Oliver LEGACY ELITE II 2023 Owner's Manual

Travel trailer
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
2023
LEGACY ELITE II
OWNER'S
MANUAL
VIEW THIS MANUAL ONLINE AT OLIVERTRAVELTRAILERS.COM

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LEGACY ELITE II 2023 and is the answer not in the manual?

Questions and answers

Related Manuals for Oliver LEGACY ELITE II 2023

Summary of Contents for Oliver LEGACY ELITE II 2023

  • Page 1 2023 LEGACY ELITE II OWNER’S MANUAL VIEW THIS MANUAL ONLINE AT OLIVERTRAVELTRAILERS.COM...
  • Page 3 The purpose of this manual is to answer questions that commonly occur. Read it in its entirety. We want you to enjoy your Oliver Travel Trailer to the fullest and to help make your road to vacationing freedom more pleasant and relaxing.

  • Page 4: Table Of Contents

    TABLE OF CONTENTS INTRODUCTION TOWING & SETUP 6 OVERVIEW 20 TOWING VEHICLE REQUIREMENTS 6 GETTING ACQUAINTED DRIVING TIPS OPERATING INSTRUCTIONS 7 COMPONENT 22 LOADING AND WEIGHT DISTRIBUTION 7 SEE OUR VIDEOS ON YOUTUBE 25 COUPLING 7 SCAN THE QR CODES FOR QUICK ACCESS 28 BRAKE CONTROLLER 7 CAUTION AND INFORMATION SYMBOLS 28 ELECTRIC JACK STABILIZATION SYSTEM...
  • Page 5 84 CABINETS, COUNTERTOPS, & APPLIANCES 70 AWNING 85 ROOF VENTS 71 STORAGE BASKET 85 LIGHTING 72 CURBSIDE FOLDABLE TABLE 85 CONDENSATION 72 REAR BUMPER RECEIVER 86 STORING YOUR OLIVER 87 TIRES 89 CHANGING A TIRE 90 TIRE SAFETY INFORMATION 103 MAINTENANCE SCHEDULE...

  • Page 6: Overview

    We reserve the right to change the construction or material of any part(s) at any time without incurring the obligation to install such changes on delivered units. Oliver Travel Trailers, Inc. is furnishing you with this guideline to assist you through your travels. If further assistance is needed, please contact our technical support department (888) 526-3978 during our normal business hours of Mon-Friday, 8 AM - 5 PM CST.

  • Page 7: Component Operating Instructions

    INFORMATION PRECEDED BY THESE SYMBOLS. FAILURE TO DO SO MAY RESULT IN PRODUCT DAMAGE, CAUTION ⚠ SERIOUS INJURY, OR DEATH. • READ THE ENTIRE MANUAL AND HEED ALL CAUTION DANGER ⚠ AND WARNING STATEMENTS PRIOR TO OPERATION OF YOUR OLIVER TRAVEL TRAILER. NOTICE...

  • Page 8: Weight Rating Definitions

    Be sure to read all warnings and instructions before operating your recreational vehicle. The Oliver Travel Trailer VIN (Vehicle Identification Number) is located on the driver’s side, towards the lower front of the trailer in the area of the reflector.
  • Page 9 INTRODUCTION TRAVEL TRAILER LEGACY ELITE II SPECIFICATIONS GVWR 7,000 LBS DRY WEIGHT (APPROX.) 4,900 LBS TONGUE WEIGHT (APPROX.) 490 LBS OUTSIDE LENGTH 23’ 6” OUTSIDE HEIGHT 8’ 6” OUTSIDE HEIGHT (TOP OF A/C UNIT) 9’ 7” OUTSIDE WIDTH 7’ INSIDE HEIGHT 6‘...

  • Page 10: Limited Warranties

    Oliver will not be liable for any damages as a result of any delay or failure to timely deliver for any reason.

  • Page 11: What Is Not Covered

    Buyer in whatever form or nature arising out of or in connection with the products sold to Buyer if Oliver is proven to have no cause in the occurrence. This provision does not limit in any way any term, feature, or benefit specified...

  • Page 12: Changes And Improvements

    If the particular model of goods ordered by the Buyer has been replaced by a new model, Oliver may at its option ship the new model of such goods.

  • Page 13: Warranty Authorization

    Oliver may recommend a service provider or may request the travel trailer to be returned to Oliver for repair. Warranty repairs made without authorization may be subject to denial or partial payments.

