LOW ENERGY APPLICATION NOTE PORTALP USA, Inc. recommends that all of its automated When using the SW10/19 for a low energy application, PORTALP pedestrian door products be installed by a trained automatic recommends the use of a door-mounted presence sensor on the...
REMARQUE SUR L’APPLICATION À ÉNERGIE FAIBLE PORTALP USA, Inc (ci-après dénommée “PORTALP”) préconise Lors de l’utilisation du SW10 / 19 en présence d’application à que tous ses produits relatifs aux portes piétonnes automatiques énergie faible, PORTALP préconise l’utilisation d’un avertisseur soient installés par un technicien de portes automatiques...
SW10 (Full Power) & SW19 (Low Energy) INSTALLATION GUIDE PRODUCT DESCRIPTION & SPECIFICATIONS Automatic Doors & Building Access Control Power Supply* 115 VAC (+6%, -10%) 60Hz with ground Power Consumption 100W Current Consumption Motor 24 VDC Permanent Magnet with Belt Driven Encoder Header Dimensions 1/2”...
SW10 (Full Power) & SW19 (Low Energy) INSTALLATION GUIDE HEADER INSTALLATION Automatic Doors & Building Access Control Mount the pre-drilled back-plate to the top door frame using appropriate fasteners for the type of frame. (Refer to Door Prep drawings on pgs.
Page 8
SW10 (Full Power) & SW19 (Low Energy) INSTALLATION GUIDE HEADER INSTALLATION Automatic Doors & Building Access Control PUSH SIDE INSTALLATION SINGLE | § DOOR PREP DRAWINGS Opening Width Operator Width X Dim 36" 39" 6.25" 42" 45" 12.25" 44" 47"...
Page 9
SW10 (Full Power) & SW19 (Low Energy) INSTALLATION GUIDE HEADER INSTALLATION Automatic Doors & Building Access Control PUSH SIDE INSTALLATION DOUBLE | § DOOR PREP DRAWINGS Opening Width Operator Width A Dim C Dim 72" 75" 12-7/16" 84" 87" 10-7/8"...
Page 10
SW10 (Full Power) & SW19 (Low Energy) INSTALLATION GUIDE HEADER INSTALLATION Automatic Doors & Building Access Control PULL SIDE INSTALLATION SINGLE | § DOOR PREP DRAWINGS Opening Width Operator Width Y Dim 36" 39" 6.25" 42" 45" 12.25" 44" 47"...
Page 11
SW10 (Full Power) & SW19 (Low Energy) INSTALLATION GUIDE HEADER INSTALLATION Automatic Doors & Building Access Control PULL SIDE INSTALLATION DOUBLE | § DOOR PREP DRAWINGS Opening Width Operator Width A Dim C Dim 72" 75" 12-7/16" 84" 87" 10-7/8"...
Page 12
SW10 (Full Power) & SW19 (Low Energy) INSTALLATION GUIDE HEADER INSTALLATION Automatic Doors & Building Access Control DOUBLE EGRESS INSTALLATION | § DOOR PREP DRAWINGS Opening Width Operator Width A Dim C Dim 72" 75" 12-7/16" 84" 87" 10-7/8" 88"...
Page 13
SW10 (Full Power) & SW19 (Low Energy) INSTALLATION GUIDE HEADER INSTALLATION Automatic Doors & Building Access Control 4.875” 4.875” DOUBLE EGRESS PULL ARM DOUBLE EGRESS PUSH ARM WWW.PORTALP.COM...
SW10 (Full Power) & SW19 (Low Energy) INSTALLATION GUIDE MOUNT THE OPERATOR(S) Automatic Doors & Building Access Control § Operator is non-handed – same operator for all hands of doors Handing is determined by how the operator is mounted inside the header §...
Page 15
SW10 (Full Power) & SW19 (Low Energy) INSTALLATION GUIDE MOUNT THE OPERATOR(S) Automatic Doors & Building Access Control For pull application the motor should be located near the hinge side of the door. For push application the I/O board should be located near the hinge side of the door.
