Pana-Pacific ALLIANCE ABP N54B CP137WK Instruction Manual

Am/fm cd player with bluetooth
Hide thumbs
Table of Contents

Advertisement

Quick Links

ABP N54B CP137WK
AM/FM CD PLAYER WITH BLUETOOTH
INSTRUCTION MANUAL
LECTEUR CD AM/FM AVEC BLUETOOTH
MODE D'EMPLOI
REPRODUCTOR DE CD CON AM/FM Y BLUETOOTH
MANUAL DE INSTRUCCIONES
Brought to market by Pana-Paci c, Inc.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ALLIANCE ABP N54B CP137WK and is the answer not in the manual?

Questions and answers

Summary of Contents for Pana-Pacific ALLIANCE ABP N54B CP137WK

  • Page 1 ABP N54B CP137WK AM/FM CD PLAYER WITH BLUETOOTH INSTRUCTION MANUAL LECTEUR CD AM/FM AVEC BLUETOOTH MODE D’EMPLOI REPRODUCTOR DE CD CON AM/FM Y BLUETOOTH MANUAL DE INSTRUCCIONES Brought to market by Pana-Paci c, Inc.
  • Page 2 Before Use ....................3 Installation/Connection ............... 2 Basics ......................4 References ....................2 Getting Started ..................5 More information Change the display information 1 Set the clock and date 2 Set the other optional settings Troubleshooting ..................2 Radio ......................6 Specifications ..................

  • Page 3: Volume Setting

    [FUNCTION] menu. (Page 6) Do not operate any function that takes your attention away from safe [XX] driving. (Page XX) indicates references are available on the stated page. Volume setting: General: ENGLISH...
  • Page 4 * Only for illustration purpose. On the faceplate ENGLISH...

  • Page 5: Press And Hold

    Press B SRC repeatedly to enter STANDBY. Press the volume knob to enter [FUNCTION]. Turn the volume knob to select an item (see the following table), then press the knob. Repeat step 3 until the desired item is selected or activated. Press and hold to exit.
  • Page 6 [SOURCE SELECT] [SPOTIFY SRC] [ON]: Enables SPOTIFY/SPOTIFY BT in source selection. ; [OFF]: Disables. (Page 10) [BT AUDIO SRC] [ON]: Enables BT AUDIO in source selection. ; [OFF]: Disables. (Page ) [BUILT-IN AUX] [ON]: Enables AUX in source selection. ; [OFF]: Disables. (Page 11) [CD READ] [1]: Automatically distinguishes between audio file disc and music CD.
  • Page 7 Default: [XX] [TUNER SETTING] Eject disc Label side Selects the searching method for S / T buttons when pressed. [SEEK MODE] [AUTO1]: Automatically search for a station. ; [AUTO2]: Search for a preset station. ; [MANUAL]: Manually search for a station. [AUTO MEMORY] [YES]: Automatically starts memorizing 6 stations with good reception.
  • Page 8 While in USB source, press 5 repeatedly. On the faceplate [FUNCTION] Press the volume knob to enter [FUNCTION]. Turn the volume knob to select [USB], then press the knob. Turn the volume knob to select [MUSIC DRIVE], then press the knob. Turn the volume knob to select [DRIVE CHANGE], then press the knob.
  • Page 9 [SKIP SEARCH] setting Press the volume knob to enter [FUNCTION]. Turn the volume knob to select [USB], then press the knob. Turn the volume knob to select [SKIP SEARCH], then press the knob. [MODE OFF] Turn the volume knob to select the skip search ratio, then press the Press knob.
  • Page 10 On the faceplate Preparation: [ON] [SPOTIFY SRC] [SOURCE SELECT]. (Page 6) [REPEAT ALL] [REPEAT ONE] [REPEAT OFF] Start up the Spotify application on your device. Connect your device to the USB input terminal. [SHUFFLE ON] [SHUFFLE OFF] USB input terminal iPhone/ iPod touch *1 Available for premium account users only.
  • Page 11 Press Preparation: Turn the volume knob to select a list type, then press the knob. [ON] [BUILT-IN AUX] [SOURCE SELECT]. (Page 6) Turn the volume knob to select the desired song or station. Press the volume knob to confirm. Connect a portable audio player (commercially available). Auxiliary input jack Portable audio player 3.5 mm (1/8") stereo mini plug with “L”...

