www.eyedaptic.com

EYE5

Eyedaptic Glasses User Manual

Version 5.0.0/0

EYE5 MD3

Enhancing Vision To Revitalize Life

Table of Contents

Need help?

Do you have a question about the EYE5 and is the answer not in the manual?

Questions and answers

Summary of Contents for Eyedaptic EYE5

Page 1 ® www.eyedaptic.com EYE5 Eyedaptic Glasses User Manual Version 5.0.0/0 EYE5 MD3 Enhancing Vision To Revitalize Life...
Page 2: Package Contents
(C) Data cable to connect glasses to (A) EYE5 glasses phone (L shaped plug) (D) USB charger block (B) Mobile phone with pre-installed software to control EYE5 glasses (E) Charging cable for the PHONE only *Cables (C) and (E) are NOT interchangeable...
Page 3 EYE5 Glasses (A) - Parts Overview EyeSwitch toggle button Adjustable nose pad EYE5 connection port L shaped side of the data cable (C) Use the included data cable to plugs into glasses - must use this connect the phone to the glasses...
Page 4 EYE5 Phone (B) – Parts Overview Zoom adjuster Press the up/down buttons to adjust zoom level Power save mode Press once to turn off the phone display, but leave the glasses on Press again to turn Sleep mode and phone display back on...
Page 5: How To Power On/Off
How to Power On/Off • To power on the phone: hold the power button for 5 seconds, or until the screen lights up • To power off the phone: hold the power button for 5 seconds, click on the "Power Off" option, and the screen will go dark "Power Off"...
Page 6 How to Charge the Phone Only the phone needs to be charged, the glasses do not need to be charged 1. Plug the charging cable (E) into the charging block (D) 2. Plug the charging cable (E) into the phone (B) DO NOT USE THE DATA CABLE FOR CHARGING 3.
Page 7: Sleep Mode
Sleep Mode Sleep mode puts the phone display and the glasses to sleep, but does not completely turn off the device – this will save battery To activate sleep mode: press the power button once (top right) - the phone screen AND glasses will go dark Phone is in sleep mode, glasses are off Power...
Page 8: Power Save Mode
Power Save Mode Power save mode turns the phone screen off, but the glasses remain on To activate power save mode: press the top left button once – the screen will go dark and a flashing arrow will appear Phone is in power save mode, glasses are still on Power save button...
Page 9 Setting up the Phone & Glasses Before using EYE5 glasses for the first time: Fully charge the phone battery, until light at the top of the phone turns green or percentage on the phone is 100% After the battery is charged:...
Page 10 (C) into the glasses (A) and the other side into the phone (B) Wait for the EYE5 app to launch automatically or press the Eyedaptic logo to start the app If the app does not open, unplug the cable from the phone, wait 5 seconds,...
Page 11: Home Page Overview
Home Page Home Page Overview Opens up the settings Turns menu EyeSwitch Toggles Toggles Britext autozoom on/off on/off Set favorite features Slide along the bar to Scroll up or down to see manually change magnification additional features (when autozoom is OFF)
Page 12 Home Page EyeSwitch changes the mode of viewing from the camera on the glasses to the camera on the phone Turns Turns EyeSwitch EyeSwitch In EyeSwitch mode the settings options are simplified to just Autozoom and Britext...
Page 13 Home Page EyeSwitch mode can also be activated by the button on the glasses Press and this button and once released, it will activate EyeSwitch mode It may take a second to change modes - you will get an audio confirmation...
Page 14 Home Page Settings Returns to Opens up the home page settings page Scroll up or down to see all menu options...
Page 15: Manual Zoom
Home Page Manual Zoom Manual zoom allows the user to control full-screen magnification by adjusting the zoom slider at the bottom of the home screen Magnification – fades, reappears when adjusted Slide along the bar to manually change magnification (when autozoom is OFF)
Page 16 Home Page Autozoom Autozoom mode prompts the glasses to automatically zoom in on TEXT and FACES when detected Toggles autozoom on/off To switch Toggle between text between and facial text and detection faces...
Page 17 Home Page Autozoom - Text Autozoom in text mode prompts the glasses to automatically zoom in on text when detected A box will appear on the screen and prompt the zoom Read text with slow head motion Large head movement It will zoom to preferred or a quick shake will text size, which is...
Page 18 Home Page Autozoom - Faces Autozoom in text mode prompts the glasses to automatically zoom in on faces when detected A box will appear on the screen and prompt the zoom - this box will fade after a few seconds and will reappear with head movement Facial recognition will only work if the...
Page 19 Settings Autozoom - Settings Additional autozoom settings can be adjusted from the settings page Toggles Adjust how much head autozoom motion is needed to on/off zoom out of autozoom Controls how quickly the glasses recognize text Switch between text and faces...
Page 20 Home Page Britext Britext mode is a contrast enhancement that outlines the edges of text and objects, making them easier to distinguish Toggles Britext on/off Britext off Britext on...
