MTX Thunder 895 Install Manual

MTX Thunder 895 Install Manual

Amplifier input connections

Advertisement

AMPLIFIER
Crossover
Select Switch
Front RCA Inputs

Amplifier Crossover Select Switch Settings:

Rear:
5.25" or Smaller
6.5" or Larger
FR HP
FR HP
Front:
5.25" or Smaller
6.5" or Larger
FR HP
FR HP

Amplifier Input Connections

Crossover
Select Switch
Rear RCA
Inputs
Subwoofer
RCA Inputs
For installation options go to mtx.com
Remote/Power Antenna
Turn-On Wire
CAR STEREO
(SOURCE UNIT)
REQUIRED INSTALLATION
Adjustable Wrench
TOOLS:
Power Drill
Utility Knife
Crimpers
Screw Driver
Part #: NDM291

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Thunder 895 and is the answer not in the manual?

Questions and answers

Summary of Contents for MTX Thunder 895

  • Page 1 FR HP FR HP Amplifier Input Connections Crossover Select Switch Remote/Power Antenna Rear RCA Inputs Subwoofer RCA Inputs For installation options go to mtx.com Turn-On Wire CAR STEREO (SOURCE UNIT) REQUIRED INSTALLATION TOOLS: Power Drill Adjustable Wrench • Crimpers •...
  • Page 2 Ground To Metal Of Vehicle Connect to Car Stereo Remote/Power Antenna Turn-On Wire Grommet Minimum Wire Size: Remove Paint Disconnect Power: 4 AWG. Ground: 4 AWG. from Metal Battery Negative (-) Cable Prior to Installing Amplifier For installation options go to mtx.com...
