Summary of Contents for ALI Beverage-Air WTFR48AHC
- Page 1 INSTALLATION AND OPERATING INSTRUCTIONS for all WTF Worktop Freezer Models 809-171A 07/20/2022 SEE BACK COVER FOR 3779 CHAMPION BLVD, WINSTON-SALEM, NC 27105 WARRANTY REGISTRATION Phone: (888) 845-9800 | Fax: (800) 253-5168 | Web: beverage-air.com...
-
Page 2: Table Of Contents
User Manual for WTF Freezers Beverage-Air WELCOME Thank you for purchasing a Beverage-Air cabinet. This Please read the following installation and maintenance series has passed our strict quality control inspection and instructions before installing or using your unit. If you meets the high standards set by Beverage-Air! You have have any questions, Please call our Technical Service made a quality investment that with proper maintenance... -
Page 3: Safety
User Manual for WTF Freezers Beverage-Air SAFETY This appliance has been designed with your safety in mind. It has many features to keep you from being harmed. However, safe operation and maintenance are your responsibilities. This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety. - Page 4 User Manual for WTF Freezers Beverage-Air SAFETY Note: The top panel of this unit can be damaged by standing on it. Damage like that is NOT covered by warranty. WARNING Risk of Personal Injury From Falling Stay OFF top of unit Beverage-Air Rev.
-
Page 5: Important Information
User Manual for WTF Freezers Beverage-Air IMPORTANT INFORMATION This unit is intended to be used in a commercial application. That includes schools and cafeterias. If installed in a residence some commercial service companies may not be able to service it on site. The manufacturer has designed and produced this machine with the finest in materials. -
Page 6: Product Information
User Manual for WTF Freezers Beverage-Air PRODUCT INFORMATION Door or Cabinet Dimensions Full Load Power Cord Refrigerant Type / Model Door Type Drawer w x d x h (Inches) Amps Plug (NEMA) Charge (g) / (oz) Count STANDARD DEPTH UNIT WITH DOORS WTF24AHC 24 x 32 x 39 5/8 5-15P... -
Page 7: Clearance And Placement
User Manual for WTF Freezers Beverage-Air CLEARANCE AND PLACEMENT 0" 3 13/16" 2" LEFT/RIGHT SIDE BOTTOM REAR MINIMUM MINIMUM MINIMUM CLEARANCE CLAERANCE CLEARANCE Placement Consider the following when selecting a location for your freezer: Clearance: • 0 in. at the top •... -
Page 8: Unpacking And Set Up
User Manual for WTF Freezers Beverage-Air UNPACKING AND SET UP Carefully inspect the shipping carton for damage. This is the only time that shipping damage may be claimed. If damage is suspected, open the carton immediately and, if there is damage, retain the carton and contact the shipper to make a claim. Do NOT contact the manufacturer. -
Page 9: Shelf Installation
User Manual for WTF Freezers Beverage-Air SHELF INSTALLATION 1. Determine the proper location for the shelf clips. 6. Place shelves so that the retaining tab on the clip The reference numbers on the pilaster can serve as a captures the shelf as shown. guide to ensure all clips are properly located. -
Page 10: Electrical
User Manual for WTF Freezers Beverage-Air ELECTRICAL This is a cord-connected unit, and must be connected to its own dedicated power supply. Check the dataplate on the machine to confirm the voltage and per the dataplate use the correct fuses or HACR circuit breakers. Note: Do not connect to GFI / GFCI outlets. -
Page 11: Using The Unit
User Manual for WTF Freezers Beverage-Air USING THE UNIT Operation is simple, just keep it connected to the correct The freezer will automatically defrost as needed, there is power supply and the freezer will maintain the internal no set time for defrost. Push and immediately release the temperature it has been set to. -
Page 12: Sequence Of Operations Freezer
User Manual for WTF Freezers Beverage-Air SEQUENCE OF OPERATIONS FREEZER The freezer operates based on the air temperature measured by the probe located at the return air. CONTROLLER CONTROLLER COMPONENT OPERATION OPERATION ACTION ACTION Compressor turns Compressor turns The Compressor Contact The Compressor Contact on when the air off when the air... - Page 13 User Manual for WTF Freezers Beverage-Air Keyboard Functions DEFROST (ESC) DOWN SET (ENTER) Quick press and release Quick press and release Quick press and release Quick press and release • Activates manual defrost • Increases Set Point • Decreases Set Point •...
- Page 14 01 2 3 ÿ 56 7 8 6 9 ÿ 3 ÿ ÿ 9 ÿ 5 9 ÿ 9 2 3 ÿ 2 2 3 6 2 3 User Manual for WTF Freezers Beverage-Air ! "...