  • Page 14: Safety

    SAFETY LP SYSTEM SAFETY SAFETY REGULATIONS These guidelines are for the safe usage of the LP gas systems and appliances. The following warnings are posted throughout your recreational vehicle to provide information on the LP gas system. They have been installed not only because of requirements to do so but also as a constant reminder to our customers to exercise proper caution when using or being around LP gas appliances and equipment.
  • Page 15 SAFETY WARNING THE PROPANE PIPING SYSTEM IS DESIGNED FOR USE ⚠ WITH PROPANE ONLY. DO NOT CONNECT NATURAL GAS TO THIS SYSTEM. SECURELY CAP INLET WHEN NOT CONNECTED FOR USE. AFTER TURNING ON PROPANE, EXCEPT AFTER NORMAL CYLINDER REPLACEMENT, TEST PROPANE PIPING AND CONNECTIONS TO APPLIANCES FOR LEAKAGE WITH SOAPY WATER OR BUBBLE SOLUTION.

  • Page 16: Alarms

    SAFETY WARNING GAS COOKING APPLIANCES NEED FRESH AIR FOR SAFE ⚠ OPERATION. BEFORE OPERATING: • OPEN VENTS OR WINDOWS SLIGHTLY OR TURN ON EXHAUST FAN PRIOR TO USING COOKING APPLIANCE. • GAS FLAMES CONSUME OXYGEN, WHICH SHOULD BE REPLACED TO ENSURE PROPER COMBUSTION. •...

  • Page 17: Fire Safety

    SAFETY FIRE SAFETY WARNING DO NOT USE PORTABLE FUEL BURNING EQUIPMENT, ⚠ INCLUDING WOOD AND CHARCOAL GRILLS AND STOVES, INSIDE THE RECREATIONAL VEHICLE BECAUSE THE USE OF SUCH EQUIPMENT INSIDE THE RECREATIONAL VEHICLE CAN CAUSE FIRES OR ASPHYXIATION. FAILURE TO DO SO CAN RESULT IN DEATH OR SERIOUS INJURY. Fire safety is an important part of owning a recreational vehicle.

  • Page 18: Emergency Egress Window

    SAFETY 4. Feel doors before opening them to see if they are hot. If a door is cool, open it slowly DO NOT and check for fire and heat before you proceed. open a hot door – use an alternate escape route. Stay close to the floor if air is smoky. Take short shallow breaths through a wet cloth if possible.

  • Page 19: Reporting Safety Defects

    If you believe that your vehicle has a defect, which could cause a crash or could cause injury or death, you should immediately inform the National Highway Traffic Safety Administration (NHTSA) in addition to notifying Oliver Travel Trailers. If NHTSA receives similar complaints, it may open an investigation and if it finds that a safety defect exists in a group of vehicles, it may order a recall and remedy campaign.

  • Page 20: Towing & Setup

    TOWING & SETUP This section covers coupling, towing, and other important steps to setup your trailer for camping. TOWING VEHICLE REQUIREMENTS WARNING • AN IMPROPERLY COUPLED TRAILER CAN RESULT IN ⚠ DEATH OR SERIOUS INJURY. USE OF A TOW VEHICLE WITH A TOWING CAPACITY LESS THAN THE LOAD RATING OF THE TRAILER CAN RESULT IN LOSS OF CONTROL, AND MAY LEAD TO DEATH OR SERIOUS...

  • Page 21: Driving Tips

    TOWING & SETUP DRIVING TIPS GENERAL Get to know how your tow vehicle handles with the added weight of your RV. The brakes and steering operation will be different. Before taking a trip practice making right and left turns, braking, backing up, and accelerating. CLEARANCE Watch for overhanging branches, awnings, or similar obstructions that can damage your vehicle’s roof or equipment/accessories mounted on top of it.

  • Page 22: Loading And Weight Distribution

    Check the telephone directory, online, or with local authorities for the location of weigh stations in your area. If you find that you have exceeded the GVWR of the Oliver, you will have to remove items until you are within specified limits.
  • Page 23 Therefore, if you are towing a 6000 lbs. trailer, the tongue weight should be measured at approximately 600 lbs. Oliver Travel Trailers confirms that the tongue weight is 9-15% of the dry weight before the trailer leaves the factory.
  • Page 24 TOWING & SETUP Now that you have these weights recorded, check to see if you can safely pull your Oliver with your tow vehicle. The GVW (Gross Vehicle Weight) of the trailer must not exceed 7,000 lbs. Your tongue weight should be between 9-15% of that weight. If these weights are within regulation, then feel free to enjoy the open road! https://catscale.com/...

