- Page 1 Getting Started Guide for TWR-K60N512-IAR FREESCALE TOWER SYSTEM IAR KickStart Kit ™ For the Freescale Kinetis K60 family of microcontrollers Downloaded from Elcodis.com electronic components distributor...
- Page 2 FREESCALE TOWER SYSTEM Get to Know the TWR-K60N512-IAR Primary Connector Infra-Red Touch TWRPI General Purpose Socket Tower Plug-In (TWRPI) Socket LED/Touch Buttons SW3 (Reset) E1–E4 Power/OSJTAG MK60N512 Mini-B USB VMD100 Connector Microcontroller Secondary MMA7660 Connector Accelerometer Figure 1: Front Side of TWR-K60N512 Module Not Including TWRPI. Potentiometer TWR-K60N512 SD Card...
- Page 3 Getting Started Guide for TWR-K60N512-IAR FREESCALE TOWER SYSTEM Features of the Kinetis K60N512 Kit This guide briefly describes how to get started using IAR Embedded Workbench ® with IAR J-Link (Lite), USB-JTAG/SWD debug probe for Cortex-M to run an example application on the Freescale Kinetis K60N512 board. For more detailed information, see the IAR Embedded Workbench IDE User Guide, and the C-SPY hardware debugger documentation, which can be found on the Help menu in the IAR Embedded Workbench IDE.
- Page 4 FREESCALE TOWER SYSTEM Install Software Tools and BSP The installation DVD contains all the software and documentation you need to start building and running embedded applications on the Freescale Kinetis K60N512 kit. We recommend that you follow the installation instructions on the DVD and use the default directories for installation. STEP STEP Install the Software...
-
Page 5: Learn More
Getting Started Guide for TWR-K60N512-IAR FREESCALE TOWER SYSTEM STEP STEP Run Example Project Run RTOS BSP a. Start IAR Embedded a. Follow the links on the Getting Workbench and click “EXAMPLE Started DVD to download RTOS BSPs. PROJECTS” in IAR Information Center. b. Set up the board or Tower System b. Select Freescale > Freescale Kinetis > according to the user guide included in K60 >... -
Page 6: Jumper Options
FREESCALE TOWER SYSTEM Jumper Options The following is a list of all the jumper options for the TWR-K60N512 module. The default installed jumper settings are shown in bold. Jumper Option Setting Description MCU Power Connect on-board 3.3V supply to MCU Connection Isolate MCU from power (connect an ammeter to measure current) - Page 7 Getting Started Guide for TWR-K60N512-IAR FREESCALE TOWER SYSTEM Jumper Option Setting Description JTAG Board Connect on-board 5V supply to JTAG port Power Connection (supports powering board from JTAG pod supporting 5V supply output) Disconnect on-board 5V supply to JTAG port IR Transmitter Connect PTD7/CMT_IRO to IR Transmitter Connection...
- Page 8 FREESCALE TOWER SYSTEM Learn more: To find more example projects and information on the K60 microcontrollers, please visit freescale.com/TWR-K60N512. To download the latest software updates, visit iar.com/kit_updates. To watch video recordings about IAR Embedded Workbench IDE, C-SPY debugger and power debugging, visit iar.com/video. Disclaimer: Information given in this document is intended as a help for the user. IAR Systems shall not be held liable for any losses or problems arising from using the information given in this document. Neither whole nor any part of the information in this document may be adapted or reproduced. Troubleshooting: If you are unable to find the cause of a problem, try resetting the evaluation board by using the reset button on the board. Then restart the C-SPY Debugger in the IAR Embedded Workbench IDE. You can also try disconnecting and reconnecting the power to the evaluation board, pressing the reset button and then restarting C-SPY.