Page 16
SW10 (Full Power) & SW19 (Low Energy) INSTALLATION GUIDE MOUNT THE OPERATOR(S) Automatic Doors & Building Access Control I/O BOARD MOTOR PUSH = I/O BOARD IS TOWARDS THE HINGE JAMB OPERATOR OPERATOR LH PUSH RH PUSH WWW.PORTALP.COM...
Page 17
SW10 (Full Power) & SW19 (Low Energy) INSTALLATION GUIDE MOUNT THE OPERATOR(S) Automatic Doors & Building Access Control PULL = ROUND MOTOR IS TOWARDS THE HINGE OPERATOR OPERATOR LH PUSH RH PUSH § Mount the header to the doorframe with the screws provided.
SW10 (Full Power) & SW19 (Low Energy) INSTALLATION GUIDE PUSH ARM INSTALLATION Automatic Doors & Building Access Control All push arms come standard with 35mm spindle. 50mm and 80mm available as an accessory. (BOX CONTENT - Page 33 - 35)
Page 19
SW10 (Full Power) & SW19 (Low Energy) INSTALLATION GUIDE PUSH ARM INSTALLATION Automatic Doors & Building Access Control Adjust the secondary telescopic arm to the prescribed length according to chart: Reveal Hinge Hung X Dim. Center Pivot X Dim. 0"...
Page 20
SW10 (Full Power) & SW19 (Low Energy) INSTALLATION GUIDE PUSH ARM INSTALLATION Automatic Doors & Building Access Control Rotate the primary arm in the opening direction as to reach the pivot point of the secondary. Attach the arms together with the hardware provided.
SW10 (Full Power) & SW19 (Low Energy) INSTALLATION GUIDE PULL ARM INSTALLATION Automatic Doors & Building Access Control Standard Pull Arm Offset (double egress) Pull Arm For 0-degree reveal For reveal greater than 0 degrees Use 20mm spindle Use 20mm Spindle...
WARNING: Ensure all incoming electrical power is shut off électrique entrante est coupée avant de procéder au before proceeding with any wiring to SW10/19. Use only câblage du SW10/19. À utiliser uniquement avec le faisceau with wire harness provided; failure to do so may result in de câbles fourni;...
SW10 (Full Power) & SW19 (Low Energy) INSTALLATION GUIDE POWER ON & INDICATIONS Automatic Doors & Building Access Control DL1 : GREEN USB CONNECTION DL2: FLASHING DL3: BLUE 5V POWER SUPPLY DL4: BOARD VALUES DIFFER FROM DIP SWITCHES (PRESS SW1 MOMENTARILY TO EXTINGUISH YELLOW LED) Upon applying power, observe the above LED’s.
SW10 (Full Power) & SW19 (Low Energy) INSTALLATION GUIDE SET-UP PROCEDURES Automatic Doors & Building Access Control Perform a setup at the control as follows: Ensure main power is on § At the I/O control board, depress the SW1 button for approximately 5 seconds. When the red LED (LD2) at the Adjustment Board §...
SW10 (Full Power) & SW19 (Low Energy) INSTALLATION GUIDE SET THE DIP SWITCHES ON THE I/O BOARD Automatic Doors & Building Access Control Set the dip switches according to the application. § Dip switches are used to apply specific functions to the control.
SW10 (Full Power) & SW19 (Low Energy) INSTALLATION GUIDE SET THE DIP SWITCHES ON THE ADJUSTMENT BOARD Automatic Doors & Building Access Control Set the dip switches according to the application. § WWW.PORTALP.COM...
Page 27
Assisted Manual Enabled assisted closing following a manual Disabled assisted closing following a manual opening Closing*** opening FACTORY USE ONLY PORTALP USA, Inc. recommends the use of a door-mounted secondary activation device when dip switch 9 is ON - Enabled. WWW.PORTALP.COM...
SW10 (Full Power) & SW19 (Low Energy) INSTALLATION GUIDE WIRING CONNECTIONS (wiring diagrams are located in the Appendix) Automatic Doors & Building Access Control I/O BOARD CONNECTIONS POSITION FUNCTION DESCRIPTION Electric Lock Relay Common. Electric Lock Relay N.O. Dry contact – Contact closes upon activation. May be used for fail-secure locks by routing 1 leg of power through the relay.