  • Page 25: Coupling

    COUPLING For operating instructions and troubleshooting, view the manufacturer’s manual. Your Oliver Travel Trailer is equipped with a Class III Bulldog Steel Coupler rated for the GVWR of your trailer. The standard bulldog coupler requires a 2” ball on your tow vehicle. You may have upgraded the bulldog hitch to the 2-5/16”...
  • Page 26 TOWING & SETUP 1. Visually inspect the electrical wires from the switch box to where they are connected into the battery system and the brake system. Make sure the wires are not broken or damaged. Make sure the black coating is not damaged and that the copper wire is not exposed anywhere along the wire or at the connection point.
  • Page 27 TOWING & SETUP 1. Loose or corroded connections may cause brake failure. Solder all wire connections. 2. The breakaway switch is connected to the travel trailer’s battery system. Low or dead batteries may cause brake failure. Do not use the safety brake system as a parking brake.

  • Page 28: Brake Controller

    TOWING & SETUP BRAKE CONTROLLER ELECTRONIC BRAKE CONTROLLER ADJUSTMENT : Refer to manufacturer for more information. NOTICE A BRAKE CONTROLLER IS REQUIRED IN YOUR TOW VEHICLE WHICH WILL SYNCHRONIZE YOUR TRAILER BRAKES. IT MAY BE NECESSARY TO ADJUST THE BRAKE CONTROLLER.

  • Page 29: Braking And Burnishing Brakes

    TOWING & SETUP MANUAL OPERATION OF FRONT JACK On the tongue jack, access to the jack post can be obtained by twisting the retaining ring and bulls-eye level counterclockwise. Insert the emergency jack wrench handle onto the jack post and crank the emergency hand crank wrench to raise or lower the jack as required.

  • Page 30: Towing Check List

    TOWING & SETUP TOWING CHECK LIST 1. Close and Secure all interior drawers and doors. 2. Close all windows and draw all blinds. 3. Secure the microwave plate. 4. Close the roof vents. 5. Close the backflow preventer valve. 6. Close and lock the storm door and the entry door. 7.

  • Page 31: Set Up Check List

    TOWING & SETUP SET UP CHECK LIST 1. Pull or back into the campsite and ensure the trailer is level from side to side using leveling blocks. Chock tires and disconnect safety chains, 7-PIN cable, and breakaway switch. 2. Unlock the trailer coupler from the hitch ball by pushing the lever on the coupler forward.

  • Page 32: Electrical

    When it is not possible to access 120-volt power, the 12-volt battery system can supply the 12-volt system functions. The battery system is rechargeable by power converter/ battery charger when the Oliver is attached to an outside 120-volt power source, by use of an external generator, or optional solar package.

  • Page 33: Connecting To A Generator

    For operating instructions and troubleshooting, view the manufacturer’s manual. BATTERY COMPARTMENT The battery compartment is located on the street side of your Oliver. The marine-style latch can be locked using the small key found on your key ring. After opening the battery compartment box, you will notice a slide-out tray holding your batteries.

  • Page 34: Battery Safety

    ELECTRICAL BATTERY SAFETY WARNING • ALWAYS SHIELD YOUR EYES WHEN WORKING NEAR ⚠ BATTERIES • BATTERIES CAN EXPLODE!! DO NOT SMOKE OR EXPOSE ANY BATTERY TO ELECTRIC SPARKS OR FLAME. BATTERIES GENERATE HYDROGEN WHEN CHARGING OR DISCHARGING. HYDROGEN AND AIR ARE A VERY EXPLOSIVE MIXTURE.

  • Page 35: Standard 12-Volt Batteries

    ELECTRICAL STANDARD 12-VOLT BATTERIES Note: Battery Jumpers are 4/0 If your trailer is equipped with the standard batteries, you will find four wet cell batteries installed. The standard equipment batteries are RV or Marine Deep Cycle, Lead-Acid types. These batteries contain lead plates and liquid sulfuric acid electrolytes in sections called cells. If wet cell batteries are installed on your trailer, they are maintenance free and do not require topping off.

  • Page 36: Inverter/Charger

    ELECTRICAL The built-in Charge Wizard is a microprocessor-controlled system that constantly monitors the battery voltage and ensures rapid; yet, safe, recharge. The Charge Wizard can select one of three charging voltages and one of four operating modes depending on the condition and use of the battery. BOOST MODE: If the voltage drops below a preset level the output voltage is increased to approximately 14.4 VDC to rapidly recharge the battery.
  • Page 37 ELECTRICAL SETTING # SETTING NAME ELITE II BATTERY PACKAGE TYPE --> 6V AGM 440 AH 12V LITHIUM 12V LITHIUM 390 AH 640 AH INVERTER IGNITION CONTROL LBCO VOLTAGE 10.5V 12.1V 12.1V LBCO SHUTDOWN DELAY TIMER LBCO RECOVERY VOLTAGE 13.1V 13.1V 13.1V POWER SAVE TIME POWER SAVE MODE (LOAD SENSING)

  • Page 38: Solar Package

    ELECTRICAL WARNING YOUR OLIVER CAMPER IS EQUIPPED WITH AN ONBOARD ⚠ SURGE PROTECTOR THAT CONTROLS INCOMING SHORE POWER AND SHUTS IT OFF WHEN THE VOLTAGE DROPS BELOW 104V OR GOES ABOVE 132V. LEAVING THE INVERTER ON TO TRANSITION INTO BATTERY MODE AUTOMATICALLY MAY RESULT IN BATTERY DISCHARGE.

