Zikodrive ZDSMUL2-24 Stepper DC Motor Controller Quick Start Guide
Document Number
Revision
Date
Authorised by
1-0092-A
A
26/10/2021
AC
Zikodrive Motor Controllers are a product of Round Bank Engineering Ltd
Floor 2, Clifton Warehouse, Sowerby Bridge, West Yorkshire, HX6 2BY
enquiries@Zikodrive.com
–
www.zikodrive.com
- +44 (0) 1422647177

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ZDSMUL2-24 and is the answer not in the manual?

Questions and answers

Related Manuals for Zikodrive ZDSMUL2-24

Summary of Contents for Zikodrive ZDSMUL2-24

  • Page 1 Zikodrive ZDSMUL2-24 Stepper DC Motor Controller Quick Start Guide Document Number Revision Date Authorised by 1-0092-A 26/10/2021 Zikodrive Motor Controllers are a product of Round Bank Engineering Ltd Floor 2, Clifton Warehouse, Sowerby Bridge, West Yorkshire, HX6 2BY enquiries@Zikodrive.com – www.zikodrive.com - +44 (0) 1422647177...

  • Page 2: Table Of Contents

    Analogue Speed Input ............................. 18 UART ................................18 Troubleshooting .............................. 19 Revisions ................................20 A: ................................20 Zikodrive Motor Controllers are a product of Round Bank Engineering Ltd Floor 2, Clifton Warehouse, Sowerby Bridge, West Yorkshire, HX6 2BY enquiries@Zikodrive.com – www.zikodrive.com...
  • Page 3 B: ................................20 C: ................................20 RETURNS ................................21 WARRANTY ..............................21 Zikodrive Motor Controllers are a product of Round Bank Engineering Ltd Floor 2, Clifton Warehouse, Sowerby Bridge, West Yorkshire, HX6 2BY enquiries@Zikodrive.com – www.zikodrive.com - +44 (0) 1422647177...

  • Page 4: Introduction

    Introduction This quick start guide provide an overview of how to setup and operate the ZDSMUL2-24 stepper motor controller. Please read in full before setting the controller up and if you have any questions or are unsure anything please contact our customer service team via our website (www.zikodrive.com) and we will be happy to help.

  • Page 5: Connections On The Zdsmul2-24

    TOP LEFT (MARKED RED AND BLACK). DO NOT CONNECT THE MAIN POWER SOURCE GND TO ONE OF THE OTHER GND CONNECTIONS. Zikodrive Motor Controllers are a product of Round Bank Engineering Ltd Floor 2, Clifton Warehouse, Sowerby Bridge, West Yorkshire, HX6 2BY enquiries@Zikodrive.com...

  • Page 6: Wiring Motor Phase Wires

    Blue Connecting the Power 5-24Vdc must be applied to the board on the terminals marked in “Connections on the ZDSMUL2-24” above. Connect the power to VS and the ground to the GND connection next to this. Once all these connections are complete, the Motor controller can be powered up and the device connected to the ZDA010 software for setup.

  • Page 7: Setting Up The Zda010 Controller Host Programme

    2. An .ini file to assist with parameter setup. 3. A ZDSMUL2-24 controller with power source. 4. A 3.3V FTDI cable (a TTL-232R-3V3 cable is available for purchase from www.zikodrive.com) 5. A computer or laptop with USB connection. Getting started 1.
  • Page 8 3. Upon opening the terminal, You must then load the .ini file for the ZDSMUL2-24 stepper motor controller. This can be done by going to File > Load Config and then selecting the .ini file supplied. This file is used to set all the key parameters and varies from controller to controller so it is important to make sure you have the correct file selected.
  • Page 9 If you can see the COM port open and the settings as indicated in the image on the right then you have now successfully connected to the controller and are able to set key parameters. Zikodrive Motor Controllers are a product of Round Bank Engineering Ltd Floor 2, Clifton Warehouse, Sowerby Bridge, West Yorkshire, HX6 2BY enquiries@Zikodrive.com...

  • Page 10: Using The Zda010 Software To Set Parameters

    “INVALID!!!” and the device will ignore the command that is out of range. You can now set and read all the key values required to operate the ZDSMUL2-24. Please read on for details on how to set these values as required for your project.

