Summary of Contents for Fenner QD:HVAC
- Page 1 Installation and Operating Instructions AC Variable Speed Drive 0.75kW - 160kW 200 - 480 Volt 1 & 3 Phase...
- Page 2 HVAC Installation & Operating Instructions ııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııı ııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııı Easy Start Up Guide: QD:HVAC IP55 Mechanical Mounting Information can be found on page 12 HVAC Display (Status, diagnostics and programming) Keypad Operation can be found on page 21 Safe Torque Off (STO)
- Page 3 HVAC Installation & Operating Instructions ııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııı ııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııı Easy Start Up Guide: QD:HVAC IP66 Mechanical Mounting Information can be found on page 9 HVAC Display Applies to switched Status, Diagnostics and version only in-built Programming isolator: Mains power On/Off Keypad Operation can be...
-
Page 4: Declaration Of Conformity
User Guide without notice. All Fenner QD Series products carry a 2-year warranty, valid from the date of manufacture. This date is clearly visible on the product rating label. -
Page 5: Installation
HVAC Installation & Operating Instructions ııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııı 1. I 7 .7 Bypass Control Fuction ntroductIon 7 .8 Fire Mode Function Important Safety Information 7 .9 Motor Pre-heat Function & DC Injection 2. G eneral nformatIon and atInGs 8 pId c ontrol pplIcatIons 3. -
Page 6: Important Safety Information
. Ensure that all terminals are tightened to the appropriate torque setting Do not attempt to carry out any repair of the Fenner QD:HVAC In the case of suspected fault or malfunction, contact your local Fenner distributor. -
Page 7: General Information And Ratings
HVAC Installation & Operating Instructions ııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııı 2. General Information and Ratings 5 7 5 F 2 0 P 7 2.1 Drive Model Numbers IP55 Series & Inverter Supply Rated Enclosure Type Voltage Power 200-240V 10% - 1 Phase Input kW Model with Filter Output Frame Size Current (A) -
Page 8: Drive Model Numbers Ip66
HVAC Installation & Operating Instructions ııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııı 2.2 Drive Model Numbers IP66 200-240V 10% - 1 Phase Input kW Model with Filter Output Frame Size Current (A) 576F20P7 0.75 576F21P5 576F22P2 10.5 380-480VV 10% - 3 Phase Input kW Model with Filter Output Frame Size Current (A) -
Page 9: Mechanical Installation
• Check the drive rating label to ensure it is of the correct type and power requirements for the application. • Store the QD:HVAC in its box until required. Storage should be clean and dry and within the temperature range –40°C to +60°C 3.3. - Page 10 HVAC Installation & Operating Instructions ııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııı 3.5 Mechanical Dimensions and Mounting - IP55 Drive Size 440 17 .32 418 16.46 423 16.65 0.315 230 9.06 6.81 4.33 4.25 0.167 7 .5 0.295 540 21.26 515 20.28 520 20.47 0.315 270 10.63 235 9.25 6.89 4.25 0.167 7 .5...
-
Page 11: Removing The Terminal Cover
HVAC Installation & Operating Instructions ııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııı 3.6 Guidelines for enclosure mounting IP55 and IP66 units • Before mounting the drive, ensure that the chosen location meets the environmental condition requirements for the drive shown in section 13.1 • The drive must be mounted vertically, on a suitable flat surface •... - Page 12 HVAC Installation & Operating Instructions ııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııı 3.7 .2 Frame Size 5 3.7 .3 Frame Size 4 Using a suitable Using a suitable flat blade flat blade screwdriver, screwdriver, rotate the four rotate the four retaining screws retaining screws indicated until the indicated until the screw slot is screw slot is...
- Page 13 HVAC Installation & Operating Instructions ııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııı 3.7 .4 Frame Size 7 Using a suitable flat blade screwdriver, rotate the four retaining screws indicated until the screw slot is vertical. www.fptgroup.com Page 13...
- Page 14 HVAC Installation & Operating Instructions ııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııı 3.8 Lock Off Power Isolator Lock Off - IP66 with Built in Isolater Option On the switched models the main power islator switch can be locked in the ‘off’ position using a 20mm standrad shackle padlock (not supplied) www.fptgroup.com Page 14...
-
Page 15: Electrical Installation
HVAC Installation & Operating Instructions ııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııı 4. Electrical Installation The Fenner QD:HVAC is designed to produce the minimum possible leakage current whilst complying with worldwide standards. The level of current is affected by motor cable 4.1 Grounding the Drive length and type, the effective switching frequency, the earth connections used and the type of RFI filter installed. -
Page 16: Wiring Precautions
There are two connections in general: Star and • Fenner QD:HVAC models in frame sizes 4 to 8 are factory Delta. It is essential to ensure that the motor is connected fitted with an Input choke as standard. -
Page 17: Motor Terminal Box Connections
HVAC Installation & Operating Instructions ııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııı 4.5. Motor Terminal Box Connections Most general purpose motors are wound for operation on dual voltage supplies. This is indicated on the nameplate of the motor. This operational voltage is normally selected when installing the motor by selecting either STAR or DELTA connection. STAR always gives the higher of the two voltage ratings. -
Page 18: Control Terminal Connections
HVAC Installation & Operating Instructions ııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııı 4.8 Control Terminals Connection Diagram Control Terminal Designations and Default Function Assignments +24 Volt Control Circuit Supply or Programmable Relay Output external 24 Volt Power Supply RL1-C +24V Drive Healthy RL1-NO Run / Enable Programmable Relay Output RL1-NC Fwd/Reverse... -
Page 19: Managing The Keypad
HVAC Installation & Operating Instructions ııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııı 5. Managing the Keypad The drive is configured and its operation monitored via the built in keypad and display. IP20 Drives: IP20 rated drives are supplied with a 7 segment LED display and a five button keypad IP55 &... -
Page 20: Accessing And Changing Parameter Values
HVAC Installation & Operating Instructions ııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııııı 5.3 Accessing and Changing Parameter Values Function When Display Press Result Example Shows Fast selection of The next highest Display shows P1-10 Px-xx Parameter Groups Parameter group is Press Note: Parameter selected Display shows P2-01 Group Access must The next lowest Display shows P2-26...