  • Page 39: Agm Batteries

    ELECTRICAL ELECTRICAL 3/8” Marine Terminal (+) AGM BATTERIES (OPTIONAL EQUIPMENT) LEGACY ELITE II For operating instructions and troubleshooting, view the manufacturer’s manual. The 6-volt AGM Battery is specifically designed for deep-cycle applications. The Elite II (FOUR BATTERIES) model has four 6-volt batteries wired in series & parallel to provide 12-volt power. AGM batteries can effectively deliver 50% of their total amp hour capacity.

  • Page 40: 130 Ah Lithium Batteries

    ELECTRICAL 130 AH LITHIUM BATTERIES (OPTIONAL EQUIPMENT) For operating instructions and troubleshooting, view the manufacturer’s manual. When a charge cycle is desired on the batteries and the temperature outside the trailer is above freezing then no action is needed. If the temperature outside the trailer is below freezing, the Lithium batteries will need to be warmed before they can be charged.
  • Page 41 ELECTRICAL 130 AH LITHIUM BATTERIES PROPER RESTART If the inverter is OFF, drained or has entered Low Battery Cut Off (LBCO) and any or all of the batteries are OFF (no LED light on battery), you must properly restart/reboot the system to avoid damaging the internal Battery Management System (BMS).

  • Page 42: Lithium Battery Storage Procedure

    ELECTRICAL 2023 Elite II – Other 12V Breakers & Fuses BUSBAR CONNECTIONS & ADDITIONAL LITHIUM BATTERY STORAGE PROCEDURE FUSING/BREAKERING INFO. STUD A Storing your lithium batteries at the correct specifications is important as it keeps the EXTERIOR SOLAR PORT 15 AMP (ATC FUSE) SOLAR SHUNT POWER 1 AMP (SLOW BLOW) battery in the healthiest state possible for the fastest deployment when needed.
  • Page 43 ELECTRICAL 2023 120V Panel, Pro 2000W Inverter Configuration 120V BREAKER DESCRIPTIONS Cir. #1 AIR CONDITIONER 15 AMP* 2023 120V Panel, Pro 2000W Inverter Configuration Cir. #2 FRIDGE / WATER HEATER 20 AMP** Cir. #3 INVERTER 25 AMP 120V BREAKER DESCRIPTIONS MAIN —...
  • Page 44 If a fuse is blown, replace it with a fuse of the same amp rating. Do not replace it with a larger fuse than indicated. If the fuse continues to blow, contact the Oliver Travel Trailer Technical support department or a qualified RV service center for assistance.
  • Page 45 ELECTRICAL 2023 12V Panel Configuration * WIFI, CELL BOOSTER, BACK-UP CAM- 12V FUSE DESCRIPTIONS ERA, TV, TANK MONITOR, OMNI-DIRECTIONAL ANTENNA REFRIGERATOR 15 AMP ** 12V SOCKET/USB AT DINETTE, *ELECTRONICS 15 AMP 12V SOCKET/USB UNDER ATTIC *** 12V SOCKET IN ATTIC, WATER PUMP 15 AMP 12V SOCKET/USB IN KITCHEN...

  • Page 46: Outlets And Charging Stations

    NOTICE GFCI IS ONLY ENERGIZED WHEN AC POWER IS PRESENT. If any of the three are tripped, reset them. If they continue to trip, contact the Oliver Travel Trailer Technical support department or a qualified RV service center for assistance.
  • Page 47 ELECTRICAL CABINET LIGHTS switch controls the LED lights in the upper cabinets. DINETTE LIGHTS are touch-enabled LED lights. Touch the center of each light to turn on or off as desired. The MASTER LIGHTS switch will turn these lights off but not on. REAR LEFT LIGHTS are touch-enabled LED lights.

  • Page 48: Overview

    Freshwater is provided from an external pressurized source or from the freshwater storage tank. These connections on the Oliver are located at the rear, bottom driver side corner of the trailer. PLUMBING SYSTEM - CURBSIDE ACCESS PANELS Most of the important plumbing components and valves are found under the curbside seating access panels.