SW10 (Full Power) & SW19 (Low Energy) INSTALLATION GUIDE ADJUSTING THE MECHANICAL DOORSTOP Automatic Doors & Building Access Control CAUTION – DO NOT REMOVE THE STOPS § IMPORTANT - This step may be optional depending on your application § The mechanical stops are located on the top or bottom of the operator, depending on the hand of the door.
SW10 (Full Power) & SW19 (Low Energy) INSTALLATION GUIDE TROUBLESHOOTING Automatic Doors & Building Access Control Door will not open § Check On-Off switch for proper position. § Check LED status for LD 5, 6, and 7. If any of these LED’s are OFF, the door will not open.
SW10 (Full Power) & SW19 (Low Energy) INSTALLATION GUIDE JOB DOCUMENTATION & CLOSEOUT Automatic Doors & Building Access Control Upon completion of the installation, provide the following to the Owner or their assigned agent: § Completed & signed work ticket. Be certain to record any serial numbers for items that were replaced.
Page 44
TUCKER SW10 (Full Power) & SW19 (Low Energy) INSTALLATION GUIDE APPENDIX - BOX CONTENT Automatic Doors & Building Access Control PULL ARM (DB - Dark Bronze) QTY: 1 PLASTIC BAG CONTENT Door Arm Channel Endcap QTY: 1 Plastic Bag QTY: 1...
Page 45
TUCKER SW10 (Full Power) & SW19 (Low Energy) INSTALLATION GUIDE APPENDIX - BOX CONTENT Automatic Doors & Building Access Control PULL ARM (DB - Dark Bronze) QTY: 1 PLASTIC BAG CONTENT Door Arm Channel Endcap QTY: 1 Plastic Bag QTY: 1...
Page 46
TUCKER SW10 (Full Power) & SW19 (Low Energy) INSTALLATION GUIDE APPENDIX - WIRING DIAGRAMS Automatic Doors & Building Access Control LOW ENERGY APPLICATION: PUSH PLATES WITH APPROACH SIDE DOOR-MOUNTED SENSOR Non-Swing Side (approach) door-mounted sensor is wired into the secondary activation input (13) §...
Page 47
N.C. switching circuit will be connected to Door #1, and a sync line will be connected to Door #2. For simultaneous pairs, PORTALP provides a dual harness for the On-Off-Hold switch. Each plug-in connector for the control is wired §...
Page 48
TUCKER SW10 (Full Power) & SW19 (Low Energy) INSTALLATION GUIDE APPENDIX - ELECTRIC LOCK APPLICATION Automatic Doors & Building Access Control WWW.PORTALP.COM...
Page 49
TUCKER SW10 (Full Power) & SW19 (Low Energy) INSTALLATION GUIDE APPENDIX SW10 PAIR WITH THE BAT + TORPEDO + BEA BODUGUARD Automatic Doors & Building Access Control WWW.PORTALP.COM...
Page 50
TUCKER SW10 (Full Power) & SW19 (Low Energy) INSTALLATION GUIDE APPENDIX SW10 SINGLE/PAIR WITH THE BAT + BEA LZR MICROSCAN Automatic Doors & Building Access Control WWW.PORTALP.COM...
Page 51
TUCKER SW10 (Full Power) & SW19 (Low Energy) INSTALLATION GUIDE APPENDIX SW10 SINGLE WITH THE BAT + BEA BODUGUARD Automatic Doors & Building Access Control WWW.PORTALP.COM...
Page 52
Astragal is installed, a mechanical door coordinator may be required to ensure a proper coordinated closing during a power loss. Only fire rated hardware shall be used on a fire rated door & frame assembly. Ensure the Tucker SW10/19 that is being installed has the proper fire rated label applied to the header. WWW.PORTALP.COM...
Page 53
- TAP PROGRAMMING DEVICE - KP evo Automatic Doors & Building Access Control Please note, some functions of the SW10/19 controller require the use of a hand-held “TAP” programming device. The following functions require use of this device for programming: ü...
