CONTENTS
Getting Started -----------------------------------------------------------------------
Setup Procedures ---------------------------------------------------------------------
Setup Menu-------------------------------------------------------------------------------
Setup flow Chart ------------------------------------------------------------------------
Group 0 : Interface Selection -------------------------------------------------------
Group 1 : Device Selection for keyboard interface--------------------------
Group 2 : Inter-character Delay ---------------------------------------------------
Group 3 : Language for Keyboard Interface ------------------------------------------
Group 4 : Terminator---------------------------------------------------------------
Group 5 : Scan Mode ----------------------------------------------------------
Group 6 : Preamble and Postamble -------------------------------------------------
Group 7 : Reserved --------------------------------------------------------------------------
Group 8 : RS-232 Parameters --------------------------------------------------
Group 9 : Code 39 / Code 32 ---------------------------------------------------
Group 10-1: Interleaved 2 of 5 ------------------------------------------------------
Group 10-2: Industrial 2 of 5 / IATA------------------------------------------
Group 10-3: Matrix 2 of 5----------------------------------------------------------
Group 10-4: China Postage-------------------------------------------------------
Group 12 : ISBN/ISSN-------------------------------------------------------------
Group 13 : Codabar / NW7---------------------------------------------------------
Group 14 : Code 4--------------------------------------------------------------------
Group 15-1 : EAN 13 / JAN 13-------------------------------------------------------
Group 15-2 : UPC-A-------------------------------------------------------------
Group 15-3 : EAN-8 / JAN-8-----------------------------------------------------------
Group 15-4 : UPC-E / UCC EAN-128-----------------------------------------------
Group 16 : General Parameters-------------------------------------------------------
Group 17 : Code ID Settings---------------------------------------------------------
Group 18 : Wand Type Parameters-------------------------------------------------
Group 19 : Magnetic Parameters---------------------------------------------------
Group 20 : Function Key Emulation----------------------------------------------
Function Code for PC XT/AT------------------------------------------------------
Table-Hex : Hexadecimal---------------------------------------------------------
ASCII Table----------------------------------------------------------------------------
Hexadecimal-Decimal Conversion Table -------------------------------------------
Pin Assignments of Scanners-----------------------------------------------------
1
2
3
4
4
5
6-7
8
9-10
11-12
13-14
15
15
16-18
19-20
21
22
23
24
25-26
27
28
29
30
31
32
33
34
35
36
37-39
40
41-42
43
44
45
46-47
Advertisement
Table of Contents
Related Manuals for ICO CCD-800
Summary of Contents for ICO CCD-800
-
Page 1: Table Of Contents
CONTENTS Getting Started ----------------------------------------------------------------------- Setup Procedures --------------------------------------------------------------------- Setup Menu------------------------------------------------------------------------------- Setup flow Chart ------------------------------------------------------------------------ Group 0 : Interface Selection ------------------------------------------------------- Group 1 : Device Selection for keyboard interface-------------------------- Group 2 : Inter-character Delay --------------------------------------------------- Group 3 : Language for Keyboard Interface ------------------------------------------ 9-10 Group 4 : Terminator--------------------------------------------------------------- 11-12... -
Page 2: Getting Started
Getting Started Installing Keyboard Wedge Scanner To install a keyboard wedge scanner, follow the steps listed below: 1) Make sure that the scanner has the correct Y (U)- cable for the system (a PC or terminal) 2) Turn off the power of the system 3) Unplug the keyboard from the system 4) Connect the Y (U)- cable to the system and keyboard 5) Turn on the power of the system... -
Page 3: Setup Procedures
Setup Procedures 1) Locate a group that contains the parameters to be changed. 2) Scan the “Enter Group #” label. The scanner will sound beeps indicate that setup is in progress 3) Scan the label representing the parameter to be changed 4) Scan the “Exit”... -
Page 4: Setup Menu
Setup Flow Chart ENTER GROUP SELECT ITEMS EXIT Set All Defaults Show Version... -
Page 5: Group 0: Interface Selection
Group 0: Interface Selection ENTER GROUP EXIT KEYBOARD RS-232 WAND OCIA RS-232 Reserved 2 DTMF Reserved 4... -
Page 6: Group 1: Device Selection For Keyboard Interface
Group 1: Device Selection for Keyboard Interface ENTER GROUP EXIT PC/AT, PS/2 50,60,70,80(*) PC/XT PS/2 25, 30 (NEC 9801) (IBM 5550) (PS 55) (NEC N5520) (ACER 7300) (KW1050D/CT-700A/WANG 5120) (WANG 5425) (MAC_SE) (LC-6533) - Page 7 Group 1: Device Selection for Keyboard Interface ENTER GROUP EXIT (IBM3196,3197,3476,3477) Reserved Q Reserved R Reserved T IBM3197 IBM 3476 IBM3477 RESERVED 5 Reserved 6 RESERVED 7 Reserved 8 RESERVED 9...