  • Page 49: Water Pump & Accumulator

    Under other PLUMBING PEX lines IMPORTANT PLUMBING SYSTEM COMPONENTS & VALVES LEGACY ELITE II UNDER FRONT CURBSIDE SEATING ACCESS PANEL Under other PEX lines 1. WATER PUMP 2. WATER PUMP STRAINER 3. FACTORY INSPECTION VALVE (ALWAYS LEAVE OPEN) 4. ACCUMULATOR 5.

  • Page 50: Tank Monitoring

    The city water connection is located on the lower rear street side of the trailer. Water provided from outside the Oliver is pressurized by the system from which it is delivered. When you connect your Oliver to an outside source, the freshwater tank and the water...
  • Page 51 2. Attach a potable water hose to the outside source of water. An external water filter is recommended. 3. Connect the other end of the hose to the Oliver city water inlet. Be sure to use a pressure regulator (included at delivery) with a maximum 55 PSI.
  • Page 52 PLUMBING NOTICE • IF YOU NOTICE WATER LEAKING UNDER THE CAMPER YOU MAY NEED TO CLOSE THE FRESH TANK DRAIN VALVE. • ALWAYS FILL THE TANK WITH CLEAN WATER FROM A KNOWN SAFE SOURCE. MAKE SURE TO CAP THE WATER INLET WHEN THE TANK IS FILLED. ALSO, ALWAYS FILL THE SYSTEM WITH A HOSE THAT YOU KNOW IS CLEAN AND IS USED ONLY FOR THIS PURPOSE.

  • Page 53: Suburban Water Heater

    PLUMBING TO FILL THE FRESHWATER TANK FROM A PORTABLE POTABLE WATER CONTAINER (NON-PRESSURIZED): 1. Remove the cap from the rear water inlet at the rear of the travel trailer. 2. Attach a cut-off potable hose to the rear water inlet that is 2 feet max in length. 3.

  • Page 54: Truma Aquago Water Heater

    PLUMBING TRUMA AQUAGO WATER HEATER (OPTIONAL EQUIPMENT) For operating instructions and troubleshooting, view the manufacturer’s manual. FAUCETS AND SHOWER BATHROOM FAUCET The bathroom faucet is installed with a flexible hose for showering and for cleaning the shower. To turn on the bathroom faucet, lift the handle up to open the flow of water. Turn the lever counter-clockwise to adjust the water to the desired temperature.

  • Page 55: Toilet

    Also, leave the bath door open when the unit is not in use. This allows circulation of air and prevents mildew. TOILET Your Oliver Travel Trailer is equipped with either a standard porcelain toilet or an optional composting toilet. For operating instructions and troubleshooting, view the manufacturer’s manual.
  • Page 56 PLUMBING HOLDING TANKS The Oliver Travel Trailers holding tanks hold 30 gallons in the grey tank and 15 gallons in the black tank. Each tank should be emptied often at a dump station designated for this purpose. Most national, state, and private campgrounds have dumping facilities. Many service stations, particularly along interstate highways, also have these facilities and are listed dumping station locations across the nation.
  • Page 57 BACKFLOW PREVENTER IS CLOSED BEFORE TRAVELING. BLACK TANK FLUSH PORT Your Oliver comes standard with a black tank flush port on the street side near the bottom of the unit; this allows you to connect an outside water supply and rinse out your black tank.

  • Page 58: Water System Troubleshooting

    If the Oliver is used in cold weather and left unheated for an extended period, the water in a tank or drain line may freeze. If this occurs, you should take immediate steps to thaw it...
  • Page 59 WINTERIZATION PROTOCOL: Before we begin, please ensure your Black, Grey, and Freshwater tanks are empty. Also, we do not recommend using blown air to winterize your Oliver Travel Trailer. Doing so may damage your plumbing system. 1. The first step in the winterization process is to turn off the gas on all propane gas tanks connected to your travel trailer.
  • Page 60 PLUMBING 3. Next, you will need to close the by-pass valve on your Suburban or Truma water heater. 4. You can access the water heater by-pass valve through the curbside access panel below the bedding. 5. The bypass valve will be located near the back of the water heater. 6.
  • Page 61 PLUMBING 21. Open the outside wash station above the inlets and pull out the faucet from its holder and depress the button on the faucet head to lock the button in place. Then, turn on the cold water. 22. Prime the hand pump until antifreeze fills both hoses and pump antifreeze into the line until the flow from the faucet turns from water to antifreeze.

