- Page 1 Edge 2 | Single Board Computer Edge 2 Kit | IoT Edge Computer User Manual Get Started with https://www.mixtile.com/docs/...
-
Page 2: Changes
Edge 2 – User Manual MIXTILE Changes Version Date Changes Name 2021-08-23 First version 2021-11-12 Add key component specification 2022-03-14 Add content related to Edge2 Kit 2022-04-24 Update information of M.2 and Mini-PCIe - 2 - V1.3 Copyright © 2022 MIXTILE. -
Page 3: Table Of Contents
Edge 2 – User Manual MIXTILE Index of Contents CHANGES ......................................- 2 - INTRODUCTION ..................................- 5 - ....................................- 5 - RODUCT ESCRIPTION ........................................ - 5 - ACKAGE LIST ......................................- 5 - EATURES & P ..............................- 6 -... - Page 4 Edge 2 – User Manual MIXTILE 2.19 U.2 ......................................... - 22 - 2.20 SATA P .......................................- 24 - OWER SPECIFICATIONS ..................................- 24 - ......................................- 24 - NVIRONMENTAL ......................................- 24 - ECHANICAL SUPPORT ....................................- 25 - ....................................- 25 -...
-
Page 5: Introduction
The single-board computer combines a MIXTILE System-on-Module Core 3568, a WLAN+BT wireless module, and plenty of expansion interfaces. Edge 2 Kit is based on Edge 2, just adds one customizable enclousure and two external Wi-Fi antennas. 1.2 Package list 1x MIXTILE Edge 2 ... -
Page 6: Block Diagram & Product Overview
Edge 2 – User Manual MIXTILE 1.4 Block diagram & Product overview 1.4.1 Block Diagram The Block diagram for the Edge 2 single-board computer is shown below with descriptions for each function. - 6 - V1.3 Copyright © 2022 MIXTILE. -
Page 7: Product Overview
Edge 2 – User Manual MIXTILE 1.4.2 Product Overview - 7 - V1.3 Copyright © 2022 MIXTILE. -
Page 8: Physical Dimensions
Edge 2 – User Manual MIXTILE 1.4.3 Physical Dimensions - 8 - V1.3 Copyright © 2022 MIXTILE. -
Page 9: Key Component Specifications
1.5.2 Wi-Fi 6 / Bluetooth Edge 2 integrates a Wi-Fi and Bluetooth module AP6275S, that can wake up the device from sleep mode. AP6275S supports Wi-Fi 6 and dual-mode Bluetooth 5.0 that could interact with different vendors’ 802.11a/b/g/n/ac/ax 2x2 Access Points with MIMO standard and can accomplish up to a speed of 1200Mbps with the dual stream. -
Page 10: Microsd Socket
PCIe 3.0 signal. PCIe Support The M.2 socket supports a two-lane PCIe 3.0 interface. Edge 2 uses PI6C557-03BLE as a clock generator to provide a 100MHz clock signal for the CPU and M.2 socket. For full functioning of the two-lane PCIe signal, the selecting GPIO, PCIE_USB_SEL_GPIO1_D0 , needs to set LOW to active. -
Page 11: Gigabit Ethernet
The power port uses a USB-C port, which supports USB PD 3.0 . An on-board Power Delivery controller allows the maximum power input of 20V @ 3A. The Edge 2, as device mode, can be communicated by USB-C, which supports USB 2.0 for ADB debugging, firmware update. -
Page 12: Connector
Edge 2 – User Manual MIXTILE MIPI-DSI The MIPI-DSI display supports two channel DSI and 2.5Gbps maximum data rate per lane. It supports up to 1920x1080@60Hz display output for single-MIPI mode and 2560x1440@60Hz for dual-MIPI mode. Two MIPI-DIS interfaces use 30-pin FPC connectors, MIPI-DSI0 and MIPI-DSI1 , which include one channel MIPI-DSI and one touch panel signal (TP). -
Page 13: Connectors & Pin Assignments
