Universal Communication Gateway Reference Manual
Universal Communication
Gateway Reference Manual
The Universal Communication Gateway (UCG) is an external, high performance Building
Automation multi-protocol gateway that is preconfigured to automatically communicate
between Bryan Steam's products (hereafter called "device") connected to the UCG and
automatically configures them for BACnet®MS/TP, BACnet IP, Metasys®N2 by JCI,
Modbus TCP/IP or LonWorks®. All Honeywell SOLA, Siemens RWF 40/55, Siemens LMV,
Honeywell RM7800 Series and the Precision Digital Trident PD765 boiler configurations
and Node-ID's are selected through the UCG Web GUI Configurator for fast and easy
installation. A mix of multiple devices can be used on a single UCG. It is not necessary to
download any configuration files to support the required applications. The UCG is pre-
loaded with tested Profiles/Configurations for the supported devices. This document
provides the necessary information to facilitate installation of the UCG on BACnet
MS/TP, BACnet/IP, Metasys N2 and LonWorks network.
The UCG is provided as a 10" x 12" x 6" NEMA Type 1 control panel that must be
mounted and supplied with 120 VAC. Additional specifications can be found in
7.
1. If your boiler is equipped with a Bryan Boilers Printed Circuit Board
(WD-857), devices should be pre-wired. See
2. Each boiler device Modbus settings must be configured to
communicate to the UCG.
Bryan Steam LLC, 783 North Chili Avenue, Peru, IN 46970 Web:
Phone: 765.473.6651 Fax: 765.473.3074 E-mail:
Important
sales@bryansteam.com
i
Date: 01-25-2019
section
3.1.8.
www.bryanboilers.com
Form: 2405
Revision: 8
Section
