- Page 1 USER'S MANUAL 6-WAY graphic KEQ20 equalizer FRONT, SPEAKER REAR & BAND LEVEL SUBWOOFER LINE EQUALIZER OUTPUT DRIVER...
- Page 2 Introduction The KEQ20 is a Six Channel Pre-Amp Equalizer Network with which you can install various types of multi-amplifier systems in a car. The KEQ20 is to be used with high quality power amplifiers and speakers in a multi-amplifier system for hi-fi (high fidelity) sound reproduction.
- Page 3 1. Inputs: The has two types of inputs, Pre-Amp and Speaker Level. These inputs should get KEQ20 their signals from the main head unit and should attach to either RCA jacks or speaker leads that are coming out of your source unit. If your source unit has a front, rear and subwoofer pre-amp output, connect them to identical inputs on your .
- Page 4 Installation A:-Placement & Mounting of the KEQ20 Placement : The KEQ20 needs to be installed in the signal path after your source unit but definitely before your amplifiers and or any active crossovers. The chassis is usually mounted in the rear of the vehicle close to the amplifiers as possible.
- Page 5 Ground Connection: Use the same gauge wire as you did for the positive connector and run it from the Ground connector on the KEQ20 to a chassis ground with the length be as short as possible to ensure a good ground connection.
- Page 6 Some Example of System Configuration System 2 Sub- woofers Rear Speakers Subwoofer Rear Front Front Speakers System 3 Rear Front Rear Speakers Front Speakers - 5 -...
- Page 7 8. Now increase the volume on your source unit to your normal listening level. 9. At this point you may find yourself going back and adjusting the Output Level controls on your KEQ20 to balance the Front, Rear , and Subwoofer sections of your system to accommodate for the speaker placement and efficiency.
- Page 8 VOLUME LEVEL WITH RUNNING ENGINE: Check the power wire(red) with good connection directly to the battery and ground point must make good contact with chassis ground. Check the input grounding jumper or ground insolation selector inside. FOR MORE INFORMATION PLEASE VISIT WWW.DS18.COM...