- Page 15 01 2 3 ÿ 56 786 9 ÿ 3 ÿ ÿ 2 2 3 6 2 3 User Manual for WTF Freezers Beverage-Air () * + , ÿ . / ÿ 0 1 0 2 3ÿ 4 5 6 1 7 8 9 : ; ÿ < 9 34 8 ÿ 0 2 4 ÿ 9 ; ÿ = 2 : > 2 4 8 8 ÿ ? @A @ÿ / : 1 C 4 2 ÿ : / ÿ < D 4 ÿ = 0 2 0 34 < 4 2 ÿ < 0 E 1 4 F G ÿ < D 4 ÿ 0 1 0 2 3ÿ 9 8 ÿ ; : < ÿ 8 9 > ; 0 1 4 C H ÿ...
-
Page 16: Cleaning And Maintenance
User Manual for WTF Freezers Beverage-Air CLEANING AND MAINTENANCE Cleaning Schedule: Cabinet Condenser coil Gaskets Routine maintenance Daily wipe down Quarterly cleaning Daily inspection, check Annually that hinges are tight to Weekly interior the cabinet. Daily Exterior Cleaning It is much easier to clean on a regular basis than to have to remove stains once they have built up. 1. -
Page 17: Drawer Cleaning And Maintenance
User Manual for WTF Freezers Beverage-Air DRAWER CLEANING AND MAINTENANCE Drawer models are shipped with the drawers already installed in the cabinets. Drawers are designed with slides which have locking mechanisms to prevent drawers from coming off cabinets during normal opening and closing operations. See illustration below: Drawers and slides can be removed from a cabinet for cleaning purposes. -
Page 18: Condenser Cleaning
User Manual for WTF Freezers Beverage-Air CONDENSER CLEANING Keeping the condenser coil clean is critical to efficient 6. To reinstall the rear panel line up the bottom of the operation. panel to the bottom of the unit keeping the screw holes lined up on the panel and on the unit. -
Page 19: Methods For Cleaning Stainless Steel
User Manual for WTF Freezers Beverage-Air METHODS FOR CLEANING STAINLESS STEEL Cleaning Needed Cleaning Agent Method of Application Affect on Finish Satisfactory for use on all Areal 20, Lac-O-Nu, Lumin Wash Rub with cloth as directed finishes. Smears and fingerprints O’Cedar Cream Polish, Stainless on the package. -
Page 20: Help
User Manual for WTF Freezers Beverage-Air HELP Trouble Diagnosis for the User Malfunction Possible Cause Likely Solution Connect to proper voltage circuit Replace Unit not plugged in. fuse or reset breaker. No cooling - unit is silent Fuse or circuit breaker tripped. Check outlet for loose connection, replace Power cord plug loose in outlet. -
Page 21: For The Service Tech - R290
User Manual for WTF Freezers Beverage-Air FOR THE SERVICE TECH - R290 Refrigeration service should only be attempted by a trained trade professional certified to work on R290 systems. Here are some critical service items. Other Information: This list does not qualify anyone to service the unit. It is a Evacuation: It is critical that a refrigeration system be reminder and checklist for the service tech. -
Page 22: For The Service Tech - Wiring Diagram
User Manual for WTF Freezers Beverage-Air FOR THE SERVICE TECH - WIRING DIAGRAM CNTRL *SEE CONTROLLER DETAIL COMPRESSOR DETAIL CONDENSER FAN START RELAY S.C. COMP R.C. *SEE CONTROLLER DETAIL FACE HEATER DOOR HEATER GLASS DOOR MODELS ONLY *SEE CONTROLLER DETAIL EVAP FAN *SEE CONTROLLER DETAIL DEFROST HEATER... -
Page 23: Limited Warranty
User Manual for WTF Freezers Beverage-Air LIMITED WARRANTY WARRANTY (Warranty valid in USA and Canada) BEVERAGE-AIR THREE (3) YEAR PARTS AND LABOR WARRANTY: Also, this extended compressor-part only warranty does NOT apply to any electrical controls, condenser, evaporator, Beverage-Air Corporation warrants to the original fan motors, overload switch, starting relay, capacitors, purchaser of Beverage-Air branded equipment, including temperature control, filter/drier, accumulator, refrigeration... -
Page 24: Limited Warranty (Continued)
User Manual for WTF Freezers Beverage-Air LIMITED WARRANTY (CONTINUED) With the exception of Blast Chillers product is designed for LIMITATION OF LIABILITY: maintaining temperature and not bringing food to a desired Beverage-Air Corporation or their affiliates shall not be temperature therefore cannot be held responsible for this liable for any indirect, incidental, special or consequential function under warranty. - Page 25 User Manual for WTF Freezers Beverage-Air Warranty Registration Register your product online at beverage-air.com/parts-service or fill out and mail the form below. Cabinet Model Number: _____________________________________________ Date Of Installation: _________________ Cabinet Serial Number: _____________________________________________ Location Of Product Business Name: ____________________________________________________ Business Street: ____________________________________________________ Business City: ____________________________________ State: _________ Postal Code:___________ Mail to: Beverage-Air, 3779 Champion Blvd, Winston-Salem, NC 27105...