  • Page 12: Bluetooth Device

    Press B SRC to turn on the unit. Search and select the name of your receiver (“PP-BT-RADIO”) on the Bluetooth device. Supported Bluetooth profiles Press the volume knob to start pairing. Supported Bluetooth codecs [DEVICE DELETE] page 1 Rear panel Microphone [PHONE SELECT] [AUDIO SELECT]...
  • Page 13 [AUTO PAIRING] On the faceplate [ON] Press the volume knob to pair once you have confirmed the device name. [AUTO ANSWER] time. (Page 1 [00] [35] [15] *1 This adjustment will not affect the volume of the other sources. *2 Operations may vary according to the connected Bluetooth device. ENGLISH...
  • Page 14 Press the volume knob to enter [FUNCTION]. Turn the volume knob to select an item (see the following table), then Press to enter Bluetooth mode. press the knob. Repeat step 2 until the desired item is selected or activated. Press and hold to exit.
  • Page 15 [PHONE BOOK] (Applicable only if the phone supports PBAP.) 1 Turn the volume knob quickly to enter alphabet search mode (if the Press and hold to activate the voice recognition of the connected phonebook contains many contacts). phone. The first menu (ABCDEFGHIJK) appears. Speak the name of the contact you want to call or the voice command •...
  • Page 16 [INITIALIZE] [YES]: Initializes all the Bluetooth settings (including stored pairing, phonebook, and etc.). ; [NO]: Cancels. Press the volume knob to enter [FUNCTION]. Turn the volume knob to select an item (see the following table), then press the knob. Repeat step 2 until the desired item is selected/activated or follow the instructions stated on the selected item.
  • Page 17 On the faceplate [ALL RANDOM] [GROUP RANDOM] • [RANDOM OFF]. Press B SRC repeatedly to select iPod BT. Press B SRC repeatedly to select BT AUDIO. input terminal. (Page 7) Operate the audio player via Bluetooth to start playback. iPod BT source, the source automatically changes to iPod USB source. BSRC to select iPod BT source if the device is still connected via On the faceplate [ALL REPEAT] [FILE REPEAT] [GROUP REPEAT]...
  • Page 18 [MANUAL EQ] Adjusts your own sound settings for each source. • The settings are stored to [USER] in [PRESET EQ]. • The settings made may affect the current settings of [EASY EQ]. [62.5HZ] [LEVEL] [LEVEL –9] to [LEVEL +9] ([LEVEL 0]): Adjusts the level to memorize for each source.
  • Page 19 [SOUND EFFECT] [X ‘ OVER] [SOUND RECNSTR] [TWEETER] [FRQ] [1KHZ]/[1.6KHZ]/[2.5KHZ]/[4KHZ]/[5KHZ]/ (Not applicable for RADIO source and AUX source.) [ON]: Creates realistic sound by compensating the high-frequency [6.3KHZ]/[8KHZ]/[10KHZ]/[12.5KHZ]: Adjusts the (Sound reconstruction) components and restoring the rise-time of the waveform that are lost in crossover frequency for the tweeter speaker.
  • Page 20 [SW LPF SLOPE] [–6DB]/[–12DB]/[–18DB]/[–24DB]: Adjusts the crossover slope. (Selectable only if a setting other than [THROUGH] is selected for [SW LPF FRQ].) [SW LPF [REVERSE] (180°)/[NORMAL] (0°): Selects the PHASE] phase of the subwoofer output to be in line with the speaker output for optimum performance.
  • Page 21 [DISPLAY] [DIMMER] Dims the illumination. Insert the extraction keys deeply into the slots on each side, then [ON]: Dimmer is turned on. follow the arrows as shown on the illustration. [OFF]: Dimmer is turned off. [DIMMER TIME]: Set the time to turn on dimmer and to turn off dimmer. 1 Turn the volume knob to adjust the [ON] time, then press the knob.

  • Page 22: Wiring Connection

    Wiring connection Antenna terminal Fuse (10 A) Color and unction Yellow (Battery wire) If no connections are made, do not let the wire come out from the tab. : Ignition (ACC) Blue/White*1 : Power control Red (Ignition wire) STEERING WHEEL Light blue/yellow REMOTE INPUT To the steering wheel remote control...

