voltage Source Closure Closure Closure Closure Chassis GND Chassis GND Chassis GND...

  • Page 28: Gpi-8941-O32 Pinouts

    GPI-8941-O32 Pinouts Left Connector Output Function Right Connector Output Function GPI 1-16 Expansion 1 GPI 17-32 Expansion 2 Contact Contact Contact Contact Voltage Source Voltage Source Voltage Source Voltage Source Closure Closure Closure Closure Chassis GND Chassis GND Chassis GND Chassis GND Circuit GND Circuit GND...

  • Page 29: Gpi-8941-I16-O16 Pinouts

    GPI-8941-I16-O16 Pinouts Left Connector Input Function Right Connector Output Function GPI 1-16 Expansion 1 GPI 17-32 Expansion 2 Contact Contact Isolated Pull-to-Ground Pull-to-Ground Isolated Voltage Source Voltage Source Closure Closure Chassis GND Chassis GND Chassis GND Chassis GND Circuit GND Circuit GND Circuit GND Circuit GND...
  • Page 30 30 • GPIO Cabling GPI-8941 Series User Guide (v9.0)

  • Page 31: Reference Cabling

    • the reference inputs on the openGear frame, refer to its user guide. Reference Cabling Connect a reference source to the REF1 or REF 2 BNCs on the openGear frame. Refer to Figure 6.1 for BNC locations. Ross Video does not supply this cable. OGX-FR Series Frame REF 1...
  • Page 32 32 • Reference Cabling GPI-8941 Series User Guide (v9.0)

  • Page 33: Serial Cabling

    Serial Cabling The Serial adapter port on the rear module provides an RS-485 connection. The port supports the Image Video™ GPI485 serial protocol for control and status reporting. Refer to the user manual for your external device for the specific pinout information and the required port to use. For More Information on...

  • Page 34: Serial Interface Cable

    Serial Interface Cable The serial interface cable (Ross P/N 8941CR-100) with a DE-9 female connector on one end and a 8-pin serial adapter (female) connection on the other end. OGX-FR Series Frame REF 1 LOOP REF 2 ETHERNET LOOP Serial Interface Cable To External Serial Device Figure 7.2 Example —...

  • Page 35: Using Dashboard

    Before You Begin Before proceeding, ensure that DashBoard software version 6.2.0 or higher is installed on a PC connected to your facility network. The DashBoard software and user manual are available from the Ross Video website. For More Information on...

  • Page 36: Dashboard Interfaces Overview

    DashBoard Interfaces Overview You configure your GPI-8941 card using the DashBoard application, which is available from our website. The DashBoard user manual can also be downloaded from our website. The GPI-8941 user interface is depicted below. It is divided into a status panel on the left, and a configuration panel on the right.

  • Page 37: Basic Configuration

    Basic Configuration This chapter provides instructions for configuring the GPI-8941 using the options available in DashBoard.  This chapter assumes that DashBoard is launched on your computer and the GPI-8941 interface displays in the right-side of the DashBoard window. Before You Begin Verify or note the following before configuring your GPI-8941 card: •...

  • Page 38: Setting Up The Reference

    Enter the IP Address, Subnet Mask, and Default Gateway settings for the card. c. Ross Video recommends using a static IP Address. If you want the network settings to be automatically obtained and your facility has a DHCP server, select DHCP for the Addressing Mode.

  • Page 39: Setting Up The Vertical Reference Timing Window

    Select a reference source from the Reference Input menu. The Reference Type status field on the Config tab updates when a valid reference signal is detected. Setting up the Vertical Reference Timing Window The vertical reference is used to synchronize an output change timing window. Once you have selected the reference source, use the Timing Window options in DashBoard to specify the start and end of the timing window.
  • Page 40 Use the Stop Line field to specify the line in the video signal that marks the end of the timing window. Use the Fields menu to specify which fields the timing window will apply to. If you are using a progressive format signal, this menu is not applicable.

  • Page 41: Setting Up Remote Control

    Setting up Remote Control This chapter outlines how to specifying the communication protocol for a GPI output, and to set up communications on the Serial or Ethernet port. Specifying the Protocol for an Output Each GPI Output can be configured to use or exclude the supported communication protocols. ...

