SMARTX EYEWEAR TITAN EYEX User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

User Guide
User Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TITAN EYEX and is the answer not in the manual?

Questions and answers

ZISHAN AKHTAR
June 6, 2025

How to connect my titan eye x after factory reset with my mobile

0

Subscribe to Our Youtube Channel

Summary of Contents for SMARTX EYEWEAR TITAN EYEX

  • Page 1 User Guide User Guide...

  • Page 2: Table Of Contents

    Table Of Contents Getting Started Warning Charging Touch Input Power on the Device Install the Phone App Connect Your Glasses to Your Phone Configure Your Glasses Using the Phone App Device Usage Checking Battery Level and Connection Status Functions Supported by Default Without the App Incoming Calls Music Play Voice Assistant (OK Google or Siri)
  • Page 3 Table Of Contents Device Reset Pairing Your Phone or Switching Phones Peer to Master Connection Eyecare Menu Touch Operation Summary Specifications Warranty & Support Regulatory & Notices Note: This manual covers the new swipe-touch-based functions and manual connection, starting with software version 2.1.0. Please refer to the old manual for functions using the old touch and auto wake-up connections before this version.

  • Page 4: Getting Started

    Getting Started Warning The device plastics are fully sealed for waterproofing. Any attempt to tamper will void the warranty. Touch Area Right Temple Right is Master Front Rim Speaker Directional Audio Touch End Touch Area Left Touch Start Left Temple is Peer Charging Charge the unit before first-time use.

  • Page 5: Touch Input

    Getting Started The right temple is the master device that connects to the phone and has a built-in mic. The left temple is the peer device that connects to the master and gets audio from the master. Touch Input: The touch start and end areas are shown below. With each swipe of the touch area, you will hear the haptic sound of clicking (in some modes, you will hear a ding sound instead of clicking).
  • Page 6 Getting Started Power Off Positions Glasses placed upside down The glasses will power off in these two upside-down positions after 10 seconds. To turn it back on, pick up the glasses and touch the touch area on both temples. Please note that the above description is for the default off state of the “Auto power on (Beta)”...
  • Page 7 Make sure that your phone’s Bluetooth® is turned on.  Go to the phone’s Bluetooth menu and pair with Titan EyeX-XXXX  from the available device list. If you see two devices with the same EyeX names, please connect to the device with the headset icon.

  • Page 8: Install The Phone App

    If the frames are kept upside down, the frames will power off and not work. Install the Phone App The Titan EyeX phone companion app enables additional  functions such as Fitness Tracking, Notification Reading, Finding Glasses, Reading Time and Weather, etc.

  • Page 9: Configure Your Glasses Using The Phone App

    This will allow the app to fetch notifications from the phone (if the back button does not go to the app, restart the Titan EyeX app). You have now completed your glasses setup. The rest of this ...

  • Page 10: Device Usage

    Device Usage Checking Battery Level and Connection Status Swipe forward and backward within one second on either temple. An audio message will play the level of the battery and connection status. Yellow LED will blink 1-4 times, indicating the battery level of the glasses.

  • Page 11: Music Play

    Device Usage Note: While in a call swipe forward on the right temple Music Play To start music: Swipe backward twice (within 1 second) on the  right temple. To stop (toggle) music: Swipe backward twice (within 1 second)  on the right temple.

  • Page 12: Voice Assistant (Ok Google Or Siri)

    Device Usage Voice Assistant (OK Google or Siri) https://www.youtube.com/watch?v=_XMu13OylbI Alexa The device supports Alexa through the connected phone in Android. Please make sure to install the Amazon Alexa companion app and make sure user settings are configured. Instructions to Configure and Add Device in Alexa Download the Amazon Alexa app.

  • Page 13: App Functionality

    App Functionality App Interface Main Screen...

  • Page 14: Additional App Features

    App Functionality Functions Provided With the App Display Fitness Data: steps, distance, calories and active time.  Find Glasses: Glasses will beep when the user selects the ‘Find  Glasses’ option on the app. Locate Glasses: If glass went to power off or glass got ...

