Summary of Contents for BURTON SECURITY Keyguard IKMS
- Page 1 Packing Details KeyTag X 31 Key Cabinet X 1 Power Cable X 1 KeySeal X 31 Mechanical Key X 4 Expansion Bolt X 5 Operation Manual X 1 KeyLabel X 31 Version 1 - P1 - 30/11/2022...
-
Page 2: Technical Parameters
Technical Parameters 380mm 566mm 177mm Power Supply 220V > 12V / 5Ah Key positions Dimensions (L*W*H) 566mm x 177mm x 380mm Power Consumption 60W Max Weight 17kg Operating System Android 4.4 Material 1.5mm thick steel + ABS Display 7” Touchscreen Door Solid Steel (Standard) Certifications... -
Page 3: Administrator Login
Administrator Login 21-07-2020 08:00 Click the Touchscreen. Input the Administrator ID ”00000”. Input the Administrator Password ”00000”. Click ”Login”. ID and Password The administrator ID ”00000” cannot be changed, the Password can be changed. Main Interface 21-07-2020 08:00 The main interface shows the status of all keys. Welcome Nadine Franke present... -
Page 4: Key Registration
Key Registration Main interface → Settings → Key settings Select one key, press and hold for 1 second. Click “ ” to select all keys, then click ” ” to register. Insert all KeyTags. Close the door. All key icons change green, registration done. Key Settings Main interface →... -
Page 5: User Settings
Add User Main interface → Settings → User settings Click ” ”. Input “User name”, ”User ID”, “Telefon”, and ”Email”. 3 Set the login type “Fingerprint”, ”Face ID”, “Card”, and ”Password”. 4 Select the user type. 5 Select the valid time. User Settings Change user information Select one user, press and hold for 1 second. - Page 6 Custom Group Add Group Click “Group”, then click ” ”. Input "Group name" . Select “Operation permission”. Select “Valid time”. Select “Key permission”. User Permission Administrator have all Permission and common user do not have Permission by default. Customize user permissions by grouping.
- Page 7 Add Fingerprint, Face ID, and Card Add Fingerprint Select one user, then press “ ”. Click “Fingerprint”. Register fingerprints. Add Face Select one user, then press “ ”. Click “Face ID”. Stand before the camera. Add User Card Select one user, then press “ ”.
-
Page 8: Event Settings
Verification Settings Add Multi-verification Main interface → Settings → Multi-verification settings Press “ ”. Select "Key", “User” and "Verifier". Event Settings Add Event Main interface → Settings → Event settings Press “ ”. Input "Event", then press “OK”. 3 Click “ ”. - Page 9 Take Keys 21-07-2020 08:00 By Password Input “user ID” and “user password”. Click “Login”, select a key, take the key. By Face ID press “ ”. User ID Stand before the camera. Password Select a key, take the key. Login By Fingerprint Input “user ID”, then press “...
-
Page 10: System Alarm
System Alarm Open the door Illegally When open the door by incorrect ways, the system will alarm and all KeySlots will flash red. Door open overdue If the door is not closed within the set time (Can be changed in Cabinet Settings), the system will alarm. Foreign object in the KeySlot If there is foreign oject in the KeySlot, the system will alarm and ask to take it out. -
Page 11: Remote Control
View and Export Report Main interface → Report Click “General”, “Abnormal” and “Log” to view report. Export Report Click ” ”, select ”pages”. Click ”Export to external storage device” or click ”Send email”. Click ”Open door” . Insert USB external storage device. Remote Control One platform controls multiple key cabinets Use the network cable or enable the wifi. - Page 12 Special Announcement Please refer to the actual product, the instructions are for reference only. The manual and program will be updated in real time according to the product, and there will be no further notice if there is an upgrade. If you do not follow the instructions in the manual, the user shall bear any losses caused thereby.
