Summary of Contents for Mido R602A
- Page 1 R602A Model： Wireless LoRa Siren LoRa Siren User Manual MiDo Srl FERRARA Via Poledrelli 21 - 44121 (Fe) +39 0532 1640011 LAURIA Via Vico II Cairoli, 4 - 85044 (Pz) +39 0971 1680051 EMAIL info@midomet.com...
-
Page 2: Table Of Contents
Table of Content 1. Introduction ................................2 2. Appearance ................................3 3. Main Features ................................4 4.Set up Instruction ..............................4 4.1 Power on ............................... 4 4.2 Join Into Lora Network ..........................4 4.3 Function Key ..............................4 4.4 Remote Control ............................. 4 5. -
Page 3: Introduction
LoRaWAN open protocol, compatible with the LoRaWAN protocol. The AppServer can be used to control the R602A. The R602A has five kinds of alarm sounds - fire/ emergency / burglar / doorbell /mute mode. The high-brightness alarm flashes and the speaker emits an alarm sound to... -
Page 4: Appearance
2. Appearance Speaker Alarm Indicator Alarm Indicator Status Indicator Network Indicator DC 12V Binding Key Setting Key Battery Cover Battery Holder... -
Page 5: Main Features
Press any function key; the green indicator will flash once and it will send a data report. 4.4 Remote Control Through the App Server, the R602A can be controlled by sound and light alarms, and there are five alarm sounds that can be controlled are as follows:... -
Page 6: Data Report
1. Fire Mode 2. Emergency Mode 3. Burglar 4. Doorbell 5. Mute Mode According to the received command, it can also be determined whether the alarm flash of the device is blinking, and the alarm flash of the device is divided into three types of flashing modes: flowing light, blink and unlighted. - Page 7 Parallel to Warning, (2bytes,Unit:1s) Fixed 0x03_Doorbell, 0x02_ LedBlinkMode2 0x00) 0x04_MuteMode in Parallel to Warning Other Value is Reserved ConfigReport 0x01 MinTime MaxTime Reserved R602A 0x69 (2bytes Unit:s) (2bytes Unit:s) (5Byte,Fixed 0x00) ConfigReport 0x81 Status Reserved (0x00_success) (8Bytes,Fixed 0x00) ReadConfig 0x02 Reserved...
- Page 8 e. Setting MinTime / MaxTime = 300s = 5min * MinTime / MaxTime must equal Downlink: 0169012C012C0000000000 012C (H = 300 (D Response: 8169000000000000000000 （Configuration success） 8169010000000000000000 （Configuration failure） f. Read MinTime / MaxTime Downlink: 0269000000000000000000 Response: 8269012C012C0000000000 （Current configuration） Example#1 based on MinTime = 1 Hour, MaxTime= 1 Hour MaxTime...
-
Page 9: Installation And Precaution
7. Installation and Precaution This product does not have a waterproof function. After the join the network, please place it indoors. 1. Use screws (should be purchased) to fix it on Sound and light alarms can be applied to the following the wall. -
Page 10: Important Maintenance Instruction
All of the above suggestions apply equally to your device and accessories. If any device is not working properly. Please take it to the nearest authorized service facility for repair. MiDo Srl FERRARA Via Poledrelli 21 - 44121 (Fe) +39 0532 1640011...
