ADS-A02U

For household use

Electric Coffee Maker

Instruction Manual

Thank you for purchasing this product. Please read all information in this manual before using the

appliance.

Afterward, keep this manual in a handy location for future reference by anyone who will use this product.

Table of Contents

Need help?

Do you have a question about the ADS-A02U and is the answer not in the manual?

Questions and answers

Summary of Contents for Tiger ADS-A02U

Page 1 ADS-A02U For household use Electric Coffee Maker Instruction Manual Thank you for purchasing this product. Please read all information in this manual before using the appliance. Afterward, keep this manual in a handy location for future reference by anyone who will use this product.
Page 2 IMPORTANT SAFEGUARDS When using the appliance, basic safety precautions should always be followed including the following: 1. Read all instructions. 2. Do not touch hot surfaces. Use handles or knobs. 3. To protect against ﬁre, electric shock and injury to persons do not immerse cord, plugs, or appliance in water or other liquid.
Page 3: Table Of Contents
Introduction Table of Contents ▌Introduction ▌When You Have a Problem 4 - Important Safeguards 20 - Troubleshooting 9 - Names of Component Parts 21 - Error displays and actions to be taken and Accessories 10 - Attaching and Removing Parts ▌Others 22 - Specifications ▌How to Use...
Page 4: Important Safeguards
Important Safeguards Read the following instructions carefully before use and be sure to observe them. The precautions described below are intended to protect the user and other individuals from physical harm and to safeguard against damage to property. Be sure to follow these instructions since they are important safeguards.
Page 5 Warning In case of trouble In case of trouble, immediately unplug the plug and contact TIGER CORPORATION U.S.A. to request repair. Continued use may result in electrical shock or injury. Failure to observe this precaution may result in a fire.
Page 6 Important Safeguards Safety instructions to follow so that the appliance can be used for many years Clean the parts listed under “Parts to If mineral water or alkali ion water is wash after every use → P. 16” after used, clean the appliance even more every use.
Page 7 In the case of breakage, immediately disconnect the power plug from the outlet and contact TIGER CORPORATION U.S.A. for inspection and repair. Caution • Disconnect the plug before cleaning and leave unplugged when not in use.
Page 8 Precautions on each part █ Lid/Upper cylinder/Joint Caution Upper cylinder Joint Do not start coffee extraction with Safety instructions to follow so that the no water in the upper cylinder. appliance can be used for many years Doing so may result in fire or a malfunction. Do not use this product with less Do not remove the upper cylinder water than the minimum amount (the...
Page 9: Names Of Component Parts And Accessories
Introduction Names of Component Parts and Accessories Check each part first after unpacking the product. Cylinder unit Upper cylinder (with water level scale) Upper cylinder gasket Add water up to the scale line for the number of cups of coffee that you want to make. Two cup scale line One cup scale line Lock bar...
Page 10: Attaching And Removing Parts
Attaching and Removing Parts Removing the cylinder unit ‘ Installing the cylinder unit → P. 14 Turn the lock bar in the Remove the cylinder unit. direction of the arrow. Upper cylinder Cylinder unit Joint Lower cylinder Lock bar Attaching and removing the lower cylinder Attaching and removing the water pumping pipe <Removing>...
Page 11: When Using The Appliance For The First Time Or After A Long Time Without Use
Introduction / How to Use When Using the Appliance for the First Time or after a Long Time without Use Wash all parts other than the main unit. → P. 16 Upper cylinder gasket Joint Joint gasket Filter Tray cover Tray Measuring spoon Water pumping pipe gasket...
Page 12: Making Coffee
Making Coffee Remove the cylinder unit from the main unit. Cylinder unit ‘ Removing the cylinder unit → P. 10 Remove the upper cylinder and lower cylinder Upper from the joint. cylinder (1) Turn ‘ Be sure to hold the joint when turning the cylinders. (2) Remove Joint Lower...
