Dutailier 100 Series Assembly

A S S E M B LY M A N U A L / I N S T R U C T I O N D ' A S S E M B L A G E
G l i d e r c h a i r /
C h a i s e à b e r c e m e n t s u r b i l l e s
SERIE 100

PARTS AND HARDWARE LIST /

LISTE DES PIÈCES ET QUINCAILLERIE
4X
1
2
4X
Not included / Non Inclus
1/4 - 20 X 1 1/4 (ref# 3000302)
5/16 (ref# 3000314)
#2
Applicable for the following chair models /
Applicable pour les modèles de chaises suivantes:
8 2 6 , 8 2 7 , 8 2 9 , 6 1 A , 6 1 B , 6 1 T , 6 4 A , 6 4 B , 6 4 T
A D È L E , A L I C E , A N N A , R A C H E L , R O S E , R U B Y ,
É R I É & O N T A R I O
CHAIR TOP /
HAUT DE CHAISE
GLIDING BASE / BALANCIER