  • Page 62: De-Winterization

    PLUMBING 32. If your unit is equipped with a Truma AquaGo, drain the water heater by lifting up the black tab while pulling down the yellow Easy-Drain Lever. Doing so will eject the unit’s inlet filter which should NOT be reinstalled while the travel trailer is winterized. 33.

  • Page 63: Sanitization

    This may sound tedious but with your Oliver Travel Trailer you can simply use the rear water inlet at the rear of the camper and let it do most of the work for you. Watch the Sanitization video on YouTube.

  • Page 64: Decalcification Of Plumbing Sys

    PLUMBING 3. Check to ensure that the fresh tank drain valve is closed (see FIG 1 - 5 on page 53). 4. If water pump valves are not already in boondock mode, then reconfigure valves accordingly. See valve configuration diagrams on page 52. 5.
  • Page 65 PLUMBING Decalcification of the fresh water fixtures can be done at any time and should be done periodically when hard water has been used in the fresh water system. WHAT IS HARD WATER? All water contains dissolved minerals and nutrients, but some sources of water contain more minerals than others.
  • Page 66 PLUMBING LEGACY ELITE II PLUMBING DIAGRAM Elite II – Pex Layout Standard Water Heater Truma AquaGo Water Heater Cold Cold Water Accumulator Pressure Side Suction Side Water Heater Rear Inlet Suction Fill Fresh Water Tank Tank Drain Connects to Black Water Tank Black Tank Flush Inlet Outside Tank Fill...

  • Page 67: Propane

    The propane tanks are stored in the fiberglass propane tank housing located at the front of your travel trailer. Your Oliver comes standard with two 20 pound propane tanks or you may have upgraded to two 30 pound propane tanks.

  • Page 68: Using The Regulator

    PROPANE USING THE REGULATOR To supply gas to the components that use propane, you will need to open the valves on the propane tanks. The regulator controls the flow of propane throughout the LP lines. The two-stage automatic changeover regulator controls the flow of propane throughout the LP lines.

  • Page 69: Exterior

    Oliver Travel Trailer. Make sure to keep fingers away from the sliding mechanism when extending or retracting the steps. Use extra caution if exiting or entering the Oliver without the use of the step.

  • Page 70: Awning

    DAMAGE CAUSED BY COLLISIONS WITH ANY OF THE ABOVE OR SIMILAR IS NOT COVERED BY WARRANTY. All Oliver Travel Trailers come standard with a powered curbside awning. On Legacy Elite II models, we also offer an optional awning available on the street side of the trailer.

  • Page 71: Storage Basket

    EXTERIOR NOTICE BEFORE USING THE REMOTE, ENSURE THE AWNING POWER SWITCH(ES) ON THE MAIN SWITCH PANEL IS IN THE ON POSITION. ALWAYS CLOSE THE AWNING AND TURN OFF THE AWNING POWER SWITCH TO THE AWNING BEFORE TRAVELING. BE SURE TO CHECK FOR DEBRIS ON THE AWNING BEFORE RETRACTING.

  • Page 72: Rear Bumper Receiver

    EXTERIOR CURBSIDE EXTERIOR FOLDABLE TABLE WARNING NEVER EXCEED THE WEIGHT LIMIT OF 20 LBS ON THE ⚠ TABLE. Your travel trailer is equipped with an exterior foldable up table that is ideal for placing drinks, food, or cooking utensils on while cooking outside or enjoying a relaxing evening. To use the exterior table, turn the marine-grade latch and pull the table up.

  • Page 73: Interior

    INTERIOR MAXXAIR CABIN FAN The MaxxAir fan installed in your Oliver functions as an effective air exhaust or intake. The 12-volt fan is operated either remotely or using the built-in switch panel. It is recommended to use the MaxxAir fan while cooking. The remote will be located in either your kitchen galley drawer or pantry.

  • Page 74: Countertops

    For operating instructions and troubleshooting, view the manufacturer’s manual. REFRIGERATOR The refrigerator-freezer combo in your Oliver can be operated two ways; AC (120-volt shore power) or DC (12-volt battery power). When the refrigerator is in auto mode it will automatically switch between AC and DC. There is a cold setting button to cycle cold levels from 1 to 7.

  • Page 75: Microwave

    ENTERTAINMENT SYSTEM If your Oliver is equipped with the full entertainment system it consists of a stereo/DVD head unit, a TV, and four speakers located throughout the main cabin.

  • Page 76: Television

    INTERIOR TELEVISION You will find remotes for both the smart TV and stereo located in the kitchen galley drawer at delivery. The TV operates on 120-volt power. If you are camping off-grid and your trailer is equipped with an inverter, you will need to turn the inverter on to operate the TV.

