Eggtimer Rocketry Quasar User Manual page 2

Eggtimer Quasar Features
WiFi-Enabled, Three-Output data-logging flight computer with integrated GPS tracker and telemetry
Programming, arming, and downloading can all be done with any WiFi/browser-enabled device
No apps required on your device, just a browser
Fits easily in a 29mm body tube, weighs only 30 grams
Altimeter records data up to 60,000'
Fully "mach immune", deployments are inhibited until the rocket is moving slowly near apogee
Detailed flight data for 15 flights is saved, and can be downloaded using your browser
Summary data can be downloaded or viewed on your browser, immediately after the flight
Main deployment channel can be set to fire from 100' to 2000'
Drogue deployment channel delay configurable from nose-over +0 to +30 secs
AUX channel can be configured as a Drogue, Main, or for doing Airstarts
AUX airstart output can be qualified with altitude@time and/or velocity@time
Deployment channels' on-time can be set from 1-9 secs... great for hot-wire non-pyro deployments
Channels can be set for standard servos for deployments, travel from 23-90 degrees CW or CCW
"Fail-Safe" mode can fire main chute if a drogue failure is detected, preventing a potential high-speed
chute deployment or crash
Real-time GPS and altimeter telemetry is streamed during flight for use with the Eggfinder LCD Receiver
Available in license-free and 70 cm Ham versions
Battery input is polarity protected
Works with a 2S/7.4V LiPo battery, 500 mAH or larger capacity recommended
10A current-limited deployment channels protect against "brownouts", shorts, and overcurrent loads
Works with all common deployment ematches
Test mode so you can safely do an actual pyro test up to 100' away from your rocket
Dual-ended deployment outputs, igniters are essentially "dead" until well into the flight
No switch needed, since it's disarmed and the igniters are dead until YOU arm it remotely