-
Page 8: Group 2: Intercharacter Delay
Group 2: Intercharacter Delay ENTER GROUP EXIT Start Keyboard Setting Scan Enter Group 2 Label -- > Scan Start Keyboard (or RS-232) Setting Label --> Scan two digits labels in "Table-Hex" --> Scan Exit Label Start RS-232 Setting Keyboard Default Value: 05 RS-232 Default Value : 00... -
Page 9: Group 3: Language For Keyboard Interface
Group 3: Language for Keyboard Interface ENTER GROUP EXIT U.S. (*) ENGLAND FRANCE GERMANY ITALY BELGIUM SWEDEN/FINLAND SPANISH DENMARK PORTUGAL SWISS NORWAY... - Page 10 Group 3: Language for Keyboard Interface ENTER GROUP EXIT CANADA HOLLAND POLAND LATIN JAPAN RESERVED 1 RESERVED 2 RESERVED 3 (IBM THINK-PAD FOR JAPAN) (PANASONIC CF-II FOR JAPAN)
-
Page 11: Group 4: Terminator
Group 4: Terminator ENTER GROUP EXIT KEYBOARD NONE SPACE CTRL-C... - Page 12 Group 4: Terminator ENTER GROUP EXIT RS-232 NONE CR/LF SPACE CTRL-C STX..ETX XON.. XOFF...
-
Page 13: Group 5: Scan Mode
Group 5: Scan Mode ENTER GROUP EXIT 1: Trigger On/Off 2: Trigger On/Good Read Off (*) 3: Trigger On/Good Read Off/ Delay Timeout = ? 4: Continuous/Trigger Off 5: Continuous/LED Always on 6: Continuous/No Trigger 7: Continuous/Testing 8: Continuous/Trigger Off/ Delay Timeout = ? - Page 14 Group 5: Scan Mode ENTER GROUP EXIT FLASH OFF(*) FLASH ON SHORT ZONE LONG ZONE LASER DELAY For Laser Scanner Mode Default Laser Delay Timeout = 60 sec. Scan Enter Group 5 Label Scan Laser Delay --> Refer to the Table-Hex at page 41 and select a value --> Scan Confirm in Table Hex.
-
Page 15: Group 6: Preamble And Postamble
Group 6: Preamble and Postamble ENTER GROUP EXIT Preamble Postamble Preamble & Postamble Setting: Scan Enter Group 6 Label --> Scan Preamble or Postamble Label --> Refer to ASCII Table(page 44), scan two digits in Table-Hex (Page 43) Representing one character, maximum 10 characters can be accepted. --> Scan Confirm Label in Table-Hex (Page 43) Scan Exit Label Clear... -
Page 16: Group 8: Rs-232 Parameters
Group 8: RS-232 Parameters ENTER GROUP EXIT Baud Rate 1200 2400 4800 9600(*) 19200 38400 Data Bit BIT 7 BIT 8... - Page 17 Group 8: RS-232 Parameters ENTER GROUP EXIT Parity : NONE (*) EVEN Handshaking: NONE (*) XON/OFF Scanner Ready Data Ready ACK/NAK...
- Page 18 Group 8: RS-232 Parameters ENTER GROUP EXIT (CK/NAK Response Time CTS Observation Time:) 100 ms 300 ms 500 ms 1 sec. 3 sec (*) 5 sec. 10 sec.
-
Page 19: Group 9 : Code 39 / Code
Group 9: CODE 39 / (CODE 32) ENTER GROUP EXIT Enable (*) Disable Standard (*) Full ASCII Transmit Start/End Character Disable (*) Enable Transmit Check Character Enable (*) Disable Verify Checksum Enable Disable (*) Enable CODE 32... - Page 20 Group 9: CODE 39 / (CODE 32) ENTER GROUP EXIT Verify Normal (*) Verify Strick...
