Modern WF291237AAE Assembly Instructions

Important note:

1. Place all wooden parts on a clean and smooth surface such as a rug or carpet to avoid scratching the
parts.
2. Kindly follow the assembly instructions step by step.
3. Do not tighten all screws and bolts until the table is fully assembled.
4. Unscrew the protective plastique supports from the metal insert of the legs before assembly.
A
Chair Back
1pc
E
Left Stretcher
1pc
1
Bolt
1/4"X40mm
2pcs
5
Spring Washer
1/14"X11mm
14 pcs
Step 1
ASSEMBLY INSTRUCTIONS
ITEM: WF291237AAE/WF291237AAP
Parts Identification
B
Seat cushion
1pc
F
Right Stretcher
1pc
Hardware Identification
2
Long Bolt
1/4"X80mm
4pcs
6
Flat Washer
1/4"X19mm
14 pcs
7
2
5
6
C
Front Left Leg
1pc
G
Front Stretcher
1pc
3
Bolt
1/4"X60mm
4pcs
7
Allen Key
1pc
B
A
7
1
5
6
D
Front Right Leg
1pc
4
Bolt
1/4"X20mm
4pcs
8
Wood screw
4X38mm
4pcs
PAGE 1 OF 2
