Summary of Contents for KIENLE PK 400
- Page 1 Deep Frying and Pasta Technology Made in Germany Pasta Cooker Standalone and Installation and Built-on Devices Operating Instructions PK 400 PKE 400 PK 600 PKE 600 July 2022...
- Page 2 KIENLE GmbH reserves the right to make modifications or improvements without prior announcement.
-
Page 3: Table Of Contents
Table of Contents Safety Instructions and Regulations ....................3 1.1. Warning Signs, Hazard Symbols and Information Symbols ............3 1.2. Basic Safety Instructions and Regulations ................... 4 1.3. Intended Use ..........................4 1.4. Misuse ............................4 1.5. Product-specific Hazards ......................5 1.6. -
Page 4: Safety Instructions And Regulations
1. Safety Instructions and Regulations ➔ Follow the safety instructions in the installation and operating instructions! ➔ Caution: Switch off power to the appliance and secure against switching back on before opening the appliance! Incorrect electrical installation can lead to severe injury or even death. Electrical connections may only be made by a qualified electrician Incorrect installation, settings, modifications or failure to carry out maintenance work on the appliance can lead to damage to the appliance or injury to persons. -
Page 5: Basic Safety Instructions And Regulations
1.2. Basic Safety Instructions and Regulations The appliance complies with the state of the art and recognised technical safety rules. Nevertheless, there may still be residual risks. The appliance may only be operated in perfect condition under observance of the operating instructions. -
Page 6: Product-Specific Hazards
1.5. Product-specific Hazards ➔ crushing or hitting Avoid hazard for parts of the body: Observe the instructions on the packaging for storing, lifting or transporting. ➔ risk of explosion Avoid - The appliance must not be installed in places where there is a risk of explosion. ➔... -
Page 7: Personnel Qualification
1.6. Personnel Qualification ➔ Observe work safety regulations. ➔ Read the installation and operating instructions carefully before use. Activity User group Qualification/training Installation/commissioning Specialist Authorised electrician (qualified electrician or personnel person with similar training) Work on the electrical Specialist Authorised electrician (qualified electrician or personnel system person with similar training) -
Page 8: Installation
2.3. Installation ➔ Installation may only be performed by specialist personnel or acceptance must be carried out by specialist personnel at least (before FIRST-TIME commissioning). ➔ Install the appliance or level ground. Balance slight unlevelness with the adjustable screw feet. ➔... -
Page 9: Water Connection
3. Water Connection 3.1. Notes on water Connection ➔ Ask your local water supply company for information about the water quality, water pressure and water hardness prior to installation. ➔ Observe the regional regulations and “Technical Rules for Drinking Water Installations” EN 1717! ➔... -
Page 10: Choice Of Water Softener/Water Filter Water Treatment
4. Choice of Water Softener/Water Filter Water Treatment 4.1. Water Treatment System ➔ Water softener manufacturers offer systems that are specially designed for pasta cookers. These can also be combined with particulate/fine and activated carbon filters. We recommend the water softener from Brita Co., for example. ➔... -
Page 11: Conversion For The Units Of Water Hardness
4.3. Conversion for the Units of Water Hardness °dH °e °fH mval/l mmol/l German degree 1 °dH = 1.253 1.78 17.8 0.357 0.1783 English degree 1 °e = 0.798 1.43 14.3 0.285 0.142 French degree 1 °fH = 0.560 0.702 4.4. -
Page 12: Electrical Connection
5. Electrical Connection ➔ The electrical connection may only be made by specialist personnel in accordance with the applicable regulations VDE 0100 and the regulations of the responsible energy supply company. ➔ An electric main switch must be wired easily accessible. The switch must disconnect the appliance effectively and at all poles from the mains. -
Page 13: Appliance Description
7. Appliance Description Page | 12... -
Page 14: Pasta Basket Range
8. Pasta Basket Range Order No. Description 77010 Pasta basket for inserting in pasta cooker without lift Dimensions: 130 x 85 x 200 mm 77020 Pasta basket for inserting in pasta cooker without lift Dimensions: 140 x 140 x 200 mm 77030 Pasta basket for inserting in pasta cooker without lift Dimensions: 160 x 290 x 200 mm 77040... -
Page 15: Time Setting
9. Time setting On/Off button (selection) Signal field Temperature & Info field time indicator Programme button field Filling button (confirm + next) Switch on: Press the On/Off button briefly Change to programming level: Press the On/Off button briefly 2x (signal panel flashes green/blue) Press and hold programme button Year number entry: e.g. -
Page 16: Commissioning/Quick Guide
Commissioning/Quick Guide Page | 15... -
Page 17: Programming
Programming Page | 16... -
Page 18: Correct Cooking Salt Dosing
(Other products with slightly different amounts.) A 150 ml ladle holds approx. 240 g of cooking salt. Pasta cooker PK 400 Water capacity 24 litres First dosing 240 g fine cooking salt. Refilling after 8 litres (salt display) 80 g (= approx. 4 tablespoons) Pasta cooker PK 600 Water capacity 45 litres First dosing 480g fine cooking salt. -
Page 19: Cleaning Instructions For Pasta Cookers
Cleaning Instructions for Pasta Cookers General note: ➔ Only dose salt into the reservoir filled with hot water. ➔ Do not dose too much salt. The water has only a limited absorbency. Overdosed salt sinks to the bottom and is no longer dissolved. More frequent dosing is kinder on the appliance and improves the product quality. -
Page 20: Pasta Cookers And Stainless Steel
Pasta Cookers and Stainless Steel Causes All cooking reservoirs from Kienle are made of high-quality stainless steel 1.4401 AISI 316 (V4A) material. Despite this high-quality material, there are still several points to be considered to avoid damage. The most common causes are rust bloom and pitting. -
Page 21: Pasta Cookers And Stainless Steel - Care
Pasta Cookers and Stainless Steel - Care Rust bloom on stainless steels If you discover rust bloom, find the source of the rusting material that has contaminated the cooking reservoir and eliminate this source. The brown rust bloom particles must be removed immediately. You can use a fleece suitable for stainless steel to do this. -
Page 22: Operating Notes For Pasta Cookers
Operating Notes for Pasta Cookers Only fill the cooking reservoir with softened water. Lime deposits bind starch residues and reduce the heating output and can lead to faults. Make sure that cooking reservoir is filled up to the overflow. If this is repeatedly not the case in the filling process, you can prolong the refilling time in the programme (item 10). -
Page 23: Customer Service
Never leave the water in the cooking reservoir overnight or during longer cooking breaks. This is unhygienic and leads to blockages in the drain system. After draining the water, clean the cooking reservoir and the appliance with a suitable cleaning agent and rinse again afterwards. Do not use acids! Do not forget to close the fresh water valve (on-site tap) overnight and switch off the power supply, at least at the black I- 0 switch on the substructure. -
Page 24: Maintenance
Maintenance ➔ The owner is obliged to service and clean the appliance at regular intervals. The appliance may only be operated in a technically perfect and undamaged condition. Only genuine spare parts may be used, otherwise tests and approvals will expire. Switch off the power supply to the appliance and secure against switching back on before replacing electrical or mechanical components. -
Page 25: Fault Messages
Fault Messages Message in What to do info field E 03 Temperature rises too fast Check water Press on/off switch (reset) Heater limit switch Check position of heater - must be on the reservoir bottom. E 05 Check magnet. E 06 Limit switch load shedding Bridge missing from control board.
