TrailFX WA020 Battery Changing Instructions

FITS FOR TRAIL FX SYNTHETIC ROPE WINCH WS10B.
REMOVE CONTENTS FROM BOX. VERIFY ALL PARTS ARE PRESENT.
READ INSTRUCTIONS CAREFULLY BEFORE STARTING INSTALLATION.
STEP 1: Unscrew six screws beneath the Housing.
STEP 3: Remove the White Connector.
STEP 5: Connect the New Receiver with the white connector
shown in the picture above.
Page 1 of 3
TFX Winch Wireless Remote
Receiver & Battery changing instructions
Part No. WA020
30 min
support@trailfx.com
1 866 638 4870
STEP 2: Open the Housing.
STEP 4: Remove the Receiver by pulling it upwards.
STEP 6: Stick the New Receiver using the Adhesive Tape
provided in the bottom side of the Receiver, And fix the
housing.
www.TrailFX.com
Cutting Not Drilling Not
Required
Required
PULL IT TOWARDS
ADHESIVE TAPE