  • Page 42: Enabling The Gpi-8941 For The Gpi485 Serial Protocol

    Use the Serial Control menu to enable a serial command to change the state of the GPI output connection (Allowed) or not (Not Allowed). Repeat steps 1 to 5 for each GPI output connection you want to configure. Enabling the GPI-8941 for the GPI485 Serial Protocol Each card includes an RS-485 serial port interface on the rear module.

  • Page 43: Specifying A Group Number

    Specifying a Group Number The GPI485 serial protocol organizes all GPIs into groups of 8 up to a total of 64 groups. Table 10.1 outlines the number of groups each card model supports. Table 10.1 Groups Based on the Card Model Card Model Number of Groups GPI-8941-I16...
  • Page 44 Select the RossTalk Client 1 tab located at the bottom of the Remote Control Setup tab. Use the IP Address field to specify the IP Address of the external device to send the RossTalk message to. Use the TCP Port field to specify the port the external device connects to. Click Test Connection to open and close a connection to the external device without sending any messages.

  • Page 45: Setting Up Communications For A Rosstalk Server

    Setting up Communications for a RossTalk Server The section is applicable if the GPI-8941 card needs to open a TCP port for a RossTalk server. To communicate with a server via RossTalk From the Tree View, select the node for the GPI-8941 you want to configure. Select the Remote Control Setup tab.
  • Page 46 Select the Product tab. Verify that the Software Rev field reports a version of 2.92 or higher. In the example provide in 3, the card reports a version of 3.00. Verify the Default Port Speed for the GPI-8941Card Ensure that the Default Port Speed for the GPI-8941 card is set to 100Mb/s on the MFC-OG3-N or MFC-OGX-N. To verify the Default Port Speed for the GPI-8941 card Display the MFC-OG3-N or MFC-OGX-N window as outlined in steps 1 to 3 of the procedure “To verify the MFC-OG3-N or MFC-OGX-N software version”...
  • Page 47 Verify that the GPI-8941 Card is Available on the Network Ping the GPI-8941 card using the Command Prompt function of your DashBoard client computer. Refer to the documentation for your client computer for details on using the Command Prompt. Verify the GPI-8941 RossTalk Client is Configured Correctly Ensure that the GPI-8941 RossTalk client is configured correctly for your system.

  • Page 48: Setting Up Communications Via The Gpinet Protocol

    Setting up Communications via the GPInet Protocol This section is applicable when the GPI-8941 card will use the Image Video™ ethernet protocol for control and status reporting. To enable GPInet Ethernet communications for the card From the Tree View, select the node for the GPI-8941 card you want to configure. Select the Remote Control Setup tab.

  • Page 49: Configuring The Gpi Inputs

    Configuring the GPI Inputs This chapter applies if you have the following cards: • GPI-8941-I16 • GPI-8941-I32 • GPI-8941-I16-O16 Configuring a GPI Input The number of GPI Inputs displayed in the GPI Input Setup tab depends on the card model you are using. The examples in this section feature the GPI-8941-I32 and the number of GPIs on your card may differ from what is presented here.
  • Page 50 Use the Toggle menu to specify how the GPI Input will assert. Choose from the following: • No Toggle — Select when you want to assert a particular state for a GPI Input where High is ON and Low is OFF.

  • Page 51: Configuring The Gpi Outputs

    Configuring the GPI Outputs This chapter applies if you have the following cards: • GPI-8941-O16 • GPI-8941-O32 • GPI-8941-I16-O16 Configuring the GPI Outputs The number of GPI Outputs displayed in the GPI Output Setup tab depends on the card model you are using. The examples in this section feature the GPI-8941-O32 and the number of outputs on your card may differ from what is presented here.
  • Page 52 Use the Type menu to specify whether the circuit is Wet or Dry. Choose from the following: • Contact Closure — When the output is on the output pins are connected together by a pair of relay contacts. When the output is off the output pins are not connected. The output pins are isolated from the card circuit. (Dry) •...

  • Page 53: Monitoring

    Monitoring You can enable the GPI-8941 card to generate reports on the status of each GPI. Use the settings in the Report tab to control how or if the status messages are sent to the external devices. Monitoring the GPI Input Status Reports can be generated on the RossTalk commands, or Serial commands.

