Mareli Systems RubynoR AMG 890 Manual

Mareli Systems RubynoR AMG 890 Manual

Fancoil radiator

Advertisement

Quick Links

FANCOIL RADIATOR
AMG 890 / 1090 / 1290

Advertisement

loading
Need help?

Need help?

Do you have a question about the RubynoR AMG 890 and is the answer not in the manual?

Questions and answers

Summary of Contents for Mareli Systems RubynoR AMG 890

  • Page 1 FANCOIL RADIATOR AMG 890 / 1090 / 1290...
  • Page 2 / or heating and must be used only for this purpose and according to their performance. “MARELI SYSTEMS Ltd. ” is not responsible for any damage resulting from improper installation, adjustment, maintenance or improper use.
  • Page 3 Safety rules When using a product that runs on electricity and water, you need to follow some basic safety rules, such as: It is forbidden to make changes in the safety or regulation devices or to make adjustments without permission and instructions from the manufacturer. It is forbidden to use the appliance by children or unsupervised people with disabilities.
  • Page 4 Вентилаторен Конвектор AMG890 AMG1090 AMG1290 FANCOIL RADIATOR 1090 1290...
  • Page 5 e right sided version of the fan-coil e le sided version of the fan-coil...
  • Page 6 e right sided version of the fan-coil 3-way valve option available e le sided version of the fan-coil 3-way valve option available...
  • Page 7: Device Placement

    Failure to comply with these rules may not only lead to a malfunction of the appliance, but will also void the warranty and therefore MARELI SYSTEMS LTD will not be liable for any damage caused to people, animals or property.
  • Page 8 140 mm 2500 mm 400 mm 0 mm Pos 1 Remove the lower grille pos 1 by pulling it at both upper ends.
  • Page 9 Pos.2 Unscrew the screws pos.2 on both sides of the convector. Pos.3 Pos.4 Remove the side covers pos.3 and pos.4 by sliding them upwards.
  • Page 10 Mounting holes Mounting holes Mounting holes Mounting holes Pos.4 Pos.4 If the mounting is on a wall, remove the feet pos.4 and mount the convector to the wall through the speci ed mounting holes. Pipe diameter: G 3/4 Pos.6 COLD Pos.7 Pos.8 Pos.4...
  • Page 11: Mounting The Legs

    Pos.9 Connect the power cables in terminal block Pos. 9 in the appropriate places, denoted by L, N and. Assemble everything in reverse order. MOUNTING THE LEGS...
  • Page 13: Hydraulic Connections

    Hydraulic connections e selection and sizing of hydraulic ducts must be made by a specialist who must work in accord- ance with the required good technical skills and applicable laws, taking into account the fact that smaller pipes cause malfunctions. To make the connections: - lay the hydraulic pipes - Tighten the connections with a wrench and another holding counter...
  • Page 14: Electrical Connections

    Filling the system When starting the system, make sure that the deaerator of the hydraulic unit is open. If there is no mains supply and the solenoid valve has already been supplied, use the special head to press the shut-o device of the valve to open it. Pos.10 Air extraction when lling the system Pos.10 Electrical connections...
  • Page 15 Cleaning Вентилаторен Конвектор AMG890 AMG1090 AMG1290 1090 1290...
  • Page 17: Troubleshooting

    Troubleshooting In the event of water leaks or malfunctions, turn o the power immediately and close the water taps. If one of the following faults occurs, contact an authorized service center or authorized quali ed person, avoiding taking any action. - Ventilation is not activated even if there is hot or cold water in the hydraulic circuit.
  • Page 18 Mounting 1. Place relay unit inside the wall- 2. Install metal bracket box, with the back of relay unit facing outwards. 4. Snap front on metal bracket, 3. Connect front unit to relay unit by cables attached. using the top edge as pivot.
  • Page 19 5. Finally, secure controller by screw...
  • Page 20 MEANING ITEM Time Room Temperature Current Set Point Temperature Unit Current Program Heat / Cool Mode Auto Changeover Output is ON (when appear) (valve on) Fan Low/Med/High/Auto Wi-Fi (appears when connected to internet) Mode Key: Short-Press to change H/C Press-n-hold to access internal setting Clock Key: Press to set clock.
  • Page 21 TA652FC-W Mobile App Interface For smartphones with Android...
  • Page 23 For smartphones with IOS...
  • Page 25 TA652FC-W Mobile App Interface - In Control tap, Room Temperature, Floor - In Programs tap, current program mode will temperature, Current setpoint, next setpoint be displayed. ( No Program / 1Day / 1+5+1 / (next program)will be displayed. 7days). - Press Power key to turn on or o the thermostat. - When No Program is selected, no setting can be adjusted.
  • Page 26 Clock setting **Normally the clock is automatically set once wi is connected and synchronize for each day. So manual set is not necessary when it is online. Press [CLOCK] to start the setting; Press [ ] / [ ] to change the day of week; Press [CLOCK] again to con rm day of week setting and start to adjust hour;...
  • Page 27 Temperature o set: Items Value Default e temperature of internal sensor can be cal- Value ibrated from -5°C - +5°C in case there is tem- User Interface Screen Saver perature di erence between actual value and (P00) thermostat. Screen Saver 0-120 Count down Switching Di erential:...
  • Page 28 Forced Ventilation: Technical Data Disable: Fan will turn on only when heat/cool is on. Enable: Fan keeps on (low) even heat / cool is o . Power supply: 230 ± 10% VAC Water Temp & Fan Control: Fan operation limited by external temperature. Relay Contact Voltage: In Heat mode, fan forced o when water tem- 230VAC max 50/60 Hz...
  • Page 32 MARELI SYSTEMS Ltd. Industrial Zone Simitli, 2730 Region Blagoevgrad Bulgaria info@mareli-systems.com www.mareli-systems.com MARELI SYSTEMS Ltd disclaims any responsibility for possible inaccuracies contained in this manual if they are due to printing or transcription errors. We reserve the right to make any change that appears to be...

This manual is also suitable for:

Rubynor amg 1090Rubynor amg 1290
