GILBARCO VEEDER-ROOT NC3L Installation And Maintenance Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
NC3L
Verifone 12"
71A8462520GB
E03 03/05/2022

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NC3L and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for GILBARCO VEEDER-ROOT NC3L

  • Page 1 NC3L Verifone 12” 71A8462520GB E03 03/05/2022...

  • Page 2: C O Py R Ig Ht

    NC3L Verifone 12" - Installation and maintenance C O P Y R I G H T The information included in this manual is subject to change depending on the evolution of the product; the user shall be taken care of verify the release before use it.

  • Page 3: R Emar Ks

    NC3L Verifone 12" - Installation and maintenance R E M A R K S These symbols indicate that this product is not to be disposed of with common household waste, according to the WEEE Directive (2012/19/EU). This product should be handed over to a designated collection point, e.g., on an authorized one-for-one basis or to an authorized collection site for recycling waste electrical and electronic equipment (EEE) and batteries and accumulators.

  • Page 4: War N In G

    NC3L Verifone 12" - Installation and maintenance W A R N I N G WARNING THE UNIT BEING THE SUBJECT-MATTER OF THIS MANUAL SHALL BE INSTALLED AND COMMISSIONED BY TRAINED PERSONNEL Trained personnel mean people with the appropriate technical education and...

  • Page 5: Table Of Contents

    NC3L Verifone 12" - Installation and maintenance T A B L E O F C O N T E N T S C O PY R IG HT ..............I R EMAR KS ............... III N O T E ................III WAR N IN G ........
  • Page 6 NC3L Verifone 12" - Installation and maintenance N C 3 L PO WER -O N PR O C EDUR E F OR T EMPER AT UR ES L O WER T HAN 0 °C ............... 2 6 T B SP2 B O AR D ............2 7 9.1 .

  • Page 7: 1 . D E F I N I T I O N

    NC3L Verifone 12" - Installation and maintenance 1 . D E F I N I T I O N NC3L Verifone 12” (Nordic Card 3 Landscape) is a payment terminal designed for card payment only, can be installed on dispenser.
  • Page 8 NC3L Verifone 12" - Installation and maintenance It is available single sided or double sided. Double sided version has the two sides with specular layout, where printer panel and display panels are swapped. Single side is available with layout “A” or with layout ”B”, in this case the other side has a closed panel...

  • Page 9: 2 . T E R M I N A L O V E R V I E W

    NC3L Verifone 12" - Installation and maintenance 2 . T E R M I N A L O V E R V I E W NC3L Verifone 12” "Terminal representation could be slightly different due to different optional or customization”...
  • Page 10 NC3L Verifone 12" - Installation and maintenance "Terminal representation could be slightly different due to different optional or customization” PART DESCRIPTION Verifone card reader Printer paper roll Receipt printer Key lock Display cover Display unit Alarm opened door switch Supply board CRDI...

  • Page 11: Dimen Sio N

    NC3L Verifone 12" - Installation and maintenance 3 . D I M E N S I O N S 4 . W E I G H T NC3L Verifone 12”…………………………………………………………………………………………….... 50 kg...

  • Page 12: Un Pac Kin

    NC3L Verifone 12" - Installation and maintenance 5 . U N P A C K I N G...

  • Page 13: Ac Emen

    6 . P L A C E M E N T The placement of NC3L is flexible and requires only little space since all operative actions are carried out from the front. Required space in front of the terminal is shown in previous paragraphs.
  • Page 14 NC3L Verifone 12" - Installation and maintenance Dresser Wayne Global Star 3/4 square Dresser Wayne Global Star 5 slope Dresser Wayne Global Star 5 square...

  • Page 15: In St Al L At Io

    Interference is prevented by installing power a nd communications cables in separate cable ducts. Remove scrap cables from cable manholes. WARNING: before first device switching on, please refer to Chapter #5 “NC3L power-on procedure for temperatures lower than 0 °C”.