Page 13 How to Use Attach the lower cylinder to the joint. Joint Attach ‘ Attaching the lower cylinder → P. 10 Turn Caution y Check that the joint gasket is attached. If it is not, there is the risk of burns. Add water to the upper cylinder.
Page 14 Making Coffee Install the cylinder unit onto the main unit. Cylinder unit Caution y When installing, be careful not to turn the upper cylinder. If the upper cylinder is turned, the lock bar will not turn in step ❾. Turn the lock bar in the direction of the arrow to lock the cylinder in place.
Page 15 How to Use Recommended menu setting z [Dual Temp] key The Dual Temp Brewing Method begins by brewing at high temperature and then changes to low-temperature brewing midway through the process. This method of brewing reduces undesired flavors and allows you to enjoy the true flavor of the beans. <Temperature of the coffee after extraction>...
Page 16: How To Clean
How to Clean ‘ After use, wash out the path inside the main unit with hot water. → P. 18 ‘ Disconnect the plug, and wait until this appliance has cooled down before cleaning. Items and detergent to be prepared Soft sponge Soft cloth or soft brush Mild detergent for household use...
Page 17 Odors on the upper cylinder gasket, joint gasket, or water pumping pipe gasket can be reduced by leaving the gasket in boiling water for approximately 30 minutes. If the odor is still a concern, please contact Tiger directly. How to attach the gaskets ‘...
Page 18: How To Clean The Path Inside The Main Unit
How to Clean the Path Inside the Main Unit Situation Cleaning method yWhen using the appliance for the first time Rinsing the path inside the main unit → or after a long time without use with hot water yAfter extracting coffee yWhen hot water does not flow through to the lower cylinder ㆓...
Page 19 How to Clean ㆓ Removing mineral components from the path inside the main unit (cleaning with citric acid; continued) When the cleaning with <Rinsing process> citric acid is complete, Recommended time: 2 min 30 sec all flavor and strength Press the [Start|Stop] Light in order from the left Two short selection keys light,...
Page 20: Troubleshooting
Troubleshooting Check the following before requesting repairs. Page to Symptom Point to check Action to take check yNothing happens Is the plug connected to an Connect the plug to an outlet. → → → outlet? when a key is pressed. Has the lock bar been turned to Turn the lock bar to the position →...
Page 21: Error Displays And Actions To Be Taken
→ → → — mineral components. If the problem persists even after multiple cleaning operations, contact TIGER CORPORATION U.S.A. to request repair. yThe flavor selection The temperature sensor Contact TIGER has malfunctioned. CORPORATION keys blink U.S.A.
Page 22: Specifications
‘ Gaskets, lid, upper cylinder, lower cylinder, water pumping pipe, and filter are consumable parts. If they smell bad or are heavily dirty or damaged, please contact Tiger directly. ‘ Parts that come into contact with heat or steam may become worn out in use. Please contact Tiger directly.
Page 23 Others memo MEMO ………………………………………………………………………………………………………………………… ………………………………………………………………………………………………………………………… ………………………………………………………………………………………………………………………… ………………………………………………………………………………………………………………………… ………………………………………………………………………………………………………………………… ………………………………………………………………………………………………………………………… ………………………………………………………………………………………………………………………… ………………………………………………………………………………………………………………………… ………………………………………………………………………………………………………………………… ………………………………………………………………………………………………………………………… ………………………………………………………………………………………………………………………… ………………………………………………………………………………………………………………………… ………………………………………………………………………………………………………………………… ………………………………………………………………………………………………………………………… ………………………………………………………………………………………………………………………… ………………………………………………………………………………………………………………………… ………………………………………………………………………………………………………………………… ………………………………………………………………………………………………………………………… ………………………………………………………………………………………………………………………… ………………………………………………………………………………………………………………………… ………………………………………………………………………………………………………………………… ………………………………………………………………………………………………………………………… …………………………………………………………………………………………………………………………...
Page 24 Email: support@japantigercorp.com URL: https://tiger-corporation-us.com/ For customers outside the continental U.S., please contact the nearest Tiger Customer Service in your area, or the dealer where the original purchase was made. TIGER CORPORATION Head Office: 3-1 Hayami-cho, Kadoma City, Osaka 571-8571, Japan...