  • Page 23: About Ipod/Iphone

    General About iPod/iPhone • This unit can only play the following CDs: • Made for – iPod touch (6th generation) – iPhone 5S, 6, 6 Plus, 6S, 6S Plus, SE, 7, 7 Plus, 8, 8 Plus, X, XS, XS MAX, XR (iOS 12.1 or later) •...
  • Page 24 Source name Display information: Main display STANDBY Source name/Clock Clock back to the beginning Each time you press DISP, the display information changes. • If the information is unavailable or not recorded, “NO TEXT”, “NO INFO”, or other information RADIO Source name/Clock Frequency Clock...
  • Page 25 Symptom Remedy Symptom Remedy Sound cannot be heard. • Adjust the volume to the optimum level. Playback order is not as The playback order is determined by the order in which • Check the cords and connections. intended. files were recorded (disc) or the file name (USB). “MISWIRING CHECK WIRING Turn the power off, then check to be sure the terminals of Elapsed playing time is not...
  • Page 26 Symptom Remedy Symptom Remedy “NA FILE” Make sure the media (disc/USB) contain supported audio No Bluetooth device is • Search from the Bluetooth device again. files. (Page ) detected. • Reset the unit. (Page 4) “COPY PRO” A copy-protected file is played (disc/USB). Bluetooth pairing cannot •...
  • Page 27 Symptom Remedy Frequency Range 87.9 MHz — 107.9 MHz (200 kHz step) “NOT SUPPORT” The connected phone does not support Voice Recognition Usable Sensitivity 8.2 dBf (0.71 V/75 Ω) feature or phonebook transfer. (S/N = 30 dB) “NO ENTRY” There is no registered device connected/found via Quieting Sensitivity 17.2 dBf (2.0 V/75 Ω) Bluetooth.
  • Page 28 USB Standard USB 1.1, USB 2.0 (High speed) Maximum Output Power 50 W × 4 File System FAT12/16/32 Full Bandwidth Power 22 W × 4 (at less than 1 % THD) Maximum Supply Current DC 5 V 1.5 A Speaker Impedance 4 Ω...
  • Page 29 FCC CAUTION Información acerca de la eliminación de equipos eléctricos y electrónicos al final de la vida Changes or modifications not expressly approved by the party responsible for compliance could void the útil (aplicable a los países que hayan adoptado sistemas independientes de recogida de user’s authority to operate the equipment.
  • Page 30 ISED CAUTION CAUTION This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science This equipment complies with FCC/ISED radiation exposure limits set forth for an uncontrolled and Economic Development Canada’s licence-exempt RSS(s). Operation is subject to the following two environment and meets the FCC radio frequency (RF) Exposure Guidelines and RSS-102 of the ISED radio conditions: frequency (RF) Exposure rules.

  • Page 31: Software License Agreement

    SOFTWARE LICENSE AGREEMENT Article 4 Right pertaining to the Licensed Software The software embedded in the Product (hereinafter the "Licensed Software") provided by Licensor is Any and all copyrights and other rights pertaining to the Licensed Software and related documents copyrighted to or sublicensable by the Licensor, and this Agreement provides for the terms and conditions shall belong to the Licensor or the original holder of the right who granted to the Licensor the license or which Users shall follow in order to use the Licensed Software.

  • Page 32: Important Notice Concerning The Software

    Important Notice concerning the Software Article 9 Destruction of the Licensed Software If this Agreement is terminated pursuant to the provision of Article 8, the User shall destroy the Licensed Software, any related documents and copies thereof within two (2) weeks from such date of termination. -jansson Copyright (c) 2009-2012 Petri Lehtinen <petri@digip.org>...
  • Page 33 -CMP sha2 AUTHOR: Aaron D. Gifford - http://www.aarongifford.com/ The MIT License (MIT) Copyright (c) 2014 Charles Gunyon Copyright (c) 2000-2001, Aaron D. Gifford All rights reserved. Permission is hereby granted, free of charge, to any person obtaining a copy of this software and associated documentation files (the "Software"), to deal in the Software without restriction, including without You may obtain a copy of the license at limitation the rights to use, copy, modify, merge, publish, distribute, sublicense, and/or sell copies of the...
  • Page 34 Copyright (c) 1995, 1996 Carnegie-Mellon University. All rights reserved. T-Kernel 2.0 This product uses the source code of T-Kernel 2.0 under T-License 2.0 granted by T-Engine Forum Author: Chris G. Demetriou (www.tron.org) Permission to use, copy, modify and distribute this software and its documentation is hereby granted, BSD-3-Clause provided that both the copyright notice and this permission notice appear in all copies of the software, Copyright (c) 2000-2001, Aaron D.
  • Page 35 • Windows Media is a registered trademark or trademark of Microsoft Corporation in the United States and/or other countries. This product is protected by certain intellectual property rights of Microsoft. Use or distribution of such technology outside of this product is prohibited without a license from Microsoft. •...
