INSTALL GUIDE
2016 AUDI S4 PTS WITH KEYPORT AUTOMATIC
DOCUMENT NUMBER
A558F12
REVISION DATE
20211223_151400
FIRMWARE
RSA-AUD2
HARDWARE
CMVWXA0
ACCESSORIES
ATTENTION: TO COMPLETE THIS INSTALLATION SOME ACCESSORIES MAY BE
REQUIRED. VISIT OUR WEBSITE TO SEE ALL THE REQUIRED ACCESSORIES FOR
YOUR VEHICLE.
TERMS OF USE
Automotive Data Solutions Inc. ("ADS") products are strictly intended for installation by Certified Technicians who are employed
by a registered business specialized in the installation of automotive aftermarket electronics products. Prior to beginning
installation of an ADS product in a vehicle, it is the Certified Technician's responsibility to review the most current Product Guide,
Install Guide and vehicle-specific notes available in Weblink®. ADS is not responsible for any damages whatsoever, including but
not limited to any consequential damages, incidental damages, damages for loss of time, loss of earnings, loss of profit,
commercial loss, loss of economic opportunity and the like that may or may not have resulted from the use, misuse, improper
installation or operation of its products. ADS reserves itself the right to suspend any Weblink® account without notice and
decline to offer technical support to non-Certified Technicians, noncompliant Certified Technicians or end users.
www.idatalink.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the idatastart RSA-AUD2 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for ADS idatastart RSA-AUD2

  • Page 1 Prior to beginning installation of an ADS product in a vehicle, it is the Certified Technician’s responsibility to review the most current Product Guide, Install Guide and vehicle-specific notes available in Weblink®. ADS is not responsible for any damages whatsoever, including but not limited to any consequential damages, incidental damages, damages for loss of time, loss of earnings, loss of profit,...
  • Page 2: Remote Start

    PAGE 2 OF 13 FEATURE LIST - 1 OF 1 Doc No.: A558F12 - 20211223_151400 Supported Supported REMOTE START SECURITY SYSTEM Data Immobilizer Bypass (no key required) Arm OEM Alarm Key Required for Immobilizer Bypass Disarm OEM Alarm Takeover Available Aftermarket Alarm Control from OEM Remotes No Takeover Available (shutdown on unlock or door open) Aftermarket Alarm Control from OEM RFID Entry Sensors...
  • Page 3 PAGE 3 OF 13 MODULE LAYOUT - 1 OF 1 Doc No.: A558F12 - 20211223_151400 MODULE CONNECTORS CONNECTOR PINOUT 01 GREEN•BLACK DOT - LOCK (-) OUTPUT 01 GREEN•BLACK DOT - LOCK (-) OUTPUT 02 BLUE•BLACK DOT - UNLOCK (-) OUTPUT 02 BLUE•BLACK DOT - UNLOCK (-) OUTPUT MODULE 03 RED/WHITE•BLACK DOT - TRUNK RELEASE (-) OUTPUT...
  • Page 4 PAGE 4 OF 13 HARDWIRE / COMPONENT LOCATOR - 1 OF 1 Doc No.: A558F12 - 20211223_151400 T004_H U.S. Patent No. 8,856,780 CA 2759622 2016 Audi S4 PTS with keyport Automatic Automotive Data Solutions Inc. © 2021 RSA-AUD2-[CMVWXA0]-EN www.idatalink.com...
  • Page 5 2- SET IGNITION TO ON POSITION. 3- LOOK IF MODULE LED FLASHED GREEN OR RED. 3- LOOK IF MODULE LED FLASHED GREEN OR RED. 4- DISCONNECT ADS-AUD2-OBD HARNESS AND TURN IGNITION TO OFF. 4- DISCONNECT ADS-AUD2-OBD HARNESS AND TURN IGNITION TO OFF. 01 GREEN•BLACK DOT 01 GREEN•BLACK DOT...
  • Page 6 PAGE 6 OF 13 T-HARNESS / WIRING DIAGRAM - 2 OF 2 Doc No.: A558F12 - 20211223_151400 CUT LOOP FOR AUTOMATIC TRANSMISSION ONLY CUT LOOP FOR AUTOMATIC TRANSMISSION ONLY CONNECTIONS TO BCM - STEP 1 CONNECTIONS TO BCM - STEP 1 BCM RIGHT REAR OF TRUNK (B) USE OPTIONAL AUD-RF HARNESS TO EXTEND USE OPTIONAL AUD-RF HARNESS TO EXTEND...
  • Page 7 PAGE 7 OF 13 TYPE 1A - MODULE PROGRAMMING - KLON - 1 OF 2 Doc No.: A558F12 - 20211223_151400 When programming, only one OEM keyfob will Set ignition to OFF position. Insert OEM keyfob 1 in keyport. be used. Place the other one at least 10 feet ON START away from the vehicle.
  • Page 8 PAGE 8 OF 13 TYPE 1A - MODULE PROGRAMMING - KLON - 2 OF 2 Doc No.: A558F12 - 20211223_151400 Press and hold the brake pedal. Press the lock button of OEM keyfob 1 three times [3x]. Release the brake pedal. Wait, the hazard lights will flash twice [2x].
  • Page 9 PAGE 9 OF 13 TYPE 2A - MODULE PROGRAMMING - KEY BOX - 1 OF 1 Doc No.: A558F12 - 20211223_151400 When programming, have an OEM keyfob on Set ignition to OFF position. Module Programming Procedure completed. you. The other OEM keyfob (no battery) will ON START remain permanently in the key box.
  • Page 10 PAGE 10 OF 13 TAKEOVER PROCEDURE - KEYPORT WITH PTS - 1 OF 1 Doc No.: A558F12 - 20211223_151400 >> All vehicle doors must be closed and locked Take over procedure completed. prior to remote start sequence. >> Time restriction. Complete steps 2 to 5 within Failure to follow procedure will result in 45 seconds.
  • Page 11 PAGE 11 OF 13 REMOTE STARTER ERROR CODES - 1 OF 1 Doc No.: A558F12 - 20211223_151400 REMOTE STARTER ERROR CODES: NOTES PARKING LIGHT FLASHES DIAGNOSTIC I WARNING: The following applies only when the parking lights are 3 + 1 Tach is not programmed OR engine is already running.
  • Page 12 PAGE 12 OF 13 MODULE DIAGNOSTICS - 1 OF 2 Doc No.: A558F12 - 20211223_151400 LED 2* LED 1** LED STATUS DIAGNOSTIC Missing/wrong information from firmware or vehicle. • Flashing RED See firmware specific diagnostics, or contact technical support. • Solid RED Module waiting for more vehicle information.
  • Page 13 PAGE 13 OF 13 MODULE DIAGNOSTICS - 2 OF 2 Doc No.: A558F12 - 20211223_151400 LED 2* LED 1** LED STATUS DIAGNOSTIC • Flashing rapid RED Remote start shutdown sequence. • Flashing slow RED Remote start shutdown error code. Contact technical support. •...

This manual is also suitable for:

Idatastart cmvwxa0