  • Page 16: Me C Ha Ni Ca L I Ns Ta Ll At I On

    1. Open the computer head doors, the computer head side and bottom panel, the airing panel and the two side pumps panels; also remove the cable pass through cover (part #21) on the NC3L terminal. 2. Pull out all the cables from the inside of the dispenser column to let them pass around of the NC3L terminal.
  • Page 17 NC3L Verifone 12" - Installation and maintenance 4. Fasten for half length the four M6 screws on the dispenser computer head thread. If there is any fixing thread available, fasten the screws with four M6 hexagonal nuts. WARNING Risk of tipping over.
  • Page 18 NC3L Verifone 12" - Installation and maintenance 5. Insert the four screws head in the keyhole shaped holes of NC3L terminal pushing it upward (1) and then moving it toward the column (2). 6. Open the reader/printer unit’s front doors (opening the keyhole cover and turning the key 90° clockwise).
  • Page 19 7. Open the pinpad/display unit’s doors. Turn the key inside the reader/printer unit, on left top, 90° clockwise and pull the safety lever. 8. Check the NC3L terminal is lined up with the dispenser head. Tighten up the four screws inside the NC3L terminal.
  • Page 20 NC3L Verifone 12" - Installation and maintenance 9. For each terminal side follow this sequence: insert additional two M6 screws with grower washers and nuts inside the computer head, then tighten up.

  • Page 21: E Le C Tr Ic Al I Ns Ta L La T I O N

    E L E C T R I C A L I N S T A L L A T I O N In the following diagram you can see the cables connections that needs to be done to install the NC3L.
  • Page 22 NC3L Verifone 12" - Installation and maintenance 11. The cables need to be held with cable clamps placed on the NC3-L chassis below the cables cover. Cable shield shall touch the clamp. 12. Connect the AC mains cable to the dispenser head power supply terminal block.
  • Page 23 Bending the cable too sharply or repeatedly may cause damage to the wires inside the cable. 15. Mount the cable channel cover (it may vary depending on fuel dispenser type) under the NC3L terminal hooking the two frontal hooks on the dowel screws, then insert the studs (of the opposite side) inside the...
  • Page 24 NC3L Verifone 12" - Installation and maintenance 16. Use supplied cleaning isopropanol-soaked cloth to clean the lower part and the corners area of the pump electronic head. 17. Apply the self-adhesive gaskets on four corners (as shown in picture). Remove the protection film from the weather cover and apply it to the lower part of the pump electronic head.
  • Page 25 21. Open the NC3L display door (side A) and turn ON the switch inside the unit at the top left edge. 22. Open the NC3L display door (side B) and turn ON the switch inside the unit at the top left edge.
  • Page 26 NC3L Verifone 12" - Installation and maintenance 8 . N C 3 L P O W E R - O N P R O C E D U R E F O R T E M P E R A T U R E S L O W E R T H A N 0 ° C WARNING: this procedure is recommended to guarantee the correct functioning of the terminal in term of performances and reliability.

  • Page 27: T B Sp2 B O Ar

    NC3L Verifone 12" - Installation and maintenance 9 . T B S P 2 B O A R D NC2L terminal is provided with two power supply input lines. The first line will feed heater module and the second line will feed the electronic boards.

  • Page 28: Fuse S

    NC3L Verifone 12" - Installation and maintenance Here the description of input and output connectors 9 . 1 . F U S E S There are two fuses on TBSP2, they are marked on PCB silkscreen as F1 and F2, see picture.

  • Page 29: 0 . C O Mpo N En T S An D Main T En An C

    1 0 . C O M P O N E N T S A N D M A I N T E N A N C E 10.1.1. Manual Card reader UX300 NC3L Verifone is equipper with Manual card reader Verifone UX300...
  • Page 30 NC3L Verifone 12" - Installation and maintenance CONNECTING TO A UX400 CONTACTLESS UNIT...
  • Page 31 NC3L Verifone 12" - Installation and maintenance The following pictures list ports pinout on the UX300 board. MDB POWER PORT This is the UX300 power supply connector This is the ethernet connector used to connect UX300 to LAN. Be carefully to do not connect LAN to other...
  • Page 32 NC3L Verifone 12" - Installation and maintenance 10.1.2. Manual Card reader maintenance The regular cleaning of the card reader reduces the reading failure rate and extends its life. Use the cleaning kit PN 8713883 to perform cleaning procedure. This kit consist of 5 cleaning cards and a compressed air can.
  • Page 33 NC3L Verifone 12" - Installation and maintenance The maintenance interval depends from the number of cards read and from environmental conditions. We recommend cleaning the reader every 3/6 months, following the instructions below. 1. Take a clean and dry Clean Card and insert it into the reader mouth.
  • Page 34 NC3L Verifone 12" - Installation and maintenance 4. The straw position is important; try to get as near the access mouth and the half of the Clean Card as possible. 5. Also try to keep the straw as parallel as possible to the Clean Card or at least with a small incidence angle.
  • Page 35 NC3L Verifone 12" - Installation and maintenance 1 0 . 2 . C O N T A C T L E S S C A R D R E A D E R U X 4 0 0 Cotactless card reader Verifone UX400 is an optional device connected to Verifone Card reader UX300. This card reader will let you use contactless cards.