  • Page 15: Locate Glasses

    App Functionality Find My Device Select the ‘Features’ tab on the main screen and select ‘Find My Device’. The glasses will beep for 10 seconds. Clicking this button again on the app or swiping on the left temple will stop the beeping.

  • Page 16: Play Notifications

    App Functionality Play Notifications Note: This feature is available only on Android. When a notification arrives, a beep is played on the glasses. If the user swipes forward on the right temple within 10 seconds of the beep, the notification message is played to the user. A swipe forward/backward while the notification is playing will stop the playback.
  • Page 17 App Functionality Custom Touch 1 (Time, Weather & Camera Snap) A swipe forward on the left temple will play the current time. The second swipe forward after the time is played will play the current weather. The weather units (C or F) can be configured from the settings screen.

  • Page 18: Presentation Controls

    App Functionality Custom Touch 2 (Find Phone) Two swipes backward (within 1 second) on the left temple will activate the ‘Find Phone’ feature. The phone will beep for 6 seconds. The beep can be stopped by another swipe backward. Presentation Controls A presentation on the user’s computer can be controlled using the swipe function of the glasses.

  • Page 19: Ppt Control Software On Windows Computer

    App Functionality PPT Control Software on Windows Computers Download and install the desktop/computer software from the  below link or the PPT companion app pop-up: https://www.fastrack.in/collections/reflex-wav Both the phone and computer must be connected to the same  network. Select the ‘Start Presentation’ option from the app drop-down ...

  • Page 20: Set Goals/Units

    App Functionality Set Goals/Units In Set Goals, the user can set the daily target steps and calorie  burn target. In Units, the user can select weight, height and distance units.  Sedentary Reminder The glasses will alert the user with “Idle for XXX time” when the user does not walk during daytime hours (8 am to 8 pm).

  • Page 21: Quit App

    App Functionality Settings Menu Quit App Please note that the app will run in the background even if it is swiped out in Android. To fully quit the app, use the Quit App option in the app. In the iPhone app, swiping the app out will fully quit the app.
  • Page 22 App Functionality In this feature you can opt for below microphone settings. Mic setting 1: Default setting that produces good crisp mic output. But on few phones, this option might produce some noise. If your caller on the other side complains about noise, you can switch to Mic setting 2 Mic setting 2: Setting that gives produces slightly mellowed...
  • Page 23 Device Reconnection Pairing to Multiple Phones or Switching Phones The device supports up to 4 phone/computer connections. First, disconnect EyeX from the previously connected phone/computer Bluetooth menu. EyeX is ready to pair with another phone or computer when the blue LED blinks on the right temple. Go to the Bluetooth menu of the new phone/computer and pair EyeX.
  • Page 24 App Functionality Eyecare Menu On the home screen, select the Eyecare menu.  These are a set of eye tests for users to test their vision.  Contact lens users can set notifications (monthly, quarterly,  half-yearly or yearly).
  • Page 25 Swipe Touch Operations Summary Features Operations Swipe forward or backward on both temples. A Power On (Master and Peer) touch will power on the device if it’s picked up from an upside-down position. If no phone/computer is connected, the device will be in discoverable mode with a blue light blinking.
  • Page 26 Swipe Touch Operations Summary Features Operations Swipe forward on the left temple. The first swipe Play Time, Weather will announce the time. A swipe again within and Snap Camera Selfie 5 seconds will announce the weather. (the app has to be connected) A swipe when the app camera screen is on will take a photo.
  • Page 27 Warranty & Support Eyex Non-prescription Warranty Policy The EyeX non-prescription warranty policy covers products against defects in materials and workmanship for a period of one (1) year from the original date of purchase. You are automatically eligible for EyeX warranty when you make a purchase on smartxglasses.com. No registration required.
  • Page 28 Maximum Volume in Android and iPhone EyeX uses a similar maximum volume on iPhone and Android. Please ensure the below are in default settings to get maximum volume from the phone. On iPhone, ensure that the Reduce Loud Sounds setting is not enabled.
  • Page 29 Maximum Volume in Android and iPhone On Android, ensure Dolby Atmos (or any other audio enhancer settings) is enabled.
