Summary of Contents for Spansion FM3 Series
- Page 1 Spansion International Inc. MCU-UG-9B0002-11 User Guide FM3 FAMILY ADAPTER BOARD ADA-FM3-100PMC-MC USER GUIDE...
-
Page 2: Revision History
Revision History Revision History Date Issue 02-Feb-2011 V1.0 Cha first release 14-Jan-2015 V1.1 AEh Spansionized This document contains 16 pages. MCU-UG-9B0002-11 - 2 - © Spansion Inc... -
Page 3: Warranty And Disclaimer
IC’s etc.) is subject to the terms and conditions of Spansion LLC and its affiliates (“SPANSION”) as set out below and in (i) the terms and conditions of the License Agreement and/or the Sale and Purchase Agreement and/or any other agreement under which deliverables have been delivered, (ii) the technical descriptions and (iii) all accompanying written materials. - Page 4 5. Should one of the above stipulations be or become invalid and/or unenforceable, the remaining stipulations shall stay in full effect. The contents of this document are subject to change by SPANSION without a prior notice, thus contact SPANSION about the latest one...
-
Page 5: Table Of Contents
ADC select jumper settings ..............11 Other jumper settings .................... 12 2.2.5 Hall sensor input ..................12 2.2.6 Quadrature encoder input ................ 13 3 INFORMATION IN THE WWW..................14 4 CHINA-ROHS REGULATION ..................15 5 RECYCLING ........................16 © Spansion Inc. - 5 - MCU-UG-9B0002-11... -
Page 6: Overview
MCU. 1.2 Features of the ADA-FM3-100PMC-MC adapter board 34-pin connector, compatible to different Spansion inverter boards such as SK- POWER-3P-LV2-MC Jumpers to select different MCU pin connections of various resources ... -
Page 7: Hardware
SK-FM3-100PMC main board because of existing connections (e.g. 7-Segment LED display, etc.) Please refer to the documentation of the evaluation board for detailed information about the jumper settings of the SK-FM3-100PMC. © Spansion Inc. - 7 - MCU-UG-9B0002-11... -
Page 8: Jumper Settings
Chapter 2 Hardware 2.2 Jumper settings 2.2.1 Silkplot containing jumper settings MCU-UG-9B0002-11 - 8 - © Spansion Inc... -
Page 9: Motordrive Connector
Depending on the voltage level coming from the external inverter, the external supply voltage present on X7 MUST NOT be directly connected with VCC of the MCU evaluation board! Connect to the external power supply input of the SK-FM3-100PMC if required. © Spansion Inc. - 9 - MCU-UG-9B0002-11... -
Page 10: Pwm And Waveform Generator Select Jumper Settings
(Jumpers set to 1-2). This might partly turn on the inverter transistors as long as the MCU pins are in high-Z or input state, e.g. during power-up or debugging. Therefore, it is recommended to disconnect the LEDs by de-soldering RN3 and RN4 when using WFG0. MCU-UG-9B0002-11 - 10 - © Spansion Inc... -
Page 11: Adc Select Jumper Settings
When using the alternative ADC channels (Jumper set to 2-3), it is recommended to disconnect the 7-segment LED Display SEG1 by removing RN1+RN2 on SK-FM3-100PMC, since these are connected to the same pins as AN08-AN15 and might influence the measurement signals coming from the inverter. © Spansion Inc. - 11 - MCU-UG-9B0002-11... -
Page 12: Other Jumper Settings
X2/X3 Pin Signal (X2) (X3) Hall A IC01_0 IC10_1 Hall B IC02_0 IC11_1 Hall C IC03_0 IC12_1 Pins 3-5 are connected to pull-up resistors (10k) which are needed by many hall sensor outputs. MCU-UG-9B0002-11 - 12 - © Spansion Inc... -
Page 13: Quadrature Encoder Input
In case an encoder without integrated line driver is used, additional pull-up resistors (2k7) are already mounted on the board (R13-R18). The inverted signals of encoders with integrated line drivers are not used. © Spansion Inc. - 13 - MCU-UG-9B0002-11... -
Page 14: Information In The Www
3 Information in the WWW Information about SPANSION INC Products can be found on the following Internet pages: Microcontroller Products http://www.spansion.com/Products/microcontrollers Power Management Products http://www.spansion.com/Products/Analog Memory Products http://www.spansion.com/Products/memory For more information about SPANSION INC. http://www.spansion.com MCU-UG-9B0002-11 - 14 - © Spansion Inc... -
Page 15: China-Rohs Regulation
Chapter 4 China-RoHS regulation 4 China-RoHS regulation This board is compliant with China RoHS. © Spansion Inc. - 15 - MCU-UG-9B0002-11... -
Page 16: Recycling
Gemäß der Europäischen WEEE-Richtlinie und deren Umsetzung in landesspezifische Gesetze nehmen wir dieses Gerät wieder zurück. Zur Entsorgung schicken Sie das Gerät bitte an die folgende Adresse: CCS Express GMBH c/o Spansion International Inc. Frankfurter Str. 83-107 D-65479 Raunheim Germany...