  • Page 36: Co N Ta Ct Le S S Car D Re A De R U X400

    NC3L Verifone 12" - Installation and maintenance 10.2.1. Contactless card reader UX400 maintenance UX400 doesn’t need any maintenance. For antenna cleaning, never use thinner, trichloroethylene, or ketone- based solvents, they can deteriorate plastic parts. Use a soft cloth with neutral soap.

  • Page 37: Pi Np Ad

    1 0 . 3 . P I N P A D NC3L Verifone 12” is equipped with a secure Verifone pinpad, model UX110. Has 10 + 6 keypad: 10 numeric, 4 colored-embossed function, 2 navigation keys. Verifone pinpad UX110 has an USB connection type B For pinpad cleaning, never use thinner, trichloroethylene, or ketone-based solvents, they can deteriorate plastic parts.

  • Page 38: Re Ce I P T Pri N Te R

    NC3L Verifone 12" - Installation and maintenance 1 0 . 4 . R E C E I P T P R I N T E R NC3L is equipped with Custom TG2460HIII-EJ ticket printer 10.4.1. Paper roll specs This ticket printer will automatically load the printer roll once the edge of the paper is detected at the printer input slot.
  • Page 39 NC3L Verifone 12" - Installation and maintenance The paper edge must be with a clean cut to avoid problems on loading paper roll. Do not try to load paper with folds or no straight cut. Follow the instruction described at section “Paper roll replacement 10.4.5”...
  • Page 40 NC3L Verifone 12" - Installation and maintenance 10.4.4. Paper Unloading To unload paper from the printer head just press the two buttons simultaneously To avoid paper jam, it is mandatory to unload the paper roll in the following • Before access to the printer head area •...
  • Page 41 NC3L Verifone 12" - Installation and maintenance Then open the printer door Remaining paper must be removed by unloading procedure Unload paper by pressing the two buttons simultaneously Do not skip this step to avoid paper jam...
  • Page 42 NC3L Verifone 12" - Installation and maintenance To remove the roll containment disk, you must align the notch on the disk to one of the 4 tips on the paper roll stud. Once the notch on the disk and one of the 4 tips on studs are aligned, remove the roll containment disk...
  • Page 43 NC3L Verifone 12" - Installation and maintenance Remove now the empty paper roll Verify paper roll edge has a clean cut with no folds. Cut it again if required.
  • Page 44 NC3L Verifone 12" - Installation and maintenance Check the right roll orientation. Printable paper side is facing down. Insert the paper roll in the printer roll stud Place the roll containment disk in its position on stud...
  • Page 45 NC3L Verifone 12" - Installation and maintenance Verify the printer is powered and insert the edge of paper roll into the printer input slot The printing mechanism will automatically load the paper. If printer doesn’t load paper automatically check again if paper edge has a flat and clean cut and try again.

  • Page 46: Dis P Lay Cle An In G

    NC3L Verifone 12" - Installation and maintenance To verify the paper has been loaded on the right way you can run a test print 1 0 . 5 . D I S P L A Y C L E A N I N G To clean display module, for standard and wash model, use only a soft, clean, and dry cloth for cleaning.

  • Page 47: Bar C Ode Re A De R C Le A Ni N G

    NC3L Verifone 12" - Installation and maintenance 1 0 . 6 . B A R C O D E R E A D E R C L E A N I N G Never use thinner, trichloroethylene, or ketone-based solvents, they can deteriorate plastic parts.

  • Page 48: Cle An In G E X Te R Na L

    NC3L Verifone 12" - Installation and maintenance 1 0 . 8 . C L E A N I N G E X T E R N A L Clean the painted surfaces with warm water and a mild detergent. WARNING: never use a dry rag due to the risk of static electricity formation.
  • Page 49 NC3L Verifone 12" - Installation and maintenance...
  • Page 50 NC3L Verifone 12" - Installation and maintenance © 2022 Gilbarco Italia S.r.l. Via de’ Cattani, 220/G 50145 Firenze, Italy Tel. (+39) 055-30941 • Fax (+39) 055-318603 http://www.gilbarco.it...