  • Page 54: Monitoring The Gpi Output Status

    Monitoring the GPI Output Status The GPI-8941 card handles all GPI Output commands in the order received. The card reports status to all active connections. A report can be generated, for each GPI output, detailing the commands sent via the GPI output connection on the rear module.

  • Page 55: Software Upgrades

    The DashBoard client enables you to upload software updates to the card. To upload software to the card Contact Ross Technical Support for the latest software version file. In DashBoard, display the Device tab of the card by double-clicking its status indicator in the Basic Tree View.
  • Page 56 56 • Software Upgrades GPI-8941 User Guide (v9.0)

  • Page 57: Dashboard Menus

     Before proceeding, ensure that you are running DashBoard software version 6.2.0 or higher. The DashBoard software and user manual are available to download from the Ross Video website. Status Tabs This section summarizes the read-only information displayed in the Status tabs. The fields in the Status tabs vary in severity from green (valid), yellow (caution), to red (alarm).

  • Page 58: Network Tab

    Table 15.2 Hardware Tab Items Item Parameters Description Uptime (h) Indicates the number of hours since the last reboot of the card Configuration Increments each time the card settings are saved to Bank non-volatile memory Network Tab Table 15.3 summarizes the read-only information displayed in the Network tab. Table 15.3 Network Tab Items Item Parameters...

  • Page 59: Config Tab

    Config Tab Table 15.4 summarizes the sub-tabs available in the Config tab. Table 15.4 Config Tab Items Item Parameters Description Vertical Reference Selection No reference input signal is supplied to the card Reference Input Frame 1* The GPI-8941 card uses the reference signal available via the REF 1 port on the openGear frame Frame 2 The GPI-8941 card uses the reference signal available...

  • Page 60: Network Setup Tab

    Default Values Table 15.5 lists the default values for the video formats listed in the Timing Window Setup area of the Config tab. Table 15.5 Config Menu Default Values — Based on Type Type Start Line Stop Line Fields NTSC Both Both 1080i...
  • Page 61 Table 15.7 RossTalk Client Menu Items Item Parameter Description IP Address #.#.#.# Specifies the IP Address of the external device the card will send messages to TCP Port Specifies the TCP port number of the external device the card will send messages to Test Connection Sends a test message to the external device located at the specified IP Address...

  • Page 62: Rosstalk Server Tab

    Table 15.7 RossTalk Client Menu Items Item Parameter Description GPI Message no message No message is sent even if this GPI is active. This is the default. GPI On Trigger A message is sent, as configured in the Message Setup area, to the external device when the specified GPI is triggered GPI Off Trigger...

  • Page 63: Gpinet Tab

    GPInet Tab Table 15.9 summarizes the options available in the GPInet tab. Table 15.9 GPInet Menu Items Item Parameters Description Enable Selected Enables the use of GPInet protocol to control the card Cleared* Disables the use of GPInet protocol to control the card UDP Port Specifies the UDP port number that remote devices will connect to when using GPInet protocol...

  • Page 64: Gpi Input Setup Tab

    Table 15.10 Serial I/O Port Menu Items Item Parameter Description Parity None* Sets the Parity type EVEN Stop Bits Sets the number of stop bits transmission Tx Driver Control Selected The serial transmit driver is enabled only when the card is sending serial data and is disabled at all other times.

  • Page 65: Setup Tab

     The GPI Input Setup tab menus are only available when using a card model that provides GPI inputs. Setup Tab Table 15.11 summarizes the menu options in the Setup sub-tab of the GPI Input Setup tab. Table 15.11 Setup Menu Items Item Parameters Description...

  • Page 66: Gpi Output Setup Tab

    Table 15.12 Report Menu Items Item Parameters Description GPI # Conn (read-only) Indicates the input pair on the rear module. For example indicates Pair 12 on the second connector of Con 2-12 the rear module. State (read-only) Indicates the specified GPI is not active Indicates the specified GPI is active RossTalk Report No Reports...