  • Page 77: Interior Storage

    On the inside of your Ollie, you will find plenty of storage for all your personal items. The oversized closet in your Oliver provides Ample storage with its two shelves and clothes hanging rod. If you have opted for the standard floor plan, you will notice a filler panel on the wall in the closet.

  • Page 78: Seating And Sleeping

    DINETTE The dinette area of your Oliver is furnished with a table and two seats that easily transform into a sleeping area. It is easy to convert the dinette into a single bed.
  • Page 79 INTERIOR...
  • Page 80 INTERIOR...

  • Page 81: Maintenance

    NOTE: Do not use a rubbing compound or any abrasive cleaner or abrasive cloth on the Oliver. If using a tar and insect remover, make sure it is safe for use on painted surfaces.

  • Page 82: Frames

    This will add years of life to your chassis. You will need to check these every few years and replace as needed. You should wash the frame regularly, especially when towing the Oliver in the winter, in areas where road salts are used.

  • Page 83: Windows And Doors

    MAINTENANCE WINDOWS AND DOORS Check the seals around the windows and doors at regular intervals. Follow previous instructions for checking the condition of seals and repairing as necessary. • Make sure that windows remain operative by adjusting and lubricating latches and moving parts annually.

  • Page 84: Propane

    MAINTENANCE PROPANE WARNING FAILURE TO COMPLY COULD RESULT IN SERIOUS INJURY ⚠ OR DEATH. The hoses, pipes, tubes, and fittings used in your LP system are designed to withstand pressures far exceeding those of the LP system. However, because environment and time can contribute to the deterioration of these components, they must be inspected for wear at regular intervals.

  • Page 85: Roof Vents

    CONDENSATION Every Oliver camper is designed for 4-Season camping however cold weather can bring along with it unwanted moisture. This natural phenomenon brings positive and negative effects for your camper. The increase of moisture in the air can make the air feel warmer but it also brings the possibility of condensation inside your camper.

  • Page 86: Storing Your Oliver

    If storing the travel trailer (or other extreme conditions), certain precautions need to be taken to protect it until you use it again. Make sure to talk with Oliver concerning any special requirements for storage in your particular geographic area. The following steps are general and Oliver can help you choose those that are most appropriate for your needs.

  • Page 87: Tires

    Don’t over or under inflate. Under inflated tires will run hot, shorten the tire’s life and decrease the Oliver safe load limit. Over inflated tires will cause a rough and bouncing ride that can damage RV components or cargo. It is a good idea to always carry an accurate tire pressure gauge in the RV to make these checks.
  • Page 88 MAINTENANCE NOTE: Cold tire inflation pressure is defined as a tire that has not been used for three or more hours, or has been driven less than one mile. Tire inflation pressure of a hot tire may show an increase of as much as 6 psi over a cold tire. Measure and adjust tire pressure when the tires are cold.

  • Page 89: Changing A Tire

    MAINTENANCE CHANGING A TIRE WARNING • NEVER CHANGE ANY TIRE WITHOUT SECURELY ⚠ CHOCKING THE REMAINING WHEELS. NEVER POSITION YOURSELF UNDER A RAISED TRAILER THAT COULD FALL ON YOU AND CAUSE SERIOUS INJURY OR EVEN DEATH! • FAILURE TO RE-TIGHTEN WHEEL NUTS AS REQUIRED COULD ALLOW WHEELS TO COME OFF WHILE THE VEHICLE IS IN MOTION, CAUSING LOSS OF CONTROL, POSSIBLE COLLISION, SERIOUS INJURY OR EVEN...