-
Page 21: Group 10-1: Interleaved 2 Of 5
Group 10-1: Interleaved 2 OF 5 ENTER GROUP EXIT Disable (*) Enable Transmit Check Character Disable Enable (*) Verify Checksum Disable Enable Length Define Min: 4 Max: 48 Barcode Length Setting Scan Enter Group 10-1 Label --> Scan Length Define Label --> Scan Four Digit Labels in Table Hex (Page 43) -->... -
Page 22: Group 10-2: Industrial 2 Of 5 / Iata
Group 10-2: Industrial 2 OF 5 / IATA ENTER GROUP EXIT Disable (*) Enable Transmit Check Character Disable Enable (*) Verify Checksum Disable Enable Length Define Min: 2 Max: 24 Barcode Length Setting Scan Enter Group 10-2 Label --> Scan Length Define Label --> Scan Four Digit Labels in Table Hex (Page 43) -->... -
Page 23: Group 10-3: Matrix 2 Of 5
Enable Group 10-3: Matrix 2 of 5 ENTER GROUP EXIT Disable (*) Enable Transmit Check Character Enable (*) Disable Verify Checksum Enable Disable (*) Length Define Min: 2 Max: 40 Barcode Length Setting Scan Enter Group 10-3 Label --> Scan Length Define Label --> Scan Four Digit Labels in Table Hex (Page 43) -->... -
Page 24: Group 10-4: China Postage
Scan Confirm Label in Table Hex --> Scan Exit Label Group 10-4: CHINA POSTAGE ENTER GROUP EXIT Disable (*) Enable Transmit Check Character Enable (*) Disable Verify Checksum Enable Disable (*) Length Define Min: 2 Max: 40 Barcode Length Setting Scan Enter Group 10-3 Label -->... -
Page 25: Group 11 : Code 128/ Code 93/ Code 11/ Msi-Plessey
Scan Confirm Label in Table Hex --> Scan Exit Label Group 11: CODE 128/(CODE 93)/(CODE 11)/(MSI-PLESSEY) ENTER GROUP EXIT CODE 128 Enable (*) Disable CODE 93 Enable Disable (*) Concatenation Enable Disable (*) - Page 26 Note: Options marked by ( ) are only available upon request Group 11: CODE 128/(CODE 93)/(CODE 11)/(MSI-PLESSEY) ENTER GROUP EXIT Enable(*) Disable Number of Check Character Two (*) Transmit Check Character Enable Disable (*) MSI/PLESSEY Enable (*) Disable...
-
Page 27: Group 12 : Isbn/Issn
Note: Options marked by ( ) are only available upon request Group 12: (ISBN/ISSN) ENTER GROUP EXIT Disable (*) Enable... -
Page 28: Group 13: Codabar / Nw7
Note: Options marked by ( ) are only available upon request Group 13: CODABAR / NW7 ENTER GROUP EXIT Enable(*) Disable Transmit Start/End Character Disable (*) Enable Start/End Transmit Type ABCD/ABCD ABCD/TN*E abcd/abcd (*) abcd/tn*e... -
Page 29: Group 14 : Code
Group 14: (Code 4) ENTER GROUP EXIT Enable Disable (*) -
Page 30: Group 15-1 : Ean 13 / Jan
Note: Options marked by ( ) are only available upon request Group 15-1: EAN-13/JAN-13 ENTER GROUP EXIT Enable (*) Disable ADD-ON 2/5 Disable (*) Enable (*) Transmit Check Character Disable Enable (*) Truncate Leading Digit Disable (*) Enable Truncate Leading Zero Disable (*) Enable... -
Page 31: Group 15-2: Upc-A
Check-Digit On (*) Check-Digit Off Group 15-2: UPC-A ENTER GROUP EXIT Enable (*) Disable ADD-ON 2/5 Disable (*) Enable (*) Transmit Check Character Disable Enable (*) Truncate Leading Digit Disable (*) Enable Truncate Leading Zero Disable (*) Enable... -
Page 32: Group 15-3: Ean-8/Jan-8
Group 15-3: EAN-8/JAN-8 ENTER GROUP EXIT Enable (*) Disable ADD-ON 2/5 Disable (*) Enable (*) Transmit Check Character Disable Enable (*) Truncate Leading Disable (*) Enable EAN Convert to EAN-13 Disable (*) Enable... -
Page 33: Group 15-4: Upc-E / Ucc Ean/128