  • Page 11: Key Values

    Motor will run at the microstep resolution Motor will interpolate the microstep to 1/256 for smoother operation (useful for running with step inputs) Zikodrive Motor Controllers are a product of Round Bank Engineering Ltd Floor 2, Clifton Warehouse, Sowerby Bridge, West Yorkshire, HX6 2BY enquiries@Zikodrive.com –...

  • Page 12: Enable Input

    If using a switch, connect the switch to the DIR input and the 3V3 input on the same terminal block (see “Connections on the ZDSMUL2-24”). Zikodrive Motor Controllers are a product of Round Bank Engineering Ltd Floor 2, Clifton Warehouse, Sowerby Bridge, West Yorkshire, HX6 2BY enquiries@Zikodrive.com...

  • Page 13: Current Setting

    0.68 0.97 0.72 1.03 0.76 1.09 0.80 1.15 0.84 1.21 0.89 1.27 Zikodrive Motor Controllers are a product of Round Bank Engineering Ltd Floor 2, Clifton Warehouse, Sowerby Bridge, West Yorkshire, HX6 2BY enquiries@Zikodrive.com – www.zikodrive.com - +44 (0) 1422647177...

  • Page 14: Holding Current

    Whenever, the motor changes speed or direction it will reference the acceleration and deceleration values and operate accordingly. Zikodrive Motor Controllers are a product of Round Bank Engineering Ltd Floor 2, Clifton Warehouse, Sowerby Bridge, West Yorkshire, HX6 2BY enquiries@Zikodrive.com...

  • Page 15: Voltage Minimum

    400rpm, then set the value to 400. This will then mean that the maximum allowable speed the controller will run at in analogue mode will be 400rpm. Zikodrive Motor Controllers are a product of Round Bank Engineering Ltd Floor 2, Clifton Warehouse, Sowerby Bridge, West Yorkshire, HX6 2BY enquiries@Zikodrive.com...

  • Page 16: Output

    Output = 3: Output goes high once every turn. Output = 4: Output is constantly low. Output = 5: On when running, off while stopped. Zikodrive Motor Controllers are a product of Round Bank Engineering Ltd Floor 2, Clifton Warehouse, Sowerby Bridge, West Yorkshire, HX6 2BY enquiries@Zikodrive.com –...

  • Page 17: Other Inputs/Outputs

    The behaviour of this output pin can be changed using the OUT UART function. (page Error! Bookmark not defined.) Zikodrive Motor Controllers are a product of Round Bank Engineering Ltd Floor 2, Clifton Warehouse, Sowerby Bridge, West Yorkshire, HX6 2BY enquiries@Zikodrive.com...

  • Page 18: Analogue Speed Input

    TX = Yellow GND = Black ENSURE YOU USE A TTL-232-3V3 LEAD OR YOU COULD DAMAGE THE CONTROLLER Zikodrive Motor Controllers are a product of Round Bank Engineering Ltd Floor 2, Clifton Warehouse, Sowerby Bridge, West Yorkshire, HX6 2BY enquiries@Zikodrive.com –...

  • Page 19: Troubleshooting

    If you have any questions, please contact our team on +44 (0) 1422 647177 or visit www.zikodrive.com send us a support request. Zikodrive Motor Controllers are a product of Round Bank Engineering Ltd Floor 2, Clifton Warehouse, Sowerby Bridge, West Yorkshire, HX6 2BY enquiries@Zikodrive.com –...

