4. Inlet port fits 1/2" schedule 40PVC slip fittings. (see FIG 1-4)
Connect inlet port of AG140-001 to the water softener.
Fig 1-4
1/2" PVC
pipe size
typical
To the Washing Machine
One typical Piping Installation
500 Jefferson Street, Placentia, California 92870 USA • 949-955-3928 • Email: orders@airgap.com
To Water Softerner
AG140-001
Copyright AIR GAP INTERNATIONAL
Model:
AG140-001
2-INCH STANDPIPE
UNIVERSAL 14GPM AIR GAP
Old Part Number:
GAP-IT, 61-S
Doc.#400-0655-004
Placentia, California
Advertisement
Table of Contents
Summary of Contents for AIR GAP AG140-001
- Page 1 Placentia, California 4. Inlet port fits 1/2" schedule 40PVC slip fittings. (see FIG 1-4) Connect inlet port of AG140-001 to the water softener. Model: AG140-001 Fig 1-4 2-INCH STANDPIPE To Water Softerner UNIVERSAL 14GPM AIR GAP 1/2” PVC pipe size...
- Page 2 AG140-001 INSTALLATION INSTRUCTION 1. Make sure that the flow rate output of the water softener meets AG140-001 flow capacity limits. 2. Install the water softener air gap into the mounting base, as shown (see FIG 1-1), for dimensions see FIG 1-2. 1.82"...