  • Page 67: Report Tab

    Table 15.13 Setup Menu Items Item Parameters Description Polarity Normal Sets the polarity of the output. Normal polarity has a Low-to-High transition starting the pulse. Inverted Sets the polarity of the output. Inverted polarity has a High to Low transition starting the pulse. Power Up State Set the specified GPI output to OFF after a card power cycle...

  • Page 68: Control Tab

    Table 15.14 Report Menu Items Item Parameters Description RossTalk Report No Reports No RossTalk reports are generated for this GPI Report Both Edges When the GPI output state is changed, a RossTalk report is sent Leading Edge Only When the specified GPI output transitions form Low to High a RossTalk report is sent Trailing Edge Only When the specified GPI output transitions from High to...
  • Page 69 Table 15.15 Control Menu Items Item Parameters Description RossTalk Control Not Allowed The specified GPI Output ignores RossTalk commands Allowed The specified GPI Output acts on RossTalk commands GPInet Control Not Allowed The specified GPI Output ignores GPInet commands Allowed The specified GPI Output acts on GPInet commands Serial Control Not Allowed...
  • Page 70 70 • DashBoard Menus GPI-8941 Series User Guide (v9.0)

  • Page 71: Technical Specifications

    Technical Specifications This chapter provides technical information for GPI-8941.  Specifications are subject to change without notice. GPI Input Specifications Table 16.1 Technical Specifications — GPI Inputs Item Specifications Isolated Input 3mA max @ 4-30VDC Input Pull to Ground • +5V supplied by the card •...
  • Page 72 72 • Technical Specifications GPI-8941 Series User Guide (v9.0)

  • Page 73: Rosstalk Protocol

    RossTalk Protocol The GPI-8941 can be controlled from a remote editor or computer via RossTalk commands. These commands can be sent to these openGear cards over an Ethernet connection (TCP/UDP) or via a serial port (RS-232/RS-485) on the card’s rear module. This chapter provides additional information on the RossTalk protocol used with the GPI-8941.

  • Page 74: Sessions

    Commands and parameters can be mixed using both verbose and terse forms. Thus the following are all equivalent: Command: GPI ModuleQuery : AllInfo GPI ModuleQuery : A GPI ModuleQuery :a gpi modulequery:a Response: GPI ModuleStatus:Type:GPI-8941 GPI ModuleStatus:Inputs:16 GPI ModuleStatus:Outputs:16 As the response is configured via the Verbose command, it will respond to terse commands with a verbose response. Sessions Up to 7 RossTalk sessions can take place concurrently, each with its own unique configuration and GPI reporting control setup.
  • Page 75 Command Response Notes GPI 1:0:Config:None:Detailed Card replies for each GPI, it will not be sending a report on changes to this session. GPI 2:0:Config:None:Detailed GPI 3:0:Config:None:Detailed GPI 4:0:Config:None:Detailed GPI 5:0:Config:None:Detailed GPI 6:0:Config:None:Detailed GPI 7:0:Config:None:Detailed GPI 8:0:Config:None:Detailed GPI 9:0:Config:None:Detailed GPI 10:0:Config:None:Detailed GPI 11:0:Config:None:Detailed GPI 12:0:Config:None:Detailed GPI 13:0:Config:None:Detailed...

  • Page 76: Sample Session 2

    Command Response Notes GPI 17:off:Event Card reports that GPI 17 has had an event, this is the trailing edge GPI 1:off:Event Card reports that GPI 1 has had an event. This input is now inactive/low. Sample Session 2 Session assumes that we want to know when GPI 1, 2, and 3 (inputs) go active and controls GPI 17, 18, and 19 (outputs).

  • Page 77: Module Id And Capabilities

    Command Response Notes GPI 19:1:C Card replies GPI 19 is on. No configuration response since auto-response is off. GPI 19:0 Set GPI 19 inactive / low GPI 19:0:E Card reports GPI 19 has had an event, this is the trailing edge Module ID and Capabilities These commands and responses allow the capabilities of the module to be queried.

  • Page 78: Session Control

    Response: GPI ModuleStatus:Type:GPI-8941 GPI ModuleStatus:Inputs:16 GPI ModuleStatus:Outputs:16 Get the module type using mixed verbose and terse. Verbose message return is off. Command: GPI modulequery: t Response: GPI M:T:GPI-8941 Session Control These commands and responses allow the session characteristics to be set up and queried. Message Auto-Response Control This command controls whether an automatic response is sent after configuration messages.