  • Page 20: Revisions

    Revisions Wrote document based on previous document for the ZDSMUL2-24 for the Program Application V1.00. Revised to improve user friendliness and general flow. Altered document for firmware version V1.01 Zikodrive Motor Controllers are a product of Round Bank Engineering Ltd Floor 2, Clifton Warehouse, Sowerby Bridge, West Yorkshire, HX6 2BY enquiries@Zikodrive.com...
  • Page 21 The use of Zikodrive products in safety critical applications is entirely at the buyers risk, and the buyer agrees to defend, indemnify and hold harmless Round Bank Engineering ltd from any and all damages, claims, suits, or expenses resulting from such use.
  • Page 22 This product warranty does not cover damage caused during shipment and any damage caused by: actions that are beyond Zikodrive Motor Controller’s control, including (but not limited to) impacts, fluids, fire, flood, wind, earthquake, lightning or similar disaster, war, lockout, epidemic, destruction of production facilities, riot, insurrection, or material unavailability;...
  • Page 23 T C S E Q I - S T P : S T E P P E R C O N T R O L L E R S O F T WA R E G U I D E I M2 0 4 1 .
  • Page 24 E Q I - S T P E Q I - S T P E Q I - S T P D e s i g n e d & Ma n u f a c t u r e d i n t h e U n i t e d K i n g d o m b y T C S Mi c r o p u m p s L i m i t e d . i n f o @m i c r o p u m p s .
  • Page 25 E Q I - S T P s t e p p e r ( w w w . m i c r o p u m p s . c o . u k ) D e s i g n e d & Ma n u f a c t u r e d i n t h e U n i t e d K i n g d o m b y T C S Mi c r o p u m p s L i m i t e d . i n f o @m i c r o p u m p s .
  • Page 26 C o n n e c o n s o n t h e E Q I - S T P V o l t a g e i n p u t D I R E C T I O N ( 1 0 v - 2 4 v ) S T E P E N A B L E...
  • Page 27 G R E E N B L A C K B L U E R E D E Q I - S T P ” T C S H o s t D e s i g n e d & Ma n u f a c t u r e d i n t h e U n i t e d K i n g d o m b y T C S Mi c r o p u m p s L i m i t e d . i n f o @m i c r o p u m p s .
  • Page 28 T C S E Q I - S T P - t h i s c a n b e d o w n l o a d e d f r o m t h e T C S w e b s i t e u n d e r t h e ‘...
  • Page 29 E Q I - S T P s t e p p e r mo t o r D e s i g n e d & Ma n u f a c t u r e d i n t h e U n i t e d K i n g d o m b y T C S Mi c r o p u mp s L i mi t e d . i n f o @ mi c r o p u mp s .
  • Page 30 D e s i g n e d & Ma n u f a c t u r e d i n t h e U n i t e d K i n g d o m b y T C S Mi c r o p u mp s L i mi t e d . i n f o @ mi c r o p u mp s .
  • Page 31 T C S H o s t E Q I - S T P . D e s i g n e d & Ma n u f a c t u r e d i n t h e U n i t e d K i n g d o m b y T C S Mi c r o p u m p s L i m i t e d . i n f o @m i c r o p u m p s .
  • Page 32 c o n t a c t w w w . m i c r o p u m p s . c o . u k D e s i g n e d & Ma n u f a c t u r e d i n t h e U n i t e d K i n g d o m b y T C S Mi c r o p u m p s L i m i t e d . i n f o @m i c r o p u m p s .
  • Page 33 E Q I - S T P b o a r d E Q I - S T P b o a r d D e s i g n e d & Ma n u f a c t u r e d i n t h e U n i t e d K i n g d o m b y T C S Mi c r o p u m p s L i m i t e d . i n f o @m i c r o p u m p s .
  • Page 34 D e s i g n e d & Ma n u f a c t u r e d i n t h e U n i t e d K i n g d o m b y T C S Mi c r o p u m p s L i m i t e d . i n f o @m i c r o p u m p s .
  • Page 35 D e s i g n e d & Ma n u f a c t u r e d i n t h e U n i t e d K i n g d o m b y T C S Mi c r o p u m p s L i m i t e d . i n f o @m i c r o p u m p s .
  • Page 36 D e s i g n e d & Ma n u f a c t u r e d i n t h e U n i t e d K i n g d o m b y T C S Mi c r o p u m p s L i m i t e d . i n f o @m i c r o p u m p s .
  • Page 37 D e s i g n e d & Ma n u f a c t u r e d i n t h e U n i t e d K i n g d o m b y T C S Mi c r o p u m p s L i m i t e d . i n f o @m i c r o p u m p s .
  • Page 38 D e s i g n e d & Ma n u f a c t u r e d i n t h e U n i t e d K i n g d o m b y T C S Mi c r o p u m p s L i m i t e d . i n f o @m i c r o p u m p s .
  • Page 39 1 0 0 0 U s i n g t h e U A R T ( T C S - 6 5 1 ) P r o g r a m c a b l e : E n s u r e t h i s c a b l e i s t h e 3 V 3 v e r s i o n a n d n o h i g h e r a s t h i s c a n d a ma g e t h e b o a r d ! D e s i g n e d &...
  • Page 40 I f y o u h a v e a n y f u r t h e r q u e s o n s , p l e a s e c o n t a c t u s d i r e c t l y v i a o u r w e b s i t e o r p h o n e l i n e . D e s i g n e d &...