  • Page 90: Tire Safety Information

    MAINTENANCE TIRE SAFETY INFORMATION This portion of the User’s Manual contains tire safety information as required by 49 CFR 575.6. Section 1.1 contains “Steps for Determining Correct Load Limit - Trailer”. Section 1.2 contains “Steps for Determining Correct Load Limit – Tow Vehicle”. Section 1.3 contains a Glossary of Tire Terminology, including “cold inflation pressure”, “maximum inflation pressure”, “recommended inflation pressure”, and other non- technical terms.
  • Page 91 MAINTENANCE If your trailer has a GVWR of 10,000 pounds or less, there is a vehicle placard located in the same location as the certification label described above. This placard provides tire and loading information. In addition, this placard will show a statement regarding maximum cargo capacity.
  • Page 92 MAINTENANCE The trailer’s placard refers to the Tire Information Placard attached adjacent to or near the trailer’s VIN (Certification) label at the left front of the trailer. 1.1.2. TRAILERS OVER 10,000 POUNDS GVWR (NOTE: THESE TRAILERS ARE NOT REQUIRED TO HAVE A TIRE INFORMATION PLACARD ON THE VEHICLE) 1.
  • Page 93 MAINTENANCE CARCASS: The tire structure, except tread and sidewall rubber which, when inflated, bears the load. CHUNKING: The breaking away of pieces of the tread or sidewall. COLD INFLATION PRESSURE: The pressure in the tire before you drive. CORD: The strands forming the plies in the tire. CORD SEPARATION: The parting of cords from adjacent rubber compounds.
  • Page 94 MAINTENANCE LIGHT TRUCK (LT) TIRE: A tire designated by its manufacturer as primarily intended for use on lightweight trucks or multipurpose passenger vehicles. LOAD RATING: The maximum load that a tire is rated to carry for a given inflation pressure. MAXIMUM LOAD RATING: The load rating for a tire at the maximum permissible inflation pressure for that tire.
  • Page 95 MAINTENANCE PLY SEPARATION: A parting of rubber compound between adjacent plies. PNEUMATIC TIRE: A mechanical device made of rubber, chemicals, fabric and steel or other materials, that, when mounted on an automotive wheel, provides the traction and contains the gas or fluid that sustains the load. PRODUCTION OPTIONS WEIGHT: The combined weight of those installed regular production options weighing over 2.3 kilograms (5 lbs.) in excess of those standard items which they replace, not previously considered in curb weight or accessory weight,...
  • Page 96 MAINTENANCE VEHICLE CAPACITY WEIGHT: The rated cargo and luggage load plus 68 kilograms (150 lbs.) times the vehicle’s designated seating capacity. VEHICLE MAXIMUM LOAD ON THE TIRE: The load on an individual tire that is determined by distributing to each axle its share of the maximum loaded vehicle weight and dividing by two.
  • Page 97 MAINTENANCE • Fundamental characteristics of tires • Tire safety tips. Use this information to make tire safety a regular part of your vehicle maintenance routine. Recognize that the time you spend is minimal compared with the inconvenience and safety consequences of a flat tire or other tire failure. 1.5.
  • Page 98 MAINTENANCE 1.5.3. CHECKING TIRE PRESSURE It is important to check your vehicle’s tire pressure at least once a month for the following reasons: • Most tires may naturally lose air over time. • Tires can lose air suddenly if you drive over a pothole or other object or if you strike the curb when parking.
  • Page 99 MAINTENANCE placard, the owner’s manual, or the sidewall of the tire you are replacing to find this information. If you have any doubt about the correct size to choose, consult with the tire dealer. 1.5.6. TIRE TREAD The tire tread provides the gripping action and traction that prevent your vehicle from slipping or sliding, especially when the road is wet or icy.
  • Page 100 MAINTENANCE 1.5.9.1. INFORMATION ON PASSENGER VEHICLE TIRES P: The “P” indicates the tire is for passenger vehicles. NEXT NUMBER: This three-digit number gives the width in millimeters of the tire from sidewall edge to sidewall edge. In general, the larger this number is, the wider the tire. NEXT NUMBER: This two-digit number, known as the aspect ratio, gives the tire’s ratio of height to width.
  • Page 101 MAINTENANCE LETTER RATING SPEED RATING 99 MPH 106 MPH 112 MPH 118 MPH 124 MPH 130 MPH 149 MPH 168* MPH 186* MPH * For tires with a maximum speed capability over 149 mph, tire manufacturers sometimes use the letters ZR. For those with a maximum speed capability over 186 mph, tire manufacturers always use the letters ZR.
  • Page 102 MAINTENANCE TEMPERATURE LETTER: This letter indicates a tire’s resistance to heat. The temperature grade is for a tire that is inflated properly and not overloaded. Excessive speed, under inflation or excessive loading, either separately or in combination, can cause heat build-up and possible tire failure.

  • Page 103: Maintenance Schedule

    MAINTENANCE MAINTENANCE SCHEDULE 1. Heavy usage such as using the recreational vehicle as a residential vehicle will require more frequent maintenance even if the camper is stationary. 2. Dusty environments will require more frequent maintenance. 3. Heavy use in Coastal and/or Snowy area with road salts will require more frequent maintenance.
  • Page 104 MAINTENANCE NOTES...
  • Page 106 OLIVER TRAVEL TRAILERS SERVICE DEPT. 228 INDUSTRIAL AVE HOHENWALD, TENNESSEE 38462 TOLL FREE: 888-526-3978 EMAIL: SERVICE@OLIVERTRAVELTRAILERS.COM SEE OUR VIDEOS AT OLIVERTRAVELTRAILERS.COM...