Edge 2 – User Manual MIXTILE 2 Connectors & Pin Assignments The following section lists the interfaces connector pin assignments, pin types with corresponding signal descriptions. The interface connectors on Edge 2 are listed in the table below. 2.1 Debug Input/ Signal Description... -
Page 14: Output
Edge 2 – User Manual MIXTILE 2.4 I2C Input/ Signal Description Name Type Output 3.3V Output 3.3V @ 100mA Max I2C3_SCL Output I2C clock signal I2C3_SDA I2C data signal Ground 2.5 5V Output Input/ Signal Description Name Type Output Output... -
Page 15: Adc
Edge 2 – User Manual MIXTILE 2.9 RS485 Input/ Signal Description Name Type Output Ground 485B RS485 differential signal Negative 485A RS485 differential signal Positive 2.10 ADC Input/ Signal Description Name Type Output 3.3V Output 3.3V @ 100mA Max SARADC_VIN4... -
Page 16: Mipi-Dsi0
Edge 2 – User Manual MIXTILE 2.13 MIPI-DSI0 Input/ Signal Description Name Type Output Ground MIPI_DSI_TX0_D0N LVDS Output MIPI-DSI0 data signal Negative MIPI_DSI_TX0_D0P LVDS Output MIPI-DSI0 data signal Positive Ground MIPI_DSI_TX0_D1N LVDS Output MIPI-DSI0 data signal Negative MIPI_DSI_TX0_D1P LVDS Output... -
Page 17: Edp
Edge 2 – User Manual MIXTILE MIPI_DSI_TX1_D0P LVDS Output MIPI-DSI1 data signal Positive Ground MIPI_DSI_TX1_D1N LVDS Output MIPI-DSI1 data signal Negative MIPI_DSI_TX1_D1P LVDS Output MIPI-DSI1 data signal Positive Ground MIPI_DSI_TX1_CLKN LVDS Output MIPI-DSI1 clock signal Negative MIPI_DSI_TX1_CLKP LVDS Output MIPI-DSI1 clock signal Positive... -
Page 18: Camera
Edge 2 – User Manual MIXTILE EDP_TX_D2N LVDS Output EDP data signal Negative EDP_TX_D2P LVDS Output EDP data signal Positive Ground EDP_TX_D3N LVDS Output EDP data signal Negative EDP_TX_D3P LVDS Output EDP data signal Positive 3.3V Output 3.3V @ 500mA Max in total 3.3V... - Page 19 Edge 2 – User Manual MIXTILE Not connected pin CAMERA0_RST_L_GPIO4_B5 Output GPIO output for camera reset CAMERA0_PDN_L_GPIO4_B4 Output GPIO output for camera disable CAMERA0_PWREN_GPIO1_D4 Output GPIO output for camera enable I2C4_SCL_M0 Output I2C clock signal I2C4_SDA_M0 Input I2C data signal...
- Page 20 Edge 2 – User Manual MIXTILE Not connected pin Not connected pin Ground Not connected pin PCIE30_TX1_N/HUB_USB3_SSTXN LVDS Output PCIE3.0/USB3.0 data signal Negative M2_UIM_RESET Input Reset signal to SIM socket PCIE30_TX1_P/HUB_USB3_SSTXP LVDS Output PCIE3.0/USB3.0 data signal Positive M2_UIM_CLK Input Clock signal to SIM socket...
- Page 21 Edge 2 – User Manual MIXTILE CLK32K_OUT0 Output Clock output 32.768K to module Not connected pin 3.3V Output 3.3V @ 3A Max in total Ground 3.3V Output 3.3V @ 3A Max in total Ground 3.3V Output 3.3V @ 3A Max in total Not connected pin 2.18 Mini-PCIe...
- Page 22 Edge 2 – User Manual MIXTILE Not connected pin Not connected pin Not connected pin Ground Ground USB2_HOST2_DM LVDS USB2.0 data signal Negative Not connected pin USB2_HOST2_DP LVDS USB2.0 data signal Positive 3.3V Output 3.3V @ 3A Max in total Ground 3.3V...
- Page 23 Edge 2 – User Manual MIXTILE Ground Ground Ground Output 5V @ 3A Max Output 5V @ 3A Max Output 5V @ 3A Max Ground Not connected pin Ground Not connected pin Not connected pin Not connected pin SATA0_LED Output...
- Page 24 Storage Temperature 0 ° to +70 °C 3.2 Mechanical Parameter Specifications PCBA dimensions, Length x Width 140mm x 100mm Edge 2 dimensions, Length x Width x Height 148mm x 105mm x 32mm - 24 - V1.3 Copyright © 2022 MIXTILE.
- Page 25 Edge 2 – User Manual MIXTILE Weight, Device (Board) 665g (113g) 4 Support 4.1 Technical Support MIXTILE technical support team assists you with the questions you may have. Contact us with the following methods below. Email: support@mixtile.com Website: https://www.mixtile.com - 25 - V1.3...