Group 15-4: UPC-E / UCC EAN/128 ENTER GROUP EXIT Enable (*) Disable ADD-ON 2/5 Disable (*) Enable (*) Transmit Check Character Disable Enable (*) Truncate Leading Digit Disable (*) Enable UCC/EAN/128 Disable (*) Enable UPC-E Convert to UPC-A... -
Page 34: Group 16: General Parameters
Disable Enable Group 16: General Parameters ENTER GROUP EXIT Upper Case Lower Case Universal ALT Mode Buzzer Pitch (Default : 16) Buzzer Duration (Default: 04) Buzzer Pitch & Buzzer Duration Setting: Scan Enter Group 16 Label --> Scan Buzzer Pitch or Buzzer Duration Label --> Scan Two Digit Labels in Table-Hex -->... -
Page 35: Group 17 : Code Id Settings
Turbo (*) Normal Group 17: Code ID Setting ENTER GROUP EXIT CODE 39 INTERLEAVED 2 OF 5 INDUSTRIAL 2 OF 5 MATRIX 2 OF 5 CHINA POSTAGE CODE 128 CODE 93 CODE 11 MSI/PLESSEY CODABAR/NW7 EAN-13/UPC-A EAN-8 UPC-E UPC-A... -
Page 36: Group 18: Wand Type Parameters
Note: Refer to ASCII Table, scan two hexadecimal labels in Table Hex to represent one character Group 18: WAND Type Parameters ENTER GROUP EXIT BAR=LOW BAR=HIGH(*) Scan Speed Lowest Low (*) High Highest Data Format Transmit in Normal Format (*) Transmit in Code 39 Format Transmit in Code 128 Format... -
Page 37: Group 19 : Magnetic Parameters
Group 19-1: (Magnetic Parameters) ENTER GROUP EXIT Disable Enable (*) Track Order Track 1/2/3 (*) Track 1/3/2 Track 2/1/3 Track 2/3/1 Track 3/2/1 Track 3/1/2... - Page 38 Note: Options marked by ( ) are only available upon request Group 19-1: (Magnetic Parameters) ENTER GROUP EXIT Track Selection Track 1&2&3 any (*) Track 1 only Track 2 only Track 3 only Track 1 and 2 Track 2 and 3 Track 1 and 2 and 3 ISO (*) (JIS-2)
- Page 39 Note: Options marked by ( ) are only available upon request Group 19-2: (Magnetic Parameters) ENTER GROUP EXIT Start Sentinel: (SS) Tk1 Default : % Tk2 Default Tk3 Default: ; ? End Sentinel: (ES) Tk1&2&3 Default: ? DLE: Tk1 Default : Null Tk2 Default: Null Tk3 Default: Null STX:...
-
Page 40: Group 20 : Function Key Emulation
STX - Tk1 Start Sentinel - Tk1 Data - End Sentinel - Tk1 - DLE STX - Tk2 Start Sentinel - Tk2 Data - End Sentinel - Tk2 - DLE STX - Tk3 Start Sentinel - Tk3 Data - End Sentinel - Tk3 - DLE Note: Options marked by ( ) are only available upon request Group 20: (Function Key Emulation) ENTER GROUP... -
Page 41: Function Code For Pc Xt/At
To scan a function key barcode label, full CODE 39 must be enabled. Please refer to Full CODE 39 Table to produce the function key barcode label. Full CODE 39 Enable Function Code for PC XT/AT F1 ($A) F7 ($G) F2 ($B) F8 ($H) F3 ($C) - Page 42 Function Code for PC XT/AT Enter ($M) End ($U) ($B) Tab ($N) PgUp ($V) BS ($O) PgDn ($W) Up ($P) Ins ($X) Down ($Q) Del ($Y) Left ($R) Esc (%A) Right ($S)
- Page 43 Home ($T) Table-Hex : HEXADECIMAL...
-
Page 44: Ascii Table
Confirm ASCII TABLE... -
Page 45: Hexadecimal-Decimal Conversion Table
Hexadecimal-Decimal Conversion Table... -
Page 46: Pin Assignments Of Scanners
For Example: Hexadecimal Decimal 56 -> H:5 L:3 D5-> H:D L:5 PIN ASSIGNMENTS 9 Pin 6 PIN DSUB/AM 25 PIN 6 PIN DIN MINI DIN COLOR Function P (F) DIN(M) Start of Yellow Scan Orange Signal Data White Indicator Blue Trigger Power Green... - Page 47 PIN ASSIGNMENTS RS-232 Signal Output COLOR FUNCTION 9 PIN DSUB/AMP(F) 25PIN DSUB(F) Black Brown Grey Violet Green VCC+5V Note : For PC applications , a cable with DC power jack is required to accept external power input. Keyboard Signal Output COLOR FUNCTION 5 PIN DIN (F)