Page 21 Home Page Contrast Contrast options can be opened from either the home page or the settings page...
Page 22 Home Page Contrast Toggles auto-contrast on and off Auto-contrast automatically turns Britext on when the zoom level is greater than 1 Slide to manually adjust the contrast 0% is NORMAL contrast and is best for most situations...
Page 23 Home Page Brightness Brightness options can be opened by either scrolling down on the home page or from the settings page Slide up and down to change the brightness of the GLASSES display...
Page 24 Home Page Making/Changing Favorites Adjust settings to your Favorite is now saved liking and click "Save as" and active (ie. Autozoom on, Britext on, (Highlighted number) contrast 20%) Select a favorite to save the selected settings as and click save (1, 2 or 3)
Page 25 Home Page Restoring a Favorite As soon as you change a setting, To restore a favorite, click the favorite will be deselected on the number (not highlighted anymore) (now highlighted again)
Page 26: Portal Settings
Settings Portal Settings Portal mode magnifies the text within a circle and tapers out at the edges – this mode is good for reading or spotting *Autozoom must be on and in TEXT mode to enable the portal Toggles portal on/off...
Page 27 Settings Reference Line Settings Places a horizontal line across the screen Toggles reference line on/off Adjust the vertical placement of the line Changes the color of the line...
Page 28: Stabilization Settings
Settings Stabilization Settings Toggles stabilization on/off Adjusts the strength Turns of stabilization stabilization on when the zoom is above this level (we recommend leaving this at 1.0x zoom)
Page 29 Settings Configuration Show or hide the EyeSwitch button on Configuration: Configuration: the home page EyeSwitch show EyeSwitch hide The button on the top right of the glasses will still turn on EyeSwitch even if the button is hidden...
Page 30 Settings Notifications Toggle notifications for low battery on/off...
Page 31 Settings Updates The phone must be connected to Wi-Fi (see page 33) to update Update available No updates available for download Click to update app to new version...
Page 32 Settings Audio Audio plays when certain settings or features are turned on/off Slide left to right to adjust the volume – a sound will play to indicate the set volume level A volume of "0" mutes the audio...
Page 33 Settings Connect to Wi-Fi Sample WiFi To connect to Wi-Fi, click "Configure" and select the desired network – you must then re-open the app...
Page 34 Fob Overview Hold to turn fob on/off Toggles between manual Manual zoom increase zoom and autozoom Cycle through contrast modes Black on white White on black Color (normal) Toggles Britext on/off Green light: device is on Manual zoom decrease Red light: fob needs to be charged...
Page 35: Troubleshooting
If the app crashes or does not start: 1. Unplug the cable from the phone 2. Wait 5 seconds Eyedaptic 3. Plug the cable back in logo and try again 4. If needed, launch the app manually by clicking the Eyedaptic logo Cable...
Page 36 Troubleshooting If all else fails: 1. Unplug the cable from "Power Off" Power button the phone 2. Turn the phone off by holding down the power button for a few seconds and then click "Power Off" 2. Wait 5 seconds 3.
Page 37 Troubleshooting If the following message pops up: EYE 5 Allow EYE 5 to access Rokid Air Pro (5.0.1)? ❑ Always open EYE 5 when Rokid Air Pro (5.0.1) is connected This message may pop up once or twice, just click on the box each time it happens and try opening the app again This may occur if you plug the cable in and connect the phone to the glasses before turning the phone on...
Page 38 Troubleshooting Do not remove the gray hybrid see through shields from the glasses displays! These shields need to stay on to optimize the visual enhancement experience of the glasses. Please do not remove them! https://eyedaptic.com/patents/...
Page 39 Troubleshooting If the glare guards come off: *The glasses can function without them If you would like to reattach them, see below (keep in mind, the parts are small, so it may be challenging and take a few minutes): 1. Locate the two ends of the glare guard 2.
Page 40: Operating Specifications
Storage Temperature Range: 40-80 degrees Fahrenheit Usage Temperature Range: 40-80 degrees Fahrenheit • Do not use near water • Do not store in direct sunlight • Do not store in a HOT or COLD car • Do not use chemical cleaners on lens Patents www.eyedaptic.com/patents...
Page 41 User violates any of the terms and conditions of this Agreement or if Eyedaptic is required to do so by law. Upon termination (i) all rights granted to User under this Agreement will terminate; and (ii) User must cease all use of the Application. Terminat ion will not limit any of Eyedaptic’s rights or remedies at law or in equity.
Page 42 Please Don’t Forget 1. Register your product at https://eyedaptic.com/product-registration/ 2. Do not put your personal SIM card into the phone. The phone will no longer work with the glasses and it will invalidate your warranty. 3. If you have more than one pair of glasses, be sure to...