  • Page 79: Verbose Message Control

    Turn auto-response on. Command: GPI S:A:1 (terse format) GPI SessionConfig : AutoResposne : On (verbose format) Response: GPI SessionStatus:AutoResponse:on Get the current session auto-response setting. Verbose message return is on. Command: GPI s:v:? Response: GPI SessionStatus:AutoResponse:on Verbose Message Control This command controls whether response messages use terse or verbose parameters. A response to this configuration command is sent automatically if the session auto-response is on or if Parameter 4 is a status request.

  • Page 80: Gpi Index Base Control

    GPI S:V:1 (terse format) GPI SessonConfig : Verbose:On (verbose format) Response: GPI SessionStatus:Verbose:on Get the current session verbose setting. Verbose message return is on. Command: GPI s:v:? Response: GPI SessionStatus:Verbose:on GPI Index Base Control This command controls whether the GPIs are numbered from 0 or 1. A response to this configuration command is sent automatically if the session auto-response is turned on or if Parameter 4 is a status request.

  • Page 81: Request All Session Settings

    Response: GPI SessionStatus:Base:0 Get the current session GPI index base setting. Verbose message return is off Command: GPI s:b:? Response: GPI S:B:0 Request All Session Settings This command requests all session settings be returned. The responses are the same as the individual setting responses.

  • Page 82: Gpi State Control

    Parameter Description Terse Verbose Query Query current report edge configuration Both Configure to report both edges Leading Configure to report leading edge only Trailing Configure to report trailing edge only None Configure to not report any changes <empty> <empty> Do change the current configuration Query Query current report type configuration Simple...

  • Page 83: Gpi Trigger Control

    GPI Trigger Control This command triggers a GPI output. There is no auto-response to this command. Any changes to the GPI state are reported as configured by the Asynchronous GPI State Reporting Control command. The command is ignored by GPI inputs. Parameter Description Terse...

  • Page 84: Gpi Status Request

    GPI Status Request This command requests a GPI status message for one or all of the GPIs. Parameter Description Terse Verbose Command GPI command/message class Select GPI by index (0-31 or 1-32 as set by Index Base Control) AllGpi Select all GPIs StatusReq Requests a status response Detailed...
  • Page 85 Parameter Description Terse Verbose Event The status message is due to a GPI change to a reportable state. Refer to the section “Asynchronous GPI State Reporting Control” on page 81 for details. Request The status message is due to a detailed status request Config The status message is due to a request in an...
  • Page 86 86 • RossTalk Protocol GPI-8941 User Guide (v9.0)

  • Page 87: Software Licenses

    Software Licenses This chapter provides third-party software license information for the GPI-8941 card. This product includes software components which are individually licensed under the following licenses. lwIP Copyright (c) 2001, 2002 Swedish Institute of Computer Science. All rights reserved. Redistribution and use in source and binary forms, with or without modification, are permitted provided that the following conditions are met: 1) Redistributions of source code must retain the above copyright notice, this list of conditions and the following disclaimer.
  • Page 88 88 • Software Licenses GPI-8941 User Guide (v9.0)

  • Page 89: Service Information

    Bootload Button In the unlikely event of a complete card failure, you may be instructed by a Ross Technical Support specialist to perform a complete software reload on the card. To reload the software on the card Eject the card from the frame.
  • Page 90 This User Manual provides all pertinent information for the safe installation and operation of your openGear Product. Ross Video policy dictates that all repairs to the GPI-8941 are to be conducted only by an authorized Ross Video Limited factory representative. Therefore, any unauthorized attempt to repair this product, by anyone other than an authorized Ross Video Limited factory representative, will automatically void the warranty.

  • Page 91: Glossary

    Glossary The following terms are used throughout this guide: Active image — the portion of the video picture area (production aperture) that is being utilized for output content. Active image excludes letterbox bars and pillarbox bars. Card — openGear terminal devices within openGear frames, including all components and switches. CBR —...
  • Page 92 92 • Glossary GPI-8941 Series User Guide (v9.0)
